THOR GH104-N Technical & Service Manual

Gas char-broiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Thor Gas Char-Broiler
Technical Service Manual
Model: GH103-P, GH103-N, GH104-P, GH104-N N
IMPORTANT FOR FUTURE REFERENCE
Please complete this information and retain this manual for the life of the equipment. For Warranty
Model Number
WARNING: For your safety, do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliances. Keep the area free and clear of
combustible.
WARNING：Improper installation, adjustment, alteration, service or maintenance can
cause property damage, injury, or death. Read the installation operating and
maintenance instructions thoroughly before installing, or servicing this equipment.
WARNING：Instructions must be posted in a prominent location. All safety
precautions must be taken in the event the user smells gas. Safety information can be
obtained from your local gas supplier.
Service and/or parts, this information is required.
Serial Number
15 Badgally Road, Campbelltown
NSW 2560
Date Purchased

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GH104-N and is the answer not in the manual?

Questions and answers

Related Manuals for THOR GH104-N

Summary of Contents for THOR GH104-N

  • Page 1 Thor Gas Char-Broiler Technical Service Manual Model: GH103-P, GH103-N, GH104-P, GH104-N N IMPORTANT FOR FUTURE REFERENCE Please complete this information and retain this manual for the life of the equipment. For Warranty Service and/or parts, this information is required. Model Number...

  • Page 2: Table Of Contents

    Table of Contents Introduction Specification Dimensions Installation 4 ~ 6 Operation 7 ~ 10 Cleaning and Maintenance 11 ~ 12 Troubleshooting 13 ~ 25 Conversion from NG to LPG and vice-versa Explosion Drawing (ALL PARTS) Parts List (ALL PARTS) 27 ~ 28 Explosion Drawing (SPARE PARTS) Spare Parts List...

  • Page 3: Introduction

    Introduction We are confident that you will be delighted with your Thor Gas Char-Broiler, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Gas Char-Broiler, there are two important things you can do.

  • Page 4: Specification

    Specification General A commercial heavy duty gas char-broiler. It uses lava rocks or radiants. Pack Contents The following is included:  Thor Gas Char-broiler  Lava or Radiant  Feet  Instruction Manual Gas Supply Requirements Natural Gas Propane GH103-N...

  • Page 5: Dimensions

    Dimensions GH103-P / GH103-N GH104-P / GH104-N...

  • Page 6: Installation

    Installation Installation Requirements NOTE: • It is most important that this appliance is installed correctly and that operation is correct before use. Installation shall comply with local gas, health and safety requirements. • This appliance shall be installed with sufficient ventilation to prevent the occurrence of unacceptable concentrations of substances harmful to health.
  • Page 7 Installation Clearances NOTE: Only non-combustible materials can be used in close proximity to this appliance. Combustible Surface Non Combustible Surface Left / Right Hand Side 250mm Rear 250mm Assembly NOTE: • This appliance is assembled before delivery except feet. • This appliance is fitted with adjustable feet to enable the appliance to be positioned securely and level. This should be carried out on completion of the gas connection.
  • Page 8 Installation 6. Check that the gas operating pressure. NOTE: The operating pressure is to be measured at the burner operating pressure test point outlet and with one griddle burner operating at the “High Flame” setting. 7. Turn off the mains gas supply and bleed the gas out of the appliance gas lines. 8.

