Summary of Contents for Reinecker Videomatic
- Page 1 User manual Videomatic Please read this user manual carefully prior to installation, use and maintenance for your own safety and in order to avoid damages on your system.
- Page 3 RoHS II (Council directive 2011/65/EEC) Die CE– Kennzeichnung auf dem Gerät dokumentiert diese Übereinstimmung. The CE mark on the system points out this accordance. M. Reinecker Geschäftsführer Alsbach-Hähnlein, M. Reinecker General Manager 24.09.2018 ....................Ort und Datum der Ausstellung...
-
Page 4: Table Of Contents
Special advice for transport and storage ..............8 Disposal of the unit according to EU directive 2002/96/EEC ........8 Power supply .......................8 Safety instructions to avoid damage ................9 II. Instructions for the reading system Videomatic ............10 Delivery content ......................10 Camera ........................10 FullHD camera with optical zoom/auto-focus ............10 Installation of the system ...................10... - Page 5 Line marker / Shadowing ..................14 Description of the Videomatic menu .................15 Menu selection ....................15 Navigate upwards the menu ................15 Explanation of the menu content................16 Menu settings .....................16 Troubleshooting ......................18 Technical details ......................18 Warranty Information ....................19 Notes .........................20...
-
Page 6: General Information
Product description Videomatic is a compact desktop video magnifier system, which magnifies text and pictures. It may be used permanently for private and professional appliance. The text or pictures are being captured by the integrated camera and then displayed on the monitor. -
Page 7: Medical Device
Safety advice Videomatic has to be installed in closed and dry rooms only. Do not plug Videomatic into an electrical circuit that is also being used for any life sustaining or support systems. -
Page 8: Precautions By Alteration Of The Performance Of The System
Stop using the reading device if technical features or performances should change. Switch the device OFF and disconnect the power supply from the mains wall socket. Refer directly to your authorized dealer or to Reinecker Vision GmbH Service Center. Do not use the system again in this condition. -
Page 9: Safety Instructions To Avoid Damage
2. Do not touch the AC adapter with wet hands. 3. Only use the original power supply and cables which are included in the delivery by Reinecker Vision GmbH. The use of any other equipment might lead to a product damage. -
Page 10: Instructions For The Reading System Videomatic
- Technology: high quality pictures with virtually no picture noise Installation of the system Unpack your Videomatic carefully and place it on a solid horizontal surface. If you have not purchased an optionally available stand that fits to the product you must provide a solid surface for the system with sufficient surface area. -
Page 11: Connection Of Unit
Connection of the unit Connect the power supply to a main wall socket and plug the adapter end of the cord into the DC12V power supply socket located on the base of the system. Note: The included power cable is to be used exclusively with connection with the system. Do NOT use any other power cable. -
Page 12: How To Start The Reading System
Replacement of lighting The electronic magnifier is equipped with a high power LED Illumination. If replace- ment of the lamp is required it should only be done by a specialist or by Reinecker Vision GmbH. Important note to the use of power supply Please only use the power supply included in the delivery. -
Page 13: Functional Description Of The Control Panel
Functional description of the control panel Frontal view: Color mode selection, Brightness (10 levels), overview mode, exit menu Line marker / Shadowing Zoom - Zoom + Open internal menu Control keys Color mode selection By pressing the round control button briefly, the following screen colors can be chosen: Position 1. -
Page 14: Zoom
Zoom - By briefly pressing the arrow control button pointing to the left magnification will be reduced step by step. By continuously pressing the arrow control button pointing to the left magnification will be continuously reduced. Zoom + By briefly pressing the arrow control button pointing to the right magnification will be increased step by step. -
Page 15: Description Of The Videomatic Menu
Description of the menu Menu selection Please press the two arrow control buttons simultaneously for approx. 2 seconds until the main menu appears on the screen. Main Menu Colour Saturation Language English AF Mode auto. Min. magnification standard Max. magnification standard Grid Frequency 50Hz... -
Page 16: Explanation Of The Menu Content
Explanation of the menu content The image shows in detail how the menu is structured. Main Menu Menu level 1 Advanced Settings Menu level 2 Colour Combination Setup Menu level 3 User colours Menu level 4 Function adjustment range | explication Menu settings... - Page 17 Main Menu Advanced Settings Colour Combination Setup Colour Combination 1-6 Disabled | Full Colour | Grayscale | False Co- Mode lour Foreground Black | Red | Green | Blue | Yellow | Magenta | Cyan | White | User 1 | User 2 Background Black | Red | Green | Blue | Yellow | Magenta | Cyan | White | User 1 | User 2...
-
Page 18: Troubleshooting
True colour is not dis- Check your reading material, colour mode setting, played correctly. brightness, colour saturation and camera lighting. Technical details Videomatic LED flat screen monitor Weight: approx. 12,2 kg 19"- class 19" class | approx. 48 cm Measurements (W x H x L) -
Page 19: Warranty Information
Warranty Information 1. Reinecker Vision GmbH grants a warranty of 24 months (warranty period only valid within the European Union) against defects in manufacture counted from date of invoice ex Reinecker Vision GmbH. 2. All parts that have been replaced when repairing the unit will automatically become property of Reinecker Vision GmbH. -
Page 20: Notes
Notes... - Page 23 Videomatic ( VIDEOMA1 ) Type: Serial number: Manufacturer: Reinecker Vision GmbH Final examination: Power supply: 100 VAC – 240 VAC 50-60 Hz With plug-in power supply: 12V DC / 5000mA Power consumption: max. 80 Watt...
- Page 24 Reinecker Vision GmbH In case service is necessary, please International Contact contact your authorized distributor. sales department, customer relations: Sandwiesenstraße 19 DE-64665 Alsbach-Hähnlein customer service: Erlenweg 3 DE-64665 Alsbach-Hähnlein Tel.: +49 6257 9311- 0 Fax: +49 6257 9311- 8230 Email: international@reineckervision.de www.reineckervision.com...
