- Page 1 ’ peratOr s manual WEED BRUSH City Ranger 2200...
- Page 2 Introduction Dear Customer Congratulations with your new Nilfisk-Egholm product. The City Ranger 2200 is a Danish designed and manufactured product, which offers a very flexible way of maintaining outdoor areas. Optimal use of your Nilfisk-Egholm Weed Brush: To ensure optimal performance of your Nilfisk-Egholm Weed Brush, please read this manual carefully before using the machine.
-
Page 3: Table Of Contents
5.1 Spare parts - City Ranger 2200 Weed Brush ....... . -
Page 4: General Information
10°. (Picture 3) When using with hopper. Read the safety instructions in the Suction Sweeper Max. 10° Operator’s Manual. Do not drive on slopes with an incline of more than 10° Operator’s Manual City Ranger 2200 Weed Brush... -
Page 5: Ec Declaration Of Conformity
+45 97 81 12 05 Telephone: hereby declares that The machine: Weed Brush 22UKB2200 Type: · has been manufactured in conformity with the provisions of the Machinery Directive 2006/42/EU Place: Lemvig Date: Signature: Knud Olsen, Senior Engineer Operator’s Manual City Ranger 2200 Weed Brush... -
Page 6: Technical Data
Ground clearance under brush 330 mm Ground clearance under vacuum nozzle 90 mm Brush diameter 675 mm Weed Brush weight 115 kg Typical working speed 2-4 km/h N.B! Specifications may be changed without prior notice. Operator’s Manual City Ranger 2200 Weed Brush... -
Page 7: Operator's Manual
A-frame. (Picture 4) The locking handle can only be engaged when the machine has been stopped. Removing: Locking Follow the procedure for fitting in the reverse order. Joystick Locking the attachment Operator’s Manual City Ranger 2200 Weed Brush... -
Page 8: Before Start-Up
It is recommended that counterweights are fitted to the machine for stability when using the Weed Brush with the Suction Sweeper hopper tank. New counterweights can be ordered from an authorised Nilfisk-Egholm distributor. Transport lock – unlocked Operator’s Manual City Ranger 2200 Weed Brush... -
Page 9: Weed Brush Applications
Vertical scouring requires weight distribution. (See City Ranger 2200 operator’s manual) Tips! The brush can also scour in front of the machine, so the operator can easily clean pavements and deep gutters. (Picture 4) Operator’s Manual City Ranger 2200 Weed Brush... -
Page 10: Change Between Vertical And Horizontal Brushing
(Picture 4) Positioning the brush completely vertically requires extra 3. Vertical left – 1. Horizontal– 2. Vertical right adjustment using the joystick. (See Section 2.7) Free/continue turning Operator’s Manual City Ranger 2200 Weed Brush... -
Page 11: Sideways Arm Movement
The arm can move from side to side: (Pictures 1 and 2) Left 1. Move the joystick sideways to move the arm out to the side. (Picture 3) The arm swings in the same direction as the joystick. Right Operator’s Manual City Ranger 2200 Weed Brush... -
Page 12: Forward/Back Brush Adjustment
The brush can tilt forward and back. (Pictures 1 and 2) 1. Move switch F2 to locked position (R). (Picture 3) 2. Move joystick sideways. (Picture 4) The brush tilts forward and back. Forward Back Switch F2, locked position Forward - Back Operator’s Manual City Ranger 2200 Weed Brush... -
Page 13: Sideways Brush Adjustment
1. Press on the black button on the joystick. (Picture 3) 2. Move joystick sideways. (Picture 3) The brush tilts in the same direction as the joystick. Left Right Engage the black button and move sideways Operator’s Manual City Ranger 2200 Weed Brush... -
Page 14: Keeps Areas Weed-Free By Collecting
