For safety and easy faucet replacement, San-Ei recommends the use of
the following helpful tools:
SAFETY GLASSES
ADJUSTABLE WRENCH
Keep Instructions for Future Reference
Thank you for purchasing San-Ei's quality faucet.
With simple care and maintenance, it will provide you with many years of reliable
performance.
Please read instructions before installation.
TIPS FOR REMOVAL OF OLD FAUCET
CAUTION: Always turn water OFF before removing existing faucet or
disassembling the faucet.
Open the faucet handles to relieve water pressure and ensure that
complete water shut-off has been accomplished.
(Complies with ASME A112.18.1)
T o o l s
PIPE WRENCH
BASIN WRENCH
A b o u t T h i s M a n u a l
- 1 -
INSTALLATION INSTRUCTIONS
K877-BW
SINGLE HANDLE
Kitchen Faucet
PLIERS
PHILLIPS SCREWDRIVER
BW-0BH
CHANNEL LOCKS
FLASHLIGHT
Advertisement
Table of Contents
Related Manuals for San-Ei K877-BW
Summary of Contents for San-Ei K877-BW
- Page 1 BW-0BH INSTALLATION INSTRUCTIONS K877-BW SINGLE HANDLE Kitchen Faucet T o o l s For safety and easy faucet replacement, San-Ei recommends the use of the following helpful tools: SAFETY GLASSES PIPE WRENCH PLIERS CHANNEL LOCKS ADJUSTABLE WRENCH BASIN WRENCH PHILLIPS SCREWDRIVER...
- Page 2 P A R T S L I S T The structure shown is an illustration. Please use this structure for better understanding. K877-BW General Description 1. Cap 2. Screw 3. Lever 4. Cover 5. Cartridge Holder 6. Lever Holder 7. Ceramic Cartridge 8.
- Page 3 O P E R A T I O N Kitchen Faucet K877-BW 11"(280mm) K877-BW 2-1/5"(55mm) M35x1.5 NOTE : Maximum deck thickness for installation is 1-1/5"(30mm). Hole size for installation is between 1-2/5"(36mm) to 1-1/2"(38mm). Waste assemble are included with some models.
- Page 4 Either ordinary flow or shower flow can be used. Ordinary flow Shower flow The spout head is twistable in 45 degree each. 45 degree each Caution!: * Don’t loosen the nut while water is running. This may cause to injure properties, due to the water leakage.
- Page 5 I N S T A L L F A U C E T Hot Water Pipe Cold Water Pipe Tighten (Caution !) Excessive bending will cause leaking and damage to the pipes. Hot Water Cold Water Pipe Pipe Temporary Tighten Compression Ring 1.
- Page 6 C A R T R I D G E R E P L A C E M E N T Caution!: Always turn water OFF before removing the cartridge. Open the handle to relieve water pressure and ensure that water shut-off has been accomplished. 1.
- Page 7 F L U S H I N G I N S T R U C T I O N S IMPORTANT! : Pipe chips, sand, stones and other solid found in new and renovated plumbing can damage the cealing of the cartridge and cause leaks to avoid damage, DO NOT TURN ON SUPPLY VALVES until instructed below.
