Thor Gas Salamander
Installation and Operation Instructions
Model: GL163-P, GL163-N
Please complete this information and retain this manual for the life of the equipment. For Warranty
Service and/or parts, this information is required.
Model Number
WARNING: For your safety, do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliances. Keep the area free and clear of
combustible materials.
WARNING ： Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury, or death. Read the installation operating and maintenance
instructions thoroughly before installing, or servicing this equipment.
WARNING：Instructions must be posted in a prominent location. All safety
precautions must be taken in the event the user smells gas. Safety information can be
obtained from your local gas supplier.
IMPORTANT FOR FUTURE REFERENCE
Serial Number
Fourth Way, Avonmouth, Bristol, BS11 8TB
Date Purchased
Advertisement
Table of Contents
Related Manuals for THOR Salamander GL163-P
Summary of Contents for THOR Salamander GL163-P
- Page 1 Thor Gas Salamander Installation and Operation Instructions Model: GL163-P, GL163-N IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or parts, this information is required. Model Number Serial Number...
-
Page 2: Table Of Contents
Contents Introduction ..................... 2 Specifications ................... 3 General Pack Contents Gas Supply Requirements Dimensions ....................4 Installation ....................5 Installation Requirements Unpacking Location Clearances Wall mounting Gas Connection Commissioning Operation ....................9 Operation Guide Description of Controls Lighting the Main Burner Racking system Cooking recommendation Cleaning and Maintenance ................9... -
Page 3: Introduction
Introduction We are confident that you will be delighted with your Thor Gas Salamander, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Gas Salamander, there are two important things you can do. -
Page 4: Specifications
Specifications General Commercial heavy duty, wall mounted gas fired infra-red grilling salamander. Pack Contents The following is included: Thor Gas Salamander 1pc rack Instruction Manual Wall Mounting Bracket, including: -2 x 25mm Black Plastic Spacer. -2 x 3/8” Bolts/Nuts Gas Supply Requirements... -
Page 5: Dimensions
Dimensions Dimensions for Gas Salamander Note: gas salamander rack can load-bearing: 15kg (33 lb) -
Page 6: Installation
NOTE: It is most important that this salamander is installed correctly and that operation is correct before use. Installation shall comply with local gas and health and safety requirements. Thor Gas Salamanders are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. -
Page 7: Clearances
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED SERVICE PERSON. 1. Thor salamanders do not require an electrical connection, as they function totally on the gas supply only. 2. It is essential that the gas supply is correct for the salamander to be installed and that adequate supply pressure and volume are available. - Page 8 Installation (Continued) b. Supply Pressure required for this appliance is shown in the ‘Specifications’ section of this manual. Check the gas supply to ensure adequate supply pressure exists. c. Input Rate of this appliance is stated on the Rating Plate fitted on the R/H side panel and in the 'Specifications' section of this manual.
-
Page 9: Commissioning
Installation (Continued) Commissioning The following commissioning checks must be carried out before the appliance is handed over for use, to ensure that the unit operates correctly and the operator(s) understand the correct operating procedure. 1. Before leaving the new installation; a. -
Page 10: Operation
COMPONENTS HAVING ADJUSTMENTS PROTECTED (E.G. PAINT SEALED) BY THE MANUFACTURER SHOULD NOT BE ADJUSTED BY THE USER/OPERATOR. Thor Gas Salamanders have been designed to provide simplicity of operation and 100% safety protection. Improper operation is therefore almost impossible, however bad operation practices can reduce the life of the gas salamander and produce a poor quality product. - Page 11 ACCESSORIES, IF USED. IT IS NOT TO BE EXCEEDED. 1. The Thor Salamander has been designed to give a good evenness of heat across the rack area, so toasting, cheese melting and grilling should be relatively even wherever food is placed.
-
Page 12: Cleaning And Maintenance
Cleaning and Maintenance General • To achieve the best results cleaning must be regular and thorough. All controls and mechanical parts should be checked and adjusted periodically by a qualified service person. If any small faults occur, have them attended to promptly. •... -
Page 13: Gas Conversion Procedure
Gas Conversion Procedure NOTE: • These conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. • For all the following conversion instructions, the side panels have to be removed (Remove the two screws at the bottom of each side panel). -
Page 14: Explosion Drawing
Explosion drawing... -
Page 15: Spare Parts List
Explosion drawing Spare Parts List... - Page 16 Spare Parts List (Continued)
- Page 17 Fourth Way, Avonmouth, Bristol, BS11 8TB...