Repeat the process in reverse order to detach vacuum nozzle. Tips! When the vacuum nozzle is not in use, it can be stored away, preventing the rubber guard from being warped. Vacuum nozzle fitted Operator’s Manual City Ranger 2200 Weed Brush... -
Page 15: Directional-Rotation And Resonances
These resonances can also be generated when the direction of rotation is changed or if the operator drives too fast. To avoid resonances, slightly tilt the brush initially or drive Left more slowly. Operator’s Manual City Ranger 2200 Weed Brush... -
Page 16: Guard Use
2. The guard can be raised if it gets in the way. (Picture 2) 3. If the guard needs to be lowered again, pull the button Raised and push guard down manually. (Picture 3) Release button Operator’s Manual City Ranger 2200 Weed Brush... -
Page 17: Weed Brush Start-Up
Weed Brush. See the City Ranger 2200 operator’s manual. Tip! Regulating brush speed reduces wear on the brush and on surfaces. See the City Ranger 2200 operator’s manual. Operator’s Manual City Ranger 2200 Weed Brush... -
Page 18: Service And Maintenance
1. Place the brush flat on the ground. 2. Loosen the three bolts. (Picture 4) Parallel 3. Adjust the guard so that it is parallel to the surface. 4. Tighten the bolts. Loosen the bolts. Guard parallel with surface Operator’s Manual City Ranger 2200 Weed Brush... -
Page 19: Adjusting The Vacuum Nozzle
X, remove a washer. One washer alters the distance by 6 mm. Both bolts must have the same number of washers. 6. Tighten the bolts and repeat steps 1 and 2. Remove bolts Extra washers underneath Operator’s Manual City Ranger 2200 Weed Brush... - Page 20 7. Adjust the angle so there is the same distance (X) in front and behind the wheel (Picture 2) and tighten the bolts on both sides. (Picture 1) Wheel bolt Pos 1, Pos 2, Pos 3, Pos 4 Operator’s Manual City Ranger 2200 Weed Brush...
-
Page 21: Lubrication / Storage
Make sure no one is under the brush when the bolts are removed. The brush is abrasive. Use protective gloves. A new brush can be ordered from an authorised Nilfisk- Egholm dealer. Three nuts Operator’s Manual City Ranger 2200 Weed Brush... -
Page 22: Guard Maintenance
2. Remove rubber profile. (Picture 2) 3. Fit new rubber profile and tighten screws. Nuts Changing a wheel 1. Remove the bolt and wheel. (Picture 3) 2. Fit new wheel. 3. Tighten bolt. Remove rubber profile Remove nut Operator’s Manual City Ranger 2200 Weed Brush... -
Page 23: Replacing Rubber Profile On Vacuum Nozzle
(See Section 2.6) Collecting Ensure that the vacuum hose below the machine is not blocked. Check vacuum nozzle adjustment. (See section 3.3) See also the troubleshooting section in the Suction Sweeper operator’s manual. Operator’s Manual City Ranger 2200 Weed Brush... -
Page 24: Conditions
· Machines with illegible serial numbers. · Damage caused by force majeure such as lightning, flood, fire, war, civil disturbance, etc. or other causes over which Nilfisk-Egholm A/S has no control. Operator’s Manual City Ranger 2200 Weed Brush... -
Page 25: Complaints
2. Remove all plastic and rubber parts and dispose of. 3. After the parts mentioned have been removed, the machine is ready to be handed over to one of your local approved scrap merchants. Operator’s Manual City Ranger 2200 Weed Brush... -
Page 26: Spare Parts
Spare parts 5.1 Spare parts - City Ranger 2200 Weed Brush 01103210 Strong brush 01103060 Soft weed brush 70501121 Guard service kit 70501111 Vacuum nozzle service kit 70501101 Nozzle kit Operator’s Manual City Ranger 2200 Weed Brush... -
Page 27: Notes
Notes Operator’s Manual City Ranger 2200 Weed Brush... - Page 28 Nilfisk-Egholm A/S Transportvej 27 DK-7620 Lemvig T. +45 97 81 12 05 F. +45 97 81 12 10 www.nilfisk-egholm.com info@egholm.dk 70101141-01 UK...
