Getting Started with the NI EVS-1464RT
The NI EVS-1464RT is a real-time, fanless embedded vision system designed for rugged industrial
applications. The NI EVS-1464RT features a dual core processor, a solid-state drive, and a variety of
industrial communication connectors. The NI EVS-1464RT includes IEEE 1394b
Vision camera interfaces, and reconfigurable I/O (RIO).
This document describes how to install the NI EVS-1464RT hardware, configure a development
computer, configure an IP address, and acquire an initial image.
Refer to the NI EVS-1464 Series User Manual for device and I/O specifications, mounting requirements,
and answers to common questions about network, firewall, hardware, software, and power issues. To
access the NI EVS-1464 Series User Manual, select Start»All Programs»National Instruments»
Vision»Documentation»NI-IMAQ IO.
What You Need to Get Started
The following components are included in the NI EVS-1464RT kit:
NI EVS-1464RT
DVI splitter cable
Three-position power connector
NI Vision Acquisition Software DVD
Required
Hardware
In addition to the items included in the NI EVS-1464RT kit, the following components are necessary to
set up and configure the NI EVS-1464RT.
One of the following power supply options:
Caution
Use the NI EVS-1464RT only with a 24 VDC, UL listed, limited power source (LPS)
supply. The power supply will bear the UL listed mark, LPS. The power supply must also meet any
safety and compliance requirements for the country of use.
PS-5 Power Supply, 24 VDC, 5 A, Universal Power Input (part number 778805-90)
Any 24 VDC ±10%, 70 W or greater power supply
Development computer running Windows Vista/XP/2000
One or two CAT 5 10/100Base-TX or CAT 5e or CAT 6 1000Base-T Ethernet cables. One Ethernet
cable is required to connect the device directly to the development computer. A second Ethernet
cable is required to connect the device to the development computer through a network.
Note
A CAT 5e or CAT 6 1000Base-T Ethernet cable is required to achieve maximum 1,000 Mbps
(Gigabit) Ethernet performance. CAT 5e and CAT 6 Ethernet cables adhere to higher electrical
standards required for Gigabit Ethernet communication. CAT 5 cables are not guaranteed to meet the
necessary electrical requirements. While CAT 5 cables may appear to work at 1,000 Mbps in some
1
To connect an IEEE 1394a camera to the NI EVS-1464RT, you will need a 6-pin to 9-pin cable or a 6-pin to 9-pin adapter.
1
bilingual and GigE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NI EVS-1464RT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for National Instruments NI EVS-1464RT

  • Page 1 While CAT 5 cables may appear to work at 1,000 Mbps in some To connect an IEEE 1394a camera to the NI EVS-1464RT, you will need a 6-pin to 9-pin cable or a 6-pin to 9-pin adapter.
  • Page 2: Required Software

    You must have all covers and filler panels installed during operation of the hardware. To connect an IEEE 1394a camera to the NI EVS-1464RT, you will need a 6-pin to 9-pin cable or a 6-pin to 9-pin adapter. When using this accessory with the NI EVS-1464RT, three of the digital I/O signals on the device are not accessible. Refer to the General-Purpose Digital I/O section of Chapter 2, LED Indicators, DIP Switches, and Connectors, in the NI EVS-1464 Series User Manual for more information.
  • Page 3 Working voltage is the highest rms value of an AC or DC voltage that can occur across any particular insulation. MAINS is defined as a hazardous live electrical supply system that powers hardware. Suitably rated measuring circuits may be connected to the MAINS for measuring purposes. © National Instruments Corporation Getting Started with the NI EVS-1464RT...
  • Page 4: Electromagnetic Compatibility Information

    Operation of this hardware in a residential area is likely to cause harmful interference. Users are required to correct the interference at their own expense or cease operation of the hardware. Changes or modifications not expressly approved by National Instruments could void the user’s right to operate the hardware under the local regulatory rules.
  • Page 5: Unpack And Verify Components

    Unpack and Verify Components Remove the NI EVS-1464RT from the package and inspect the system for any sign of damage. Notify National Instruments if the system appears damaged in any way. Do not use a damaged system.
  • Page 6: Connecting A Camera

    Connect the 3-position power connector to the power supply connector on the NI EVS-1464RT. Plug the power supply cord into an outlet. The power LED will illuminate and the NI EVS-1464RT will boot when the power supply is properly connected.
  • Page 7 If necessary, connect the power cord to the power supply. Plug the power supply cord into an outlet. The orange ISO LED on the NI EVS-1464RT front panel will illuminate when the computer is on and an isolated power supply is properly connected.
  • Page 8: Installing Ni Vision Acquisition Software

    Installing NI Vision Acquisition Software The latest version of NI Vision Acquisition software is included with the NI EVS-1464RT. NI Vision Acquisition Software includes driver software and MAX—the National Instruments configuration utility—which you can use to configure the NI EVS-1464RT.
  • Page 9 If you want to deploy the NI EVS-1464RT on a different subnet, first connect and configure the NI EVS-1464RT on the same subnet as the host computer. If you want to assign a static IP address for a different subnet, do so while the NI EVS-1464RT is connected to the development computer. After installing software on the NI EVS-1464RT physically move the NI EVS-1464RT to the correct subnet.
  • Page 10 You must connect the NI EVS-1464RT to the network before the NI EVS-1464RT boots. The NI EVS-1464RT does not have an on or off switch, and boots when power is supplied to it. The NI EVS-1464RT is now connected to the development computer through a network.
  • Page 11: Configure The Ip Address

    In the Select Remote Target dialog box, select the NI EVS-1464RT with a MAC address that corresponds to the MAC address on the bottom label of the NI EVS-1464RT you want to configure. Refer to Appendix D, Common Questions, of the NI EVS-1464 Series User Manual to troubleshoot network configuration issues.
  • Page 12 , the NI EVS-1464RT is only accessible from 169.254.x.x 0.0.0.0 the local subnet. To access the NI EVS-1464RT from a remote subnet, configure the device to obtain an IP address from a DHCP server or manually assign a static IP address. •...
  • Page 13 , the NI EVS-1464RT is only accessible from 169.254.x.x 0.0.0.0 the local subnet. To access the NI EVS-1464RT from a remote subnet, configure the device to obtain an IP address from a DHCP server or manually assign a static IP address. •...
  • Page 14 Complete the following instructions to manually configure the secondary Ethernet connector: In the Remote Systems branch of the MAX configuration tree, select the NI EVS-1464RT. Select the Network Settings tab. Click Advanced Ethernet Settings to open the Advanced Ethernet Settings dialog box.
  • Page 15: Specifications

    Deploying Multiple NI EVS-1464RT Devices As with all Ethernet devices, you can connect multiple NI EVS-1464RT devices to the same network. This feature allows remote configuration, programming, and monitoring of any NI EVS-1464RT device not protected by a firewall or user password.
  • Page 16: Electromagnetic Compatibility

    Certification column. Environmental Management National Instruments is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial not only to the environment but also to NI customers.
  • Page 17: Where To Go From Here

    Battery Directive This device contains a long-life coin cell battery. If you need to replace it, use the Return Material Authorization (RMA) process or contact an authorized National Instruments service Cd/Hg/Pb representative. For more information about compliance with the EU Battery Directive 2006/66/EC about Batteries and Accumulators and Waste Batteries and Accumulators, visit ni.com/...
  • Page 18: Where To Go For Support

    National Instruments corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. National Instruments also has offices located around the world to help address your support needs. For telephone support in the United States, create your service request at ni.com/...
  • Page 19 National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your...
