Samsung CF21G Series Service Manual page 43

7 Electrical Parts List
Loc. No. Code No.
JP843 BH39-40305U
L400 2701-000179
L501 2701-000179
L502 BH39-40305U
MP1.2 BH41-00219A
Q250 0501-000586
Q251 0501-000303
Q252 0501-000586
Q301 0501-000586
Q408 0501-000586
Q409 0501-000586
Q410 0501-000586
Q411 0501-000586
Q412 0501-000586
Q413 0501-000586
Q450 0501-000303
Q451 0501-000586
Q452 0501-000586
Q453 0501-000303
Q502 0501-000122
Q503 0501-000581
Q520 0501-000143
Q521 0501-000122
Q522 0501-000586
Q540 0501-000413
Q553 0501-000361
Q601 0501-000010
Q620 0501-000586
Q670 0501-002228
Q671 0501-000586
Q672 0501-002228
R200 2001-000591
R203 2001-000429
R204 2001-000281
R205 2001-000281
R206 2001-000739
R207 2001-000869
R208 2001-000869
R209 2001-000591
R210 2001-000281
R211 2001-000591
R215 2001-000577
R216 2001-000734
R218 2001-000786
R220 2001-000734
R221 2001-000290
R222 2001-000613
R225 2001-000435
R226 2001-000281
R227 2001-000281
R228 2001-000490
R229 2001-000429
R230 2001-000490
R231 2001-000429
R232 2001-000281
R233 2001-000734
R236 2001-000281
R237 2001-000281
R238 2001-000977
R239 2001-000281
7-10
Description
CBF HARNESS
INDUCTOR-AXIAL
INDUCTOR-AXIAL
CBF HARNESS
PCB MAIN
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
TR-SMALL SIGNAL
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
R-CARBON
Specification
52MM,AWG22(0.6PI),-,-,AWG22(0.
33uH,10%,4.2x9.8mm
33uH,10%,4.2x9.8mm
52MM,AWG22(0.6PI),-,-,AWG22(0.
CF21GS_MAIN,FR1,1,1.6T,247*330,1,21 MAIN
KSC945,NPN,250mW,TO-92,TP,120-240
KSA733,PNP,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSA733,PNP,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KSA733,PNP,250mW,TO-92,TP,120-240
2N3904,NPN,625mW,TO-92,TP,100-300
2N3906,PNP,625mW,TO-92,TP,100-300
2N6520,PNP,625mW,TO-92,TP,30-200
2N3904,NPN,625mW,TO-92,TP,100-300
KSC945,NPN,250mW,TO-92,TP,120-240
KSP44,NPN,625mW,TO-92,TP,50-200
KSC2316-Y,NPN,900mW,TO-92L,TP,120-240
KSC1008,NPN,800mW,TO-92,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KTA1281,PNP,1000mW,TO-92L,TP,120-240
KSC945,NPN,250mW,TO-92,TP,120-240
KTA1281,PNP,1000mW,TO-92L,TP,120-240
3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
4.7MOHM,5%,1/8W,AA,TP,1.8X3.2MM
56OHM,5%,1/8W,AA,TP,1.8X3.2MM
56OHM,5%,1/8W,AA,TP,1.8X3.2MM
3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
3.3KOHM,5%,1/8W,AA,TP,1.8X3.2MM
2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
47KOHM,5%,1/8W,AA,TP,1.8X3.2MM
4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
10KOHM,5%,1/8W,AA,TP,1.8X3.2MM
3.9KOHM,5%,1/8W,AA,TP,1.8X3.2MM
1MOHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
200OHM,5%,1/8W,AA,TP,1.8X3.2MM
1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
200OHM,5%,1/8W,AA,TP,1.8X3.2MM
1KOHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
4.7KOHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
8.2KOHM,5%,1/8W,AA,TP,1.8X3.2MM
100OHM,5%,1/8W,AA,TP,1.8X3.2MM
CONFIDENTIAL
Remarks
SA
SA
SA
SA
SNA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
SA
CF21G*