  • Page 9: Operation

    Operation Operation Guide CAUTION: • THIS APPLIANCE IS FOR PROFESSIONAL USE AND IS ONLY TO BE USED BY QUALIFIED PEOPLE. • ONLY QUALIFIED SERVICE PERSONS ARE TO CARRY OUT INSTALLATION, SERVICING OR GAS CONVERSION OPERATIONS. • COMPONENTS HAVING ADJUSTMENTS PROTECTED (E.G. PAINT SEALED) BY THE MANUFACTURER SHOULD NOT BE ADJUSTED BY THE USER/OPERATOR.
  • Page 10 Operation WARNING: SURFACE TEMPERATURE OF THE CHAR-BROILER CAN REACH OVER 300°C WHEN THE APPLIANCE IS OPERATED AT FULL SETTING. 1. Lighting the Main Burners The burners are fitted with individual standing pilots which allows the main burners to be turned ON- OFF without the need to manually re-light the burner each time that it is turned ON, as the burner will be automatically lit itself by the pilot burner.
  • Page 11 Operation Main burner air supply: 1. For efficient burner operation, a proper balance of gas volume and primary air supply must be maintained which will result in complete combustion. Insufficient air supply results in a yellow streaming flame. Primary air supply is controlled by an air shutter on the front of the burner. 2.
  • Page 12 Operation OPERATION: Turn the burners on about 15-20 minutes before cooking for preheating. Set the knobs to the desired flame height or temperature. Each valve will control the gas flow to the burner to bring that area of the unit up to the set temperature. If different temperature settings are to be used, adjoining areas should be set at progressively higher temperatures using the lowest temperatures on the outside burners.

  • Page 13: Cleaning And Maintenance

    Cleaning and Maintenance CAUTION: Always turn off the gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean this appliance. NOTE: Parts protected by the manufacturer or his agent are not to be adjusted by the installer, unless the installer is an authorized service agent.
  • Page 14 Cleaning and Maintenance NOTE: All maintenance operations should only be carried out by a qualified service person. To achieve the best results, cleaning must be regular, thorough and all controls and mechanical parts should be checked and adjusted periodically by a qualified service person. If any small faults occur, have them attended to promptly.

  • Page 15: Trouble Shooting

    Trouble shooting This section provides an easy reference guide to the more common problems that may occur during the operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment.
  • Page 16 Trouble shooting GENERAL INFORMATION BURNING SPEED: The velocity at which flame travels through an air-gas mixture. Burning speeds vary with types of gases, and the amount of air mixed with the gas. This air to gas ratio is very important in that it is directly related to flame stability.
  • Page 17 Trouble shooting BURNER PROBLEMS LIFTING BURNER FLAMES: Excessive primary air can cause flames to lift and blow off the burner ports which can be noisy as well as inefficient. More importantly however is the production of dangerous carbon monoxide under this condition.
  • Page 18 Trouble shooting BURNER PROBLEMS– cont’d. FLOATING FLAMES: The difference between floating flames and lifting (or blowing) flames should be clearly understood. Both conditions are undesirable, but the causes and corrective steps are different. Floating flames are lazy looking. They do not have well defined cones, and appear to be “reaching” for the air. They are long, ill- defined, quite flames which roll around in the combustion chamber sometimes completely off the ports.
  • Page 19 Trouble shooting PILOT TROUBLE SHOOTING Fault Possible Cause Remedy No gas supply or gas isolation Ensure gas isolation valve is turned on, Pilot won’t light. valve is OFF. and that gas tanks are not empty. Pilot burner is clogged/blocked. Check the pilot burner if clogged, and clean, or replace if necessary.
  • Page 20 Trouble Shooting PILOT TROUBLE SHOOTING – cont’d.: COVER ODS INJECTOR REMOVAL: 1. Turn-off the pilot. 2. Shut-off the main isolation valve and follow the lock-out/tag-out procedure. 3. Remove the griddle plate assy. 4. Remove the FDS cover. Use 3mm spanner. 5.
  • Page 21 Trouble Shooting PILOT TROUBLE SHOOTING – cont’d.: THERMOCOUPLE THERMOCOUPLE REMOVAL: 1. Turn-off the pilot. 2. Shut-off the main isolation valve and follow the lock-out /tag-out procedure. 3. Remove the trivets. 4. Remove the burner. 5. Remove the drip tray for ease of access. SAFETY 6.
  • Page 22 Trouble Shooting MAIN BURNER TROUBLE SHOOTING: Fault Possible Cause Remedy No gas supply or gas isolation Ensure gas isolation valve is turned Main burner will not light. valve is OFF. on, and that gas tanks are not empty. Insufficient gas supply pressure. Adjust the gas supply pressure to required standard.
  • Page 23 Trouble Shooting MAIN BURNER TROUBLE SHOOTING: INJECTOR MAIN BURNER INJECTOR REMOVAL: 1. Turn-off the pilot. 2. Shut-off the main isolation valve and follow the lock-out/tag-out procedure. 3. Remove the grills, radiants or lava rocks. 4. Remove the burner. 5. Remove the knob, control panel cover, and piezo Remove the main burner igniter connection.
  • Page 24 Trouble Shooting MAIN BURNER TROUBLE SHOOTING: GAS MANIFOLD ASSEMBLY REMOVAL: 1. Turn-off the pilot. 2. Shut-off the main isolation valve and follow the lock-out/tag-out procedure. 3. Disconnect the manifold from the gas regulator. 4. Remove the drip tray. 5. Remove the knob and open the control panel cover, then disconnect the piezo igniter from the wire.
  • Page 25 Trouble Shooting MAIN BURNER TROUBLE SHOOTING – cont’d.: MAIN BURNER LOW FLAME ADJUSTMENT: ADJUSTMENT 1. Light the main burner that you want to be adjusted. KNOB 2. Set the dial/knob to low flame. 3. Pull-out and remove the knob of the safety gas valve.

