  • Page 1 Installer Guide Hardware and software for LGE Ace...
  • Page 2 AC Module Installation Guide Diagram of AC Module system Transition Cable PV Rack AC Module Trunk Cable AC Junction Box General AC Cable Meter Communication Gateway 120VAC Distribution Panel -. A minimum slope of 5 in/ft. for roof installations is required to meet fire class ratings. -.
  • Page 3 AC Module Installation Guide Specification of AC Module...
  • Page 4 AC Module Installation Guide Specification of AC Module...
  • Page 5 AC Module Installation Guide Specification of AC Module...
  • Page 6 AC Module Installation Guide Specification of AC Module Drop cable Trunk cable PV module Trunk female connector Micro inverter Bracket PV frame Dust cover AC drop connector Cable holder 1)* Trunk male connector 1)* Prevents AC trunk cables from moving during transportation. ※...
  • Page 7 AC Module Installation Guide Specification of AC Module Items Div. Extension (Portrait) Male – Male, 63 inch [1.6m] Extension (Portrait) Female-Female, 63 inch [1.6m] Extension (Landscape) Cable Male-Female, 126 inch [3.2m] Transition (Male) 39 *, 59 inch [1m]* [1.5m] Transition (Female) 39 *, 59 inch [1m]* [1.5m] End Cap (Male) End Cap (Female)
  • Page 8 AC Module Installation Guide Specification of EnerBox...
  • Page 9 AC Module Installation Guide The connection method of Enerbox...
  • Page 10 AC Module Installation Guide Mount the AC module on the rack 300mm Connection of the PV Rack and PV Module (11.81 in.) Module frame Bolt Flat washer Flat washer Spring washer Support 300mm (11.81 in.)
  • Page 11 ** To prevent the danger of the electric AC Module Installation Guide shock, firmly connect all connectors and Endcaps. Connect the AC module cable - Maximum connection of AC modules at the different voltage condition Capacity Circuit Breaker AC voltage Number of maximum AC modules [per circuit] [20A]...
  • Page 12 AC Module Installation Guide Material lists for AC module connection. Landscape 2 Rows 5.4kW Portrait 3 Rows 5.4kW Portrait 2 Rows 5.4kW * It is only guide to assist for your information.
  • Page 13 AC Module Installation Guide Case I – Portrait 2 Rows 5.4kW, Position of AC Junction box is left side of Array AC Set 1 AC 240V Single Phase Male Transition Cable Female + Female AC Set 2 Extension cable AC Junction Box Female Male Material...
  • Page 14 AC Module Installation Guide Case I – Portrait 2 Rows 5.4kW, Position of AC Junction box is left side of Array AC Set 1 AC Set 2 AC 208V Three Phase Female Male Male Transition Transition Cable Cable Female + Female AC Set 3 AC Set 3 Extension cable...
  • Page 15 AC Module Installation Guide Case II– Portrait 3Rows 5.4kW, Position of AC Junction box is left side of Array AC Set 1 AC 240V Single Phase Male Transition Cable Female + Female Male Extension cable AC Junction Box AC Set 2 Female Material Model...
  • Page 16 AC Module Installation Guide Case II– Portrait 3Rows 5.4kW, Position of AC Junction box is left side of Array AC Set 1 Female AC 208V Three Phase Male Transition Cable AC Set 2 Female AC Junction Box Male Transition Cable AC Set 3 Female Material...
  • Page 17 AC Module Installation Guide Case III– Landscape 2Rows 5.4kW, Position of AC Junction box is left side of Array AC Set 1 AC 240V Single Phase Male Female + Male Female + Male Female + Male Female + Male extension cable extension cable extension cable extension cable...
  • Page 18 AC Module Installation Guide Case III– Landscape 2Rows 5.4kW, Position of AC Junction box is left side of Array AC Set 1 AC Set 2 AC 208V Three Phase Male Female + Male Female + Male Female + Male Transition extension cable extension cable extension cable...
  • Page 19 AC Module Installation Guide APP and Web setting...
  • Page 20 Normal procedure for 1 phase 240V [Flow chart] Installation Complete On Roof Circuit breaker reset For AC module Plug in Gateway APP Running Installer Mode [Optional] MAC address list Grid configuration End customer sign up AC module status Installer Add a system System configuration...
  • Page 21 *Take out bar code sticker of Gateway to register in monitoring system. J. Sign In Enervu webpage for monitoring Gateway: http://enervu.lg-solar.com/ *Register bar code stickers of AC module and Gateway.  Procedure from B to F will be completed within 15 minutes, if not, the AC module will be sleep mode.
