Congratulations on your purchase of an Arnott
offer a high quality product at the industry's most competitive pricing. Thank you for your confidence in us and
Proper installation is essential to experience and appreciate the benefits of this system. Please take a moment
to review these installation instructions before you begin to install these components on your vehicle. The
removal and installation of air suspension products should only be performed by a fully qualified, ASE
It is equally important to be aware of all necessary safety measures while installing your new Air Suspension
System. This includes proper lifting and immobilizing of the vehicle and isolation of any stored energy to
WARNING: The air suspension system is under pressure (up to 10 bar, or 150 lbf/in). Verify pressure has been relieved
and disconnect power to the air suspension system prior to disassembly. Do not allow dirt or grease to enter the system.
Always wear standard hand, ear, and eye protection when servicing the air suspension system.
Arnott
is committed to the quality of its products. If you have a question or problem with any Arnott product,
®
please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.
(In the EU please call +31 (0)73 7850 580 or email info@arnotteurope.com).
1
P-2872
AIR SUSPENSION COMPRESSOR
BMW X
BMW X
®
Certified, professional.
prevent personal injury or property damage.
Engineered to Ride, Built to Last
"
2872
P-
5
70
(E
CHASSIS)
6
71
(E
CHASSIS)
air suspension product. We at Arnott Incorporated are proud to
our product.
"
®
REV 2
06/06/2018
Advertisement
Table of Contents
Related Manuals for Arnott P-2872
Summary of Contents for Arnott P-2872
- Page 1 Always wear standard hand, ear, and eye protection when servicing the air suspension system. Arnott is committed to the quality of its products. If you have a question or problem with any Arnott product, ® please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.
- Page 2 SET STEERING TO STRAIGHT AHEAD. RAISE VEHICLE. REMOVE THE FASTENERS AND PANELING UNDER THE RIGHT SIDE OF THE VEHICLE TO EXPOSE THE VEHICLE'S AIR SUSPENSION COMPRESSOR VALVE BLOCK. ( FIGURES 10-1, 10-2 FIGURE 10-1 FIGURE 10-2 P-2872 REV 2 06/06/2018...
- Page 3 LOCATE AND REMOVE THE THREE (3) ELECTRICAL CONNECTORS ON THE COMPRESSOR/VALVE BLOCK ASSEMBLY. FIGURES 10-3, 10-4, 10-5 FIGURE 10-3 FIGURE 10-4 FIGURE 10-5 LOCATE AND REMOVE THE TWO (2) AIR LINES LEADING TO THE VALVE BLOCK. (FIGURE 10-6) FIGURE 10-6 P-2872 REV 2 06/06/2018...
- Page 4 LOOSEN AND REMOVE THE HARDWARE HOLDING THE BRACKETS FOR THE FOUR (4) BLACK TUBES RUNNING DIRECTLY UNDERNEATH THE COMPRESSOR. (FIGURES 10-8, 10-9) FIGURE 10-8 FIGURE 10-9 LOCATE AND REMOVE THE THREE (3) NUTS HOLDING THE COMPRESSOR ASSEMBLY TO THE VEHICLE. (FIGURES 10-10, 10-11) FIGURE 10-10 FIGURE 10-11 P-2872 REV 2 06/06/2018...
- Page 5 (FIGURE 10-12) FIGURE 10-12 REMOVAL COMPLETE. AIR SUSPENSION COMPRESSOR ASSEMBLY INSTALLATION Tighten all nuts and bolts to manufacturer's specifications during the installation process. INSTALL THE COMPRESSOR ASSEMBLY BACK INTO THE VEHICLE IN THE REVERSE ORDER OF REMOVAL. P-2872 REV 2 06/06/2018...
- Page 6 * IT IS RECOMMENDED THAT YOU REPLACE YOUR BMW X5/X6 AIR SPRINGS IN PAIRS. Arnott is committed to the quality of its products. If you have a question or problem with any Arnott product, ® please contact Arnott by calling 800-251-8993 during normal business hours or email techassistance@arnottinc.com.
