Retrospec CASCADE Owner's Manual

OWNER'S MANUAL
C A S C A D E - R O O F C A R G O B A S K E T
WARNING:
NEVER EXCEED YOUR VEHICLE MANUFACTURER'S RECOMMENDED TOWING CAPACITY
This roof basket is designed to attach to a wide variety of roof rack bars. Before using the basket, ensure that the universal brackets are securely attached to the vehicle cross bars.
Periodically check to ensure all knobs and screws are tight. Remove the basket when not in use.
DO NOT EXCEED YOUR VEHICLE'S LOAD BARS/CROSS BARS WEIGHT RATING
Fitting: Crossbars up to 4" width x 1.57" maximum height, 0.59 minimum height, or round bars up to 1.5" diameter. U-Bolt spacing: 6.4" x 1.57"
1. Never exceed the maximum cargo load capacity of 150 lbs.
2. There must be a minimum distance of 15 inches between vehicle's cross bars.
3. When loading, distribute weight evenly along basket platform to prevent an out of balance situation.
4. Never carry a load that is not properly secured and tied down to the cargo basket. Improperly secured items may fall onto the roadway and cause an accident.
5. Do not carry flammable items on cargo rack.
6. Never allow people to sit in or be transported in the cargo basket
Improperly installed rack, or cargo can fall onto roadway potentially causing a serious accident resulting in bodily injury.
Do not use cargo roof basket on any vehicle where the cargo basket cannot be properly and safely installed.
TOOLS
x1 x1
5 mm Hex Key Wrench
*NOT INCLUDED*
PARTS
Fairing
x1 x1
Front Basket Rear Basket
x2 x4
Side Plate Bolt
WARNING:
DO NOT EXCEED YOUR VEHICLE'S LOAD BARS/CROSS
BARS WEIGHT RATING
x4
Bracket Top
x4 x4
Washers Nut
x4 x4
Bracket U-Bolt
x8 x8
Knob End Knob
1
