Mircom MIX-100R Installation Instructions

Note
1. All circuits are power limited except for relay contacts. If the relay contacts are
connected to a non power limited source, remove the lower portion of the power
limited label along the kiss cut. Use only limited energy cable types FPL, FPLR or FPLP
on power limited circuits.

Technical Data

Part No
Compatability Identifi er
Type
Style
Dimensions
Temperature Range
Humidity
Signal Line Circuit (SLC)
Working Voltage
Modulation Voltage (peak to peak)
Supervisory Current
Surge Current
Maximum Alarm Current LED on
Max Line Impedance

Functional States

Analog Levels: Normal
Relay Output

Functional Test Data

Output Function Input
Bit Bit
2 Alarm LED 2
1 = On
0 = Off
1 Not Used 1
0 Relay Control 0
1 = On
0 = Off
25 Interchange Way, Vaughan, Ontario, L4K 5W3
Tel: (905) 660-4655, Fax: (905) 660-4113
4575 Witmer Industiral Estates, Niagara Falls, New York 14305
Tel Toll Free: (888) 660-4655, Fax Toll Free: (888) 660-4113
Website: www.mircom.com
39214-395/Issue 1 Draft B
MIX-100R
MIX-100R
Relay Output Monitor
Fascia Plate with wiring terminals
4½" x 4½" x 1"
32°F to 120°F (0°C to 49°C)
10 to 93% RH non-condensing
Supervised
17–28V DC
9-5V
0.85mA
2.5mA
3.5mA
50Ω max
16
Non Supervised, dry contact;
24VDC, 2A; 30VAC, 0.5A
Function
Alarm LED Confi rmation
1 = On
0 = Off
Not Used
Relay Confi rmation
1 = On
0 = Off
Canada
USA
4
Alpha Relay Output Module
Installation Instructions

General

The Alpha Relay Output Module, part no MIX-100R, is a loop-powered device which
incorporates a dual form C, volt-free relay output. It is mounted on a plastic fascia
plate for use with a 4" electrical box.
A red LED fl ashes in synchronization with the current pulse reply from the device. If
output bit 2 is set, the LED is illuminated continuously.
Note: the Alpha Relay Output Module is not designed for outdoor use unless it is
mounted in a suitable weatherproof enclosure.

Control Panel Compatibility

Compatibility Identifi er number: MIX-100R. The module has been approved by Under-
writers Laboratories Inc. For details of compatible control panels contact Apollo Fire
Detectors Limited.

Installation

These products must be installed in accordance with the applicable NFPA standards,
local codes and jurisdictional authorities. Failure to follow these instructions may
result in failure of devices to report an alarm condition. Apollo Fire Detectors Limited
is not responsible for devices which are improperly installed, maintained and tested.
Before installing these products, check the continuity, polarity and insulation resist-
ance of all wiring. Check that siting is in accordance with the fi re system drawings
and conforms to all applicable local codes such as NFPA 72.
1. Mount the electrical box as required and install all cables for termination. Ensure
that cable shield/earth continuity is maintained.
2. Terminate all cables in compliance with local codes and regulations.
3. Set the address of the module as shown on page 3.
4. Drill holes in the fascia plate corresponding to the holes on the mounting box
selected (Fig 1).
5. Gently push the completed assembly towards the mounting box and align the
fi xing holes. Secure the unit with the screws provided. Do not overtighten the
screws.
6. Commission the module.
