LumaPro 53DK24 Operating Instructions Manual

Operating Instructions
Please read and save these instructions. Read through this owner's manual carefully before
using product. Protect yourself and others by observing all safety information, warnings, and
cautions. Failure to comply with instructions could result in personal injury and/or damage to
product or property. Please retain instructions for future reference.
Description
Typically used to replace 2'x2' fluorescent fixtures, the LED Recessed Troffer is
designed to lay in drop ceilings in offices, schools, and healthcare applications. The
flat panels are fully dimmable, and are compatible with building controls, motion
sensors, timers, and daylight harvesting systems.
The design of the panels produces an even, consistent shadowless light. The LEDs
enable long life, high lumen maintenance, and are low maintenance and constructed
without hazardous materials.
Picture is for illustration purposes only. Your model may vary.
FEATURES
•
Standard dimming: 0-10V dimming
•
Five year limited warranty
•
CRI: 80
•
Fits standard T-bar and narrow grid drop ceilings
•
Standard white finish
•
IC Rated for direct insulation contact
Specifications and Dimensions
Model Volts
53DK24 120-277V
LED Recessed Troffer
Watts CCT Lumens
30W 4100K
CRI Size
3,680 80 2 x 2
53DK24
Dimensions (in)
H" x D" x W"
23.8" x 2.2 x 23.8
