1. VCC2 adjustment, VCC9, VCC8, VCC7, VCC5, VEE1, VDD, VCC1-2 voltage check
2. Free running frequency adjustment
3. Bright, contrast adjustment for 1 chip
4. COLOR adjustment
5. Bright, Contrast adjustment
6. Current consumption check
Preparations
1. Adjust the above items 1 through 5 with the dummy load.
Adjustment And Test Point Locations
VR502
VR700
VR101
Top View

ADJUSTMENT

VR511
VR303
VR301
P303
P304
P307
P300
— 4 —
P510
P181
P704
P703
P702
P171
P131
P152
P154
P151
P155
P105
Bottom View
P141
