- Page 1 LED MYSTIC...
- Page 2 INTRODUCTION Thank you for having chosen the item. You will see you have acquired a powerful and versatile device. Unpack your product. Before you initial start-up, please make sure that there is no damage caused by transportation. Should there be any, consult your dealer and do not use the device.
- Page 3 DMX-512 connection / connection between fixtures The wires must not come into contact with each other, otherwise Occupation of the XLR-connection: If you are using controllers with this occupation, you can connect the DMX-output of the controller directly with the DMX-input of the first fixture in the DMX-chain. If you wish to connect DMX-controllers with other XLR-outputs, you need to use adapter-cables.
- Page 4 second, 2 ON, third 1,2 ON, fourth 3, fifth 1,3 ON,… Five DMX channels: Channel 1: red from 0-100% dimming Channel 2: green from 0-100% dimming Channel 3: blue from 0-100% dimming Channel 4: flash 0-10: on/off 11-255 0-23 flashes per second Channel 5: motor speeds 0-111 motor clockwise rotation...
- Page 5 11,12 to ON, others to OFF: seven multi color patterns changing in the order of red, green, blue, red+green, green+blue, red+blue, red+green+blue automatically; the motor rotation directions change accordingly with the multi color patterns following; 10,11,12 to ON, others to OFF: firstly seven multi color patterns changing and flashing fast in the order of red, green, blue, red+green, green+blue, red+blue, red+green+blue automatically;...
