Mircom RB-MD-950 Replacement Instructions

In no event shall Mircom be liable for any direct, indirect or
consequential damages, loss of anticipated profits, loss of time or
any other losses incurred by the buyer in connection with the
purchase, installation or operation or failure of this product.
Important:
Mircom recommends that the entire system be completely tested
on a regular basis. However, despite frequent testing, and due to
but not limited to criminal tampering or electrical disruption, it is
possible for this product to fail to perform as expected.
LT-1095 Rev.0
Canada - Main Office USA
25 Interchange Way 4575 Witmer Industrial Estates
Vaughan, ON, L4K 5W3 Niagara Falls, NY 14305
Tel: (888) 660-4655 Tel: (888) 660-4655
(905) 660-4655 (905) 660-4655
Fax: (905) 660-4113 Fax: (905) 660-4113
May 2011
TECHNICAL SUPPORT
North America
Tel: (888) Mircom5
(888) 647-2665
International
Tel: (905) 647-2665
RB-MD-950 Replacement Instructions
Parts List
• 1 x RB-MD-950 Replacement Main Board Chassis Assembly
• 4 x #6-32 Hex Nut Lockwashers
Installing the RB-MD-950 Replacement Main Board Chassis
Assembly
1. Power down the INX-10A
2. Disconnect the power leads from the bottom of the main board.
3. Unplug any wired terminal blocks from the top of the main
board.
4. Remove the 4, #6-32 Hex Nut Lockwashers securing the MD-
950 to the enclosure from the locations shown in Figure 1 and
Figure 2.
5. Remove the damaged Main Board Chassis Assembly from the
enclosure.
6. Secure the RB-MD-950 Replacement Main Board Chassis
Assembly to the enclosure with 4, #6-32 Hex Nut Lockwashers.
7. Replace the terminal blocks on the RB-MD-950 with the
existing wired terminal blocks as required.
8. Reconnect the power leads.
RB-MD-950 Replacement Instructions
