Gyro PCB Installation/Replacement
Instructions for TracVision
These instructions explain how to install or replace a gyro PCB in a TracVision M5/M7 antenna.
Installation/Replacement Steps
Tools Required
This procedure requires the following tools:
• #1 Phillips screwdriver
• #2 Phillips screwdriver
• Cutting pliers
• PC with the latest version of the Flash Update Wizard installed
TIP: The Flash Update Wizard is available to KVH-authorized dealers through the KVH Partner
Portal at www.kvh.com/partners.
Technical Support
If you need technical assistance, please contact KVH Technical Support:
N. America, S. America, Australia:
Phone: +1 401 847-3327
E-mail: techs@kvh.com
KVH, TracVision, and the unique light-colored dome with dark contrasting baseplate are registered trademarks of KVH Industries, Inc. All
other trademarks are property of their respective companies. The information in this document is subject to change without notice. No
company shall be liable for errors contained herein. © 2009-2010 KVH Industries, Inc., All rights reserved. 54-0639 Rev. B
®
Europe, Middle East, Asia:
Phone: +45 45 160 180
E-mail: support@kvh.dk
M5/M7
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TracVision M5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KVH Industries TracVision M5

Summary of Contents for KVH Industries TracVision M5

  • Page 1 E-mail: support@kvh.dk KVH, TracVision, and the unique light-colored dome with dark contrasting baseplate are registered trademarks of KVH Industries, Inc. All other trademarks are property of their respective companies. The information in this document is subject to change without notice. No...
  • Page 2 Step 1 - Remove the Radome Figure 1 TracVision M5 Radome/Main PCB Cover Screws Follow the steps below to remove the radome. CAUTION For your own safety, be sure to disconnect power from all wired components before Radome performing this procedure.
  • Page 3 Step 3 - Install/Replace the Gyro PCB Figure 3 Gyro PCB Location/Connections Refer to Figure 3 to determine if your TracVision Tie-wrap Gyro PCB system includes a gyro PCB. If a gyro PCB is Elevation currently installed, proceed to Option A. If a gyro Jumper Gyro Cable...
  • Page 4 e. Reverse these instructions to install the new Figure 5 Ferrite Coil Installed gyro PCB. Ferrite Coil NOTE: Be sure to install the jumper cable supplied in the kit with its ferrite coil installed (see Figure 5), and secure the jumper cable’s connector to the gyro PCB, using a supplied tie- wrap (see Figure 6).
  • Page 5 Option B - Install a Gyro PCB Figure 7 Gyro PCB Standoffs Depending on the serial number, some TracVision M5/M7 systems require installing a gyro PCB and modifying connections. The following instructions apply only to the serial numbers specified below.
  • Page 6 c. Disconnect the gyros from the main PCB. Figure 9 Gyro Connections Then connect them to the gyro PCB connectors, as shown in Figure 9. Gyro PCB d. Install the ferrite coil onto the supplied jumper cable, as shown in Figure 10. e.
  • Page 7 PCB cover and radome. Be sure to position the cover carefully to avoid damage to the PCBs or cables. a. TracVision M5 – Secure the main PCB cover using the six Phillips screws you removed in “Step 2 - Remove the Main PCB Cover” on page 2 (see Figure 1 on page 2).
