Summary of Contents for Reinecker VEO
- Page 1 User manual...
- Page 3 Reinecker Vision GmbH Sandwiesenstraße 19 · 64665 Alsbach-Hähnlein Email: info@reineckervision.de · www.reineckervision.de Wir erklären in alleiniger Verantwortung für alle unsere Systeme, dass diese mit den folgenden Normen oder normativen Dokumenten übereinstimmen. VEO VOX ( VEOVOT24 ) Richtlinie 93/42/EWG des Rates vom 14. Juni 1993 über Medizinprodukte Risikoklasse I nach Anhang IX Regel 12 CE Konformität nach Anhang VII...
-
Page 4: Table Of Contents
II. Instructions for the reading system VEO . . . . . . . . . . . . . . . . . - Page 5 Overview mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21 Automatic switch-OFF function .
-
Page 6: General Information
I. General information Important notes on the operation of the reading system VEO! Please read them carefully prior to the operation of the reading system! Notes on the electromagnetic compatibility (EMC) This reading system is suited for use in all set-ups including the domicile that are connected directly to a public power supply for buildings with residential purposes . -
Page 7: Product Description
. Note: The mentioned life span does not reflect the complete life span of the VEO . It is rather an indication on when the product might be obsolete and substitution might be recommended due to new product developments . -
Page 8: Safety Advice
Safety advice VEO has to be installed in closed and dry rooms only . Do not plug VEO into an electrical circuit that is also being used for any life sustaining or support systems . The device may not be used in the patients environment . -
Page 9: Cleaning Of The System
Temperature range +5°C to + 50°C Relative air humidity 30% to 80% Disposal of the unit according to EU directive 2002/96/EEC VEO contains of electronic components . To avoid damage to the environ- ment, the country-specific rules have to be respected . Power supply Only use the original power supply which is included in the delivery by Reinecker Vision GmbH . -
Page 10: Safety Instructions
Do not touch the AC adapter with wet hands . Only use the original power supply which is included in the delivery by Reinecker Vision GmbH . The use of any other equipment might lead to a product damage . -
Page 11: Ii. Instructions For The Reading System Veo
II. Instructions for the reading system VEO Delivery content Reading system VEO LED-monitor 22"/24" 3-buttons remote control Power adapter 12V DC / 5000mA Adapter cable (country-specific) User manual Information sheet for repair cases Vario camera Magnification from 1x to 100x (independent of monitor size) -
Page 12: Insert / Replace Batteries In Remote Control
Installation of the system Your VEO system will normally be unpacked and set up by the supplier’s representative . If you have not purchased a VEO stand that fits to the product you must provide a solid surface for the system with sufficient surface area . -
Page 13: Connection Of Unit
Note: The delivered power cable is to be used exclusively in connection with the VEO . Once the device is plugged in, it is ready to use HDMI ports power outlet (only at VEO without monitor and VEO SWITCH) power input power cable... -
Page 14: Switch Function (Only At Veo Without Monitor And Veo Switch)
Note: Before accessing to a second image source, first the VEO and then the second image source is turned on . Changing with the remote control Pressing short: Changing the image source Pressing long:... -
Page 15: Alignment Of Monitor
Alignment of monitor Due to the monitor’s technology contrast and brightness change depend- ing on the angle of view . The highly flexible four-dimensional monitor arm enables the user to adjust the monitors height and angle according to their seated position (see below) . -
Page 16: Alignment Of Xy-Table
Alignment of xy-table The xy-table has two independent friction brakes for the x- and y-axis . The friction can be continuously adjusted from minimum to maximum . The yellow friction brake is used for the x-axis and the black brake for the y-axis . -
Page 17: Positioning Of The Remote Control Unit
Positioning of the remote control unit The remote control unit may be attached to the VEO reading system on the right side of the xy-table or underneath the monitor . In addition the remote control may also be hold in the user’s hand or e .g . placed on the table . -
Page 18: Description Of The 3-Buttons Remote Control
Description of the 3-buttons remote control Frontal view: Colour mode Power ON/OFF, Contrast / brightness, selection zoom +/ -, auto line marker / shadow- focus* Left button: • Color mode selection By turning the color mode selection-button from the left to the right the following color modes can be selected: Position 1 . full color display Position 2 . black font, white background... - Page 19 Central („zoom“) button: • Power ON/OFF By briefly pressing the “Zoom +/-” button, the video magnifier turns ON . By pressing and holding the „Zoom +/-“ button for approx . 4 sec ., the video magnifier can be turned OFF manually .
-
Page 20: Turning The Unit On Manually
. Turning the unit ON manually When the VEO is connected to the power outlet correctly it can be turned on by pushing the central („Zoom + / -“) button . When the unit powers up lights will initially illuminate and after short time automatically return to the last used brightness level . -
Page 21: Overview Mode
OFF deactivated automatic turn OFF after 15 min . automatic turn OFF after 30 min . automatic turn OFF after 60 min . Note: Once turned OFF the energy consumption of the VEO is less than 0,5 watt . -
Page 22: Menu Selection
Menu selection Keep the black button (underneath the remote control) pressed for approxi- mately 3 seconds until the main menu appears on the screen . Main Menu Brightness Contrast Color Saturation - 30 Ruler / Mask Ruler / Mask Settings AF Mode* Continuous/Zoom Reset to Factory Settings... -
Page 23: Explanation Of The Menu Content
Explanation of the menu content The image shows in detail how the menu is structured . Main Menu Menu level 1 Advanced Settings Menu level 2 Special Settings Menu level 3 Customize Buttons Menu level 4 Function adjustment range | explication Menu settings... - Page 24 Main Menu Ruler / Mask Settings Ruler Color adjustment range from 0 to 31 Green adjustment range from 0 to 31 Blue adjustment range from 0 to 31 Main Menu AF Mode Continuous | Semi-Automatic | Semi-Autom. +Zoom | Continuous / Zoom Reset to Factory Settings Return to factory settings Recall User Settings...
- Page 25 Main Menu Advanced Settings Color Combination Setup User colors User color 1 - Red adjustment range from 0 to 31 User color 1 - Green adjustment range from 0 to 31 User color 1 - Blue adjustment range from 0 to 31 User color 2 - Red adjustment range from 0 to 31 User color 2 - Green...
- Page 26 Overview: Special Settings Zoom Extension Max. Digital Zoom 3.5x Customize Buttons Store User Settings Recall User Settings Reset to Factory Settings Expert Settings Monitor size Auto Return Main Menu Advanced Settings Special Settings Zoom Extension ON | OFF Max. Digital Zoom OFF | adjustment range from 1,5x to 15x Main Menu Advanced Settings...
-
Page 27: Warranty Information
Warranty Information 1 . Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manu- facture counted from date of invoice ex Reinecker Vision GmbH . 2 . All parts that have been replaced when repairing the unit will automati- cally become property of Reinecker Vision GmbH . -
Page 28: Notes
Notes... - Page 31 Type: Serial number: Manufacturer: Reinecker Vision GmbH Final examination: Power supply: 100 - 240 VAC 50/60 Hz via plug-in power supply: 12V DC / 5000mA Power consumption: max . 80 Watt Measurements (W x H x L): approx . 51 x 60,5 x 56 cm (measured with 22"...
- Page 32 Reinecker Vision GmbH In case service is International Contact necessary, please contact your autho- sales department, customer relations: rized distributor . Sandwiesenstraße 19 DE-64665 Alsbach- Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel .: +49 6257 9311- 0 Fax: +49 6257 9311- 8230 E-Mail: international@reineckervision .de...
