Page 2: Electrical Connections
Welcome Thank you for purchasing the new Portable Air Condition SY-AC900. Read this instruction booklet carefully in order to benefit fully from this product. Store the user manual in a safe place for future reference. Important Safeguards Please read the Manual carefully before operating the machine... - Page 3 capabilities or lack of experience and knowledge do not intend this appliance for use, unless a person responsible for their safety has given them supervision or instruction concerning use of the appliance • The appliance is not intended for use by young children or infirm persons unless they have been adequately supervised by a responsible person to ensure that they can use the unit safely.
- Page 4 • This unit is designed with various protection functions such as 24 hours programmable timer, auto condensation, intelligent temperature sensor and water control with warning. • The ideal temperature for using the portable air conditions is from 15ºC~35ºC. Parts of the SY-AC900...
- Page 5 Handle Air inlet (L) Control panel Wind guide bar Wheels Remote controller Air inlet (R) Air outlet Dehumidification drainage nozzle Air inlet grille Exhaust duct assembly Window sealing plate assembly...
- Page 6 Controls and Settings Power key Press this button to turn On/Off the air conditioner. Auto Swing Key In any mode, press this button to activate the Auto swing function Wind Speed key Press this button to select High, Medium and low wind speed.
- Page 7 Temperature / time display window The LCD display indicates the adjusted temperature and time. Remote controller receiving window Remote sensor to receive signal from the remote controller. ºC-ºF switching key Press this button to switch between ºC and ºF Placement and installation Placement •...
- Page 8 Incorrect installation • It is important to keep the exhaust duct clean and smooth. Incorrect installation will affect the functioning of the A/C. • Prevent bending the exhaust pipe. • Ensure air can flow smoothly in the duct. Warning: The exhaust duct is designed especially for this model. Do not replace or stretch it or it will result in failure.
- Page 9 • As shown on the picture below, remove the plug of the drainage cap, the aqueduct and place the other end of the aqueduct into the water container or drain channel. • When entering dehumidification mode, if the room temperature ≥17 ºC (62 ºF), the compressor will start to work.
- Page 10 Maintenance Note: in order to avoid electric shock, please turn off the A/C and unplug before maintenance or repair. Cleaning the surface Clean the housing with a duster or a soft wet cloth. Do not use any chemical solvent (such as benzene, alcohol, gasoline).
- Page 11 After Season Maintenance 1. Pull out the plug in a drainage hole and empty the water-receiving plate, or drain out the water by leaning the unit. Then enter into the fan mode, and press the button for 5 seconds until it sets to the low fan speed.
- Page 12 TROUBLE CAUSE SOLUTION The A/C doesn’t Not plug in Plug in Restart the A/C after power off and work The display panel indicates drainage process. The unit should work fine. “FL” Time OFF timer function is Restart the unit after turning it off for 3 minutes. activated The refrigeration Direct sunlight...
-
Page 13: Declaration Of Conformity
Tel: 902 430 967 Fax: 91 8864285 NIF: B83254763 Manufacturing country: China Description: Portable Air Condition Sytech® SY-AC900 complies with the following directives: EMC Standard: Directive 2014/30/EU LVD Standard: Directive 2014/35/EU EER Standard: Directive 2009/125/EC ROHS Standard: Directive 2011/65/EU Restriction of Hazardous Substances...