  • Page 26: Conversion From Ng To Lpg And Vice-Versa

    Trouble Shooting CONVERTING FROM LPG TO NG AND VICE-VERSA: CONVERTER 1. Turn-off the pilot. COVER 2. Shut-off the main isolation valve and follow the lock-out/tag-out procedure. 3. Remove the gas regulator. 4. Remove the converter cover from the regulator. Use a 22mm spanner. 5.
  • Page 27 Trouble Shooting IMPORTANT!!! Only genuine authorized replacement parts should be used for the servicing and repair of this appliance. The instructions supplied with the parts should be followed when replacing components. For further information and servicing instructions, contact your nearest authorized service branch.

  • Page 28: Explosion Drawing (All Parts)

    Explosion drawing (ALL PARTS) GH103-P / GH103-N...

  • Page 29: Parts List (All Parts) 27

    Parts List (ALL PARTS) DESCRIPTION MODEL CODE GH103-P / GH103-N Dial 01.09.1050334 GH104-P / GH104-N GH103-P / GH103-N 01.05.1028910 Ornament GH104-P / GH104-N 01.05.1028992 GH103-P / GH103-N Thor LOGO 04.07.1340203 GH104-P / GH104-N Safety Valve GH103-P / GH103-N 01.20.1068524 (Accessories)

  • Page 30: Parts List (All Parts)

    Parts List (ALL PARTS) DESCRIPTION MODEL CODE GH103-P / GH103-N FDS buffer 01.05.1028943 GH104-P / GH104-N GH103-P / GH103-N FDS cover 01.05.1028942 GH104-P / GH104-N Flame device system GH103-P / GH103-N 01.22.1069541 (No include injector) GH104-P / GH104-N GH103-P ODS injector-0.20 01.20.1068546...

  • Page 31: Explosion Drawing (Spare Parts)

    Explosion drawing (SPARE PARTS) GH103-P / GH103-N...

  • Page 32: Spare Parts List

    Spare Parts List DESCRIPTION MODEL CODE GH103-P / GH103-N Dial 01.09.1050334 GH104-P / GH104-N GH103-P / GH103-N Thor LOGO 04.07.1340203 GH104-P / GH104-N Safety Valve(A60) GH103-P / GH103-N 01.20.1068524 (Accessories) GH104-P / GH104-N Manifold Assembly GH103-P / GH103-N 01.24.1070857 (Include A60 valve) GH104-P / GH104-N 01.24.1070861...

This manual is also suitable for:

Gh103-nGh104-pGh103-p