  • Page 22 Abnormal procedure for 1 phase 240V In case Gateway doesn‟t not detect installed AC module. A. Plug in the Gateway to nearest outlet to circuit breaker with PLC bridge. Nevertheless, If Gateway does not detect installed AC module, It will be require to install the dedicated outlet between the gateway and AC module. B.
  • Page 23 Job Site Works Prepare to Setting of APP and Web for 1 phase 240V ① Installation Completion AC Module ② Take out bar code sticker * Information to find faulty AC module. Require to Take out bar code sticker of all installed AC Module •Prior to switch on, installed AC module system is need to approve and inspect by Authorized person.
  • Page 24 Prepare to Setting of APP and Web for 1 phase 240V Job Site Works ⑧ Installer Mode Press Title Bar 2~3 seconds Go to No. ⑩ “MAC address List” ⑩ Enter MAC address List *2) Reset of Circuit Breaker for AC Module Display *1) 15Minutes all installed...
  • Page 25 After you clear Error message , wait Max.15 minutes ⑫Enter AC Module status again due to update period. •Download route All displayed If you find other color of displayed www.lg-solar.com AC module AC module except black color, you http://enervu.lg- color is Black ? need to follow Installation Manual solar.com/support/downloads...
  • Page 26 If end user want to Hawaii region use web server, Go to step No. ⑭ •Download route Select the type If AC module under faulty condition, www.lg-solar.com of system you have to clear Error message http://enervu.lg- voltage according to Installation Manual solar.com/support/downloads...
  • Page 27 Prepare to Setting of APP and Web for 1 phase 240V Job Site Works • It is mandatory whole process to connect web server ⑭ System configuration •Take out bar code sticker of Gateway to register in monitoring system. (The positions of bar code are on bottom and outer box of Gateway.) Click Time Synchronization to sync the time zone of the gateway and web server.
  • Page 28 Prepare to Setting of APP and Web for 1 phase 240V Office Works Sign up Enervu webpage for monitoring Gateway: http://enervu.lg-solar.com/ • To register of installed AC module system for End–customer, Installer will require to input Gateway bar code(serial No.) on web server.
  • Page 29 Setting step detail STEP #1. Connecting the EnerBox STEP #2. Entering the Installer Mode STEP #3. Scanning the AC Modules & Registration Setting STEP #4. Checking the AC Module Status STEP #5. Grid Configuration [Option] STEP #6. System Configuration STEP #7. EnerVu (Web) Configuration Setting Appendix #1- Replacement procedure of malfunction Gateway...
  • Page 30 Connecting the Gateway [Enerbox] App Download route Turn on Wi-Fi in Smart Phone Android: Play store Select the SSID[WiFi name] of Gateway [Enerbox] - “LGE_EnerBox” IOS:APP store Input the password – “87654321” * Search Name: Enervu LGE_EnerBox LGE_EnerBox...
  • Page 31 Entering the Installer Mode Press the title bar for 2~3 seconds to enter installer mode. Press for 2~3 sec.
  • Page 32 Do not REGISTER Shows the detected AC Modules. MAC Address EnerBox Only For adding or replacing the of AC Modules, EnerBox Group change Only for LG Electronics supervisor Import Only for LG Electronics supervisor Export Only for LG Electronics supervisor...
  • Page 33 AC Module Status Enter into AC Module Status just to check operating status of the AC Module.  Normal or abnormal condition AC module status In APP *Information on AC module through Gateway will be updated by every 15 minutes regardless normal or abnormal. If you find abnormal AC module in APP, you have to clear error message and wait Max.15 minutes again.
  • Page 34 Grid Configuration [Option] *Only for 3 phase 208V. Enter into Grid Configuration and set the grid configuration to suit your environment. If the grid configuration is wrong, AC module may not operate correctly. Press the Set button. It takes about 5 seconds per module for setting. Press the Update button and check that the selected grid setting is correct.
  • Page 35 System Configuration – Gateway setting & Web server activation Necessary procedure for Web server *Take out bar code sticker of Gateway to register in monitoring system. It is mandatory to connect web server. Click Time Synchronization to sync the time zone of the gateway and web server.
  • Page 36 EnerVu (Web) Configuration http://enervu.lg-solar.com/...
  • Page 37 *Appendix 1- Replacement procedure of malfunction Gateway...
  • Page 38 *Appendix 2- Replacement procedure of malfunction AC module...
  • Page 39 * Appendix 3. PLC (Powerline Communication) Issues...
