Aztech 16" Stand Fan
• Main Body
• Fan Blade
• Fan Stand
• Fan Base
ASSEMBLING THE STAND FAN
PLEASE KEEP THIS EASY START GUIDE FOR FUTURE USE.
ASF883
EASY START GUIDE
PACKAGE CONTENTS
• Front Grill
• Rear Grill
• Remote Control
1. Attach the Outer Tube and Base Cap to the Fan
Base.
2. Using the Base Nut and Base Screw, fasten the
Fan Base tightly to the Outer Tube.
3. Loosen the Height Adjustment Ring and pull
out the Inner Tube until the desired fan height
is achieved. You may then fasten the Height
Adjustment Ring to tightly clamp the Inner Tube
with the desired height in place.
4. Ease in the Main Body into the Outer Tube and
fasten the Main Body Lock to hold it in place.
5. On the Fan Motor, position the Rear Grill with the
Fan Handle facing up. Ensure that the Rear Grill
is stably positioned into the grooves of the Fan
Motor.
6. Using the Grill Nut, fasten the Rear Grill by turning
it clockwise until the Rear Grill is securely fastened
into place.
• Easy Start Guide
• User Manual
• Warranty Policy
Advertisement
Table of Contents
Related Manuals for Aztech ASF883
Summary of Contents for Aztech ASF883
-
Page 1: Package Contents
ASF883 Aztech 16” Stand Fan EASY START GUIDE PACKAGE CONTENTS • Main Body • Front Grill • Easy Start Guide • Fan Blade • Rear Grill • User Manual • Fan Stand • Remote Control • Warranty Policy • Fan Base ASSEMBLING THE STAND FAN 1. - Page 2 Should damages be found in the appliance, please do not use the • appliance and immediately bring it to the Aztech Service Center for repair or replacement. 1. Position the fan on a smooth and stable ground STABLE GROUND and plug its power adapter to a power outlet.
