BOSTONIAN SHOWER SYSTEM
INSTALLATION INSTRUCTIONS
Before installing, read entire Bostonian Shower System Installation Instructions. Observe all local building and safety
codes.
For the following installation instructions it is assumed that the water supply lines have been installed in the desired
Service at 1-866-855-2284. If you need assistance or have questions while installing your shower, contact Customer
Service.

TOOLS AND MATERIALS:

Silicone Sealant
INSTALLATION
1. Place thread sealant, or
NOTE: If your pipe nipple is already attached, please proceed directly to step 3.
2. Unthread to remove the water supply tee from the shower riser pipe. This can be found at the top of the riser pipe,
where the pipe pivots slightly
3.
wall.
4. Reattach the riser pipe to the supply tee. Do not fully tighten the connecting nut.
5. Remove the back from the piece of double-sided tape on the back of the handle tee.
6. Hold the shower out slightly from the wall. Use a level to verify that the riser pipe is completely straight.
7. When the riser is aligned properly, gently press the handle tee into the wall.
8. With the included Allen wrench, remove the small set screw from the underside of the handle tee. This will release
the mounting bracket that is being held in place by the double-sided tape.
9.
10. Push the riser pipe aside and attach the bracket to the wall with the appropriate mounting hardware.
11. Place the decorative escutcheon on the handle tee and gently put the riser pipe back in place over the mounting
bracket. Reinsert the set screw to secure.
Level
.
Thread Sealant or
