- Page 1 ASF883 Aztech 16” Stand Fan USER MANUAL PLEASE KEEP THIS USER MANUAL FOR FUTURE USE.
-
Page 3: Table Of Contents
USER MANUAL CONTENTS SAFETY INSTRUCTIONS...............3 PACKAGE CONTENTS...............5 APPLIANCE OVERVIEW..............5 ASSEMBLING THE STAND..............8 ASSEMBLING THE FAN...............9 USING THE APPLIANCE..............10 CLEANING & MAINTENANCE............13 TECHNICAL SPECIFICATIONS............14 SAFETY INSTRUCTIONS • Ensure that the appliance and all of its parts and components are properly assembled, prepared, and locked into place. •... - Page 4 • Should damages be found in the appliance, please do not use the appliance and immediately bring it to the Aztech Service Center for repair or replacement. • Your Aztech Stand Fan is not intended for people with reduced physical, sensory or mental capabilities, and/or lack of experience or knowledge.
-
Page 5: Package Contents
PACKAGE CONTENTS • Easy Start Guide • Main Body • Front Grill • User Manual • Fan Blade • Rear Grill • Warranty Policy • Fan Stand • Remote Control • Fan Base APPLIANCE OVERVIEW COMPONENTS FAN MOTOR/ FAN HEAD CONTROL PANEL SCREW FRONT GRILL... - Page 6 FAN CONTROL PANEL LED DISPLAY 1/2/3 Displays the currently selected fan speed: 1 (LOW), 2 (MEDIUM) or 3 (HIGH). FAN BUTTONS ON/SPEED • Press this button to turn ON the fan. Subsequent presses: LOW → MEDIUM → HIGH. OSC. • Press this button to enable or disable the 4-Way Fan Oscillation (horizontally and vertically).
- Page 7 REMOTE CONTROL ON/SPEED • Press this button to turn ON the fan. Subsequent presses: LOW → MEDIUM → HIGH. TIMER • Press this button repeatedly until the preferred operation time (0.5h, 1h, 2h, or 4h) is selected. MODE • Press this button repeatedly to shift between the three blowing modes of the fan: (1) Normal (default when turned on), (2) Natural, and (3)
-
Page 8: Assembling The Stand
ASSEMBLING THE STAND TIPS BEFORE ASSEMBLING THE FAN • Ensure to unpack the fan and its components. • Remove the Fan Blade Cap and the Grill Nut from the motor shaft. • Remove the Base Nut and Base Screw from the Outer Tube. STEP 1 Attach the Outer Tube and Base Cap to the Fan Base. -
Page 9: Assembling The Fan
ASSEMBLING THE FAN STEP 1 On the Fan Motor, position the Rear Grill with the Fan Handle facing up. Ensure that the Rear Grill is stably positioned into the grooves of the Fan Motor. STEP 2 Using the Grill Nut, fasten the Rear Grill by turning it clockwise until the Rear Grill is securely fastened into place. -
Page 10: Using The Appliance
• Should damages be found in the appliance, please do not use the appliance and immediately bring it to the Aztech Service Center for repair or replacement. STEP 1 Correctly assemble the fan as shown on the Stand Fan Assembly section. - Page 11 ADJUSTING THE FAN’S HEIGHT STEP 1 Correctly assemble the fan as shown on the Stand Fan Assembly section. STEP 2 Using your other hand, loosen the Height Adjustment Ring. STEP 3 Slowly lower or raise the Main Body until the desired height is achieved and tighten the Height Adjustment Ring to hold it in place.
- Page 12 • NORMAL MODE Uses one (1) speed setting (e.g. LOW) throughout the operation. • NATURAL MODE Depending on your initially selected speed, the Natural Mode automatically changes speed using a regular set of intervals. NOTE: Starting speed depends on your initially selected speed (e.g. LOW speed would enable LOW NATURAL SPEED).
-
Page 13: Cleaning & Maintenance
CLEANING & MAINTENANCE TIPS BEFORE CLEANING / MAINTENANCE • Your Aztech Stand Fan is not intended for people with reduced physical, sensory or mental capabilities, and/or lack of experience or knowledge. Constant supervision (from a person responsible for their safety) should be provided if such individuals would be using, cleaning, or operating, the appliance. -
Page 14: Technical Specifications
TECHNICAL SPECIFICATIONS Motor 100% full copper with heat protection Motor Size 74mm x 16mm Fan Grill 1.4mm wire diameter Power Consumption Timer 450 minutes Blade 5-piece AS transparent blades... - Page 16 Copyright © 2018 Aztech Technologies Pte Ltd (CRN:199800635M). All rights reserved.
