Summary of Contents for Blaupunkt 7 607 548 500
- Page 1 Zubehör / Accessories Bluetooth-/USB-Interface 7 607 545 500 mit / with PTT mit / with OLED-Display (optional) 7 607 548 500 optional www.blaupunkt.com...
-
Page 2: Connection
Connection / Anschluss Microphone Mikrofon PTT (Push To Talk) - Key PTT-Taste C1 C2 USB Socket (Memory stick not included) USB-Anschluss (ohne USB-Datenträger) - Page 3 Connection / Anschluss OLED (not included) PTT (Push To Talk) - Key PTT-Taste C1 C2 Microphone Mikrofon USB Socket (Memory stick not included) USB-Anschluss (ohne USB-Datenträger)
- Page 4 Dimensions (inch) Abmessungen (mm) Weight Gewicht For all Blaupunkt Aftermarket radios as from 2002 supporting CDC. Für alle Blaupunkt-Autoradios ab 2002, die CD Changer Control unterstützen. 1.2 (compatible with 1.x) HFP, SPP, GAP, SDAP. AADP (A2DP), AVRCP e1, CE, FCC, Bluetooth Version 2.0 (full speed), (compatible with 1.x)
-
Page 5: Table Of Contents
Connection ... 2 Technical Data ... 4 Safety notes ... 25 Declaration of conformity ... 25 Switch-on ... 25 Switch-off ... 25 Displays and controls ... 26 Registering (pairing) your cell phone with the interface ... 26 Connecting two BT devices with the interface at the same time ... -
Page 6: Technical Data
A signifi cant innovation since SW8625 is the sup- port for the OLED display (7 607 548 500 001). Note: Bluetooth USB interfaces with hardware version "1"... -
Page 7: Displays And Controls
French, German) or ID3 tags from MP3 fi les to be displayed. After initial switch-on After switch-on, the OLED display greets you with a Blaupunkt lettering which gives way for a smaller lettering after a few seconds. Registering (pairing) your cell phone with the interface Use your cell phone to search for Bluetooth de- vices (see the instructions of the cell phone ->... -
Page 8: Connecting Two Bt Devices With The Interface At The Same Time
Connecting two BT devices with the interface at the same time The use of the services "Hands-Free Calling" and "Audio Streaming" can now (new) be performed by different BT devices that are connected with the interface at the same time. For example: cell phone for hands-free calling and Music Player with Bluetooth transmitter (BT-TX) for audio streaming. -
Page 9: Overview Of Functions
Overview of functions Previously possible Mode Hands-free calling with cell phone BT hands-free calling Hands-free calling and audio streaming with cell phone BT audio streaming BT hands-free calling Audio streaming with BT transmitter (BT-TX) BT audio streaming Function not available! Possible with SW8205 or higher Hands-free calling with cell phone BT hands-free calling... - Page 10 Overview of functions Mode Previously possible Hands-free calling with 2 cell phones pos- Function not available! sible Audio streaming with 2 BT pos- transmitters (BT-TX) sible Function not available! Technically not possible Hands-free calling with 2 cell phones Function not available! BT hands-free calling BT hands-free calling Audio streaming with 2 BT...
-
Page 11: Telephone: Incoming Call
The car sound system must be in the CD changer mode and support the CDC text. The TXT or MD confi guration (device-depend- ent) must have been loaded by the interface, see www.blaupunkt.com. The cell phone must also support phone list control. ➜... -
Page 12: Audio Streaming Via Bt
Playback lists (M3U playlists) are recognised in all directories and processed, not only in the BLAUPUNKT directory. They are handled similar to directories. Sorting is done by memory sequence. During the MP3 playback, the OLED display shows additional information from the MP3 fi... -
Page 13: Browsing (Oled)
• To avoid possible setting confl icts, you should delete or rename the confi g.txt fi le from your Blaupunkt directory when using an OLED display. • The following overview shows which settings you can perform in your interface. The basic... - Page 14 Operation with PTT Adjust the desired confi guration by loading a con- fi g.txt fi le. See the section Instructions for confi g- uration changes The following table shows the displayed confi gurations in square brackets […].
-
Page 15: Settings
This setting should be activated if your cell phone does not request the PIN for the "Blaupunkt IF" after the pai- ring during the Bluetooth connection attempt. For exa- mple, this applies to Nokia 6210, Motorola V300... - Page 16 Settings [Confi g display] Display Brightness Auto (Sensor) Fix 20% … Fix 100% Standby 10 sec. … 120 sec. Switch-on Press button + display update Press button Scroll mode Continuous Once Function Settings of various display functions Brightness setting The brightness of the display adjusts automatically to the ambient light conditions.
- Page 17 Settings [Confi g display] ID3 Confi g Display 1 line 2 lines Info 1 Track Album Artist File name Directory or playlist name Info 2 Track Album Artist File name Directory or playlist name Function Display of data from MP3 fi les (ID3 tags) Selection of display form The data selected in "Info 1"...
- Page 18 SW ver: 8424 P.Date 7113 P.Code: CN Confi g: [CDC_...] | [CFG_PB_...] | … Display module Blaupunkt display 7 607 548 500 001 SW ver: 02.05 HW ver: 0E.00 Function Display of technical data The displayed technical data of the Bluetooth USB interface correspond to the data listed in "id.txt"...
- Page 19 Setting of the interface to the radio / RNS, no change for the OLED display use. Please note the Commercial radios compatibility list and delete existing confi g.txt fi les from the Blaupunkt directory of your USB stick or USB hard disk Radio display: max. 999 own playlists and directories, max. 999...
-
Page 20: Play Mode
Settings Play Mode Normal MIX Directory MIX Medium Repeat Track Repeat Directory Repeat Medium Scan Directory Scan Medium Function MIX / RPT / SCAN setting without CDC control (Operation via AUX interface - Attention: Menu item ap- pears only if there is no CDC connection to the radio!) Standard playback order Music fi... -
Page 21: Software Update
Example: "W:\ Blaupunkt" Load the software of the Bluetooth/USB inter- face from www.blaupunkt.de and store it in a directory of your computer. Unzip the ZIP fi le and copy the unzipped fi les to the Blaupunkt directory on the USB device. -
Page 22: Changing The Confi Guration (Ptt)
Loading a confi guration fi le* The Bluetooth USB interface features a factory set standard confi guration that allows safe operation with as many commercial Blaupunkt radios and radio navigation systems as possible. For com- patibility reasons, advanced functions and setting options had to be deactivated for this purpose. - Page 23 # in the fi rst column) the desired parameters. For this, proceed as follows: • Copy the fi le "confi g_universal.txt" from the unpacked download archive into the Blaupunkt directory of your USB data me- dium. • Rename the fi le in "confi g.txt". •...
-
Page 24: Fcc-Statements
FCC-Statements All following FCC statements are valid for the Industry Canada Standard (IC) as well. 1. General Interference Warning: (according to FCC part 15.19) This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful in- terference, and... - Page 25 08-750 18 50 01-8471644 02-6130 0446 76 889 704 0800-118922 0212-335 07 23 800-950-2528 0800 7045446 +604-6382 474 Blaupunkt GmbH Robert-Bosch-Str. 200 D-31139 Hildesheim CM-AS/SCS - 8 622 406 341 Fax: 05121-49 4002 01-610 393 91 44-898 644 09-435 99236...
