Tempco Instruction Manual
1/16 DIN Solid State Temperature Controller–
Relay Output–Solid State Output–For Heating
Model Numbers: TEC-901, TEC-902, TEC-905
Temperature controls in this series are designed to fit panel cutouts that are 1-25/32" (45mm)
square. 4-1/8" minimum depth is required to provide clearance for rear terminal connections. All
models have the following specifications in common:
Input
Thermocouple (T/C)
RTD
Cold junction compensation
Input break protection
Input impedance
Common mode rejection (CMR)
Normal mode rejection (NMR)
Control Output
Relay—heating
Optional: 3–32VDC
Control Modes
On-Off
Proportional
Indication
Output
Set Point
Resolution
Accuracy
Power
Rating
Consumption
Environmental and Physical
Operating Temperature
Humidity
Insulation
Breakdown
Vibration
Shock
Weight
Dimensions
1-7/8" (48mm) x 1-7/85"(48mm) x 3-3/4"(94mm) H x W x D
Depth behind panel: 3-3/8" (86mm).
Panel cutout
DIN case
Type K, J. See Control label.
Three-wire PT 100 ohm DIN or JIS.
Automatic
Built-in, upscale on open sensor and output off.
10M ohm
CMRR 120dB, min.
NMRR 60dB, min. (60Hz)
SPDT relay, 3 amps max resistive load at 120V/240VAC, 24VDC.
For control of solid state relay.
Hysteresis: 5.0% of scale symmetrically above and below the set point.
Proportional Band fixed at 5% of scale. 20 seconds standard relay cycle time.
1 second for SSR controls. TEC-905 has manual reset of 4% of scale,
adjustable externally.
Red LED, heater on/green LED, heater off.
TEC-901, 902: 0.2% of SPAN. TEC-905: least significant digit.
TEC-901, 902: 0.2% of SPAN. TEC-905: least significant digit.
TEC-901, 902: 110/220VAC ±15% NOT field selectable, 50/60Hz.
TEC-905: 90–264VAC. 24V AC/DC models can be special ordered.
Less than 3VA.
10 to 125°F (-12 to 52°C)
0–90% RH (non-condensing)
20M ohm min. (5000VDC)
2000VAC, 50/60Hz, 1 minute
10–55Hz, amplitude 1.0mm
660ft/s
(20g)
2
9oz (250g)
1-25/32" square (45 mm square)
Plastic full plug-in construction with screw terminals on rear and adjustable
brackets for panel mounting.
Revision 11/2010
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tempco TEC-902
Summary of Contents for Tempco TEC-902
- Page 1 1/16 DIN Solid State Temperature Controller– Relay Output–Solid State Output–For Heating Model Numbers: TEC-901, TEC-902, TEC-905 Temperature controls in this series are designed to fit panel cutouts that are 1-25/32" (45mm) square. 4-1/8" minimum depth is required to provide clearance for rear terminal connections. All...
- Page 2 The solid-state relays can be single or three-phase. The TEC-905 possesses universal line voltage capability from 90–264VAC. The TEC-901 and TEC-902, however, are not interchangeable between different line voltages; only the specified line voltage must be used. When wiring the thermocouple, make sure that the thermocouple and extension wire conform to the thermocouple type specified by the instrument.
-
Page 3: Wiring Precautions
1 N-m (8.9 lb-in or 10 KgF-cm). General Operation OUT lamp indication: HI and LO indication lamps on TEC-902: Adjust the set point to the temperature desired. The “OUT” These lamps compare the actual temperature of the lamp will glow red, indicating that the control is calling for process to the control set point. - Page 4 Short Short 20 sec. Relay output Other options available for large volume orders, Open Short 1 sec. SSR drive consult Tempco for more information. Open Open 0.02 sec. Linear current or voltage output (3) Range Code (TEC-905) -199–199°C 0–999°C -99.9–99.9°C 0–1200°C...
-
Page 5: Troubleshooting
Tempco Electric Heater Corporation is pleased to offer No product returns can be accepted without a completed Return suggestions on the use of its products. However, Tempco makes Material Authorization (RMA) form. no warranties or representations of any sort regarding the fitness for use, or the application of its products by the Purchaser.
