V2616 Hardware User's Manual
First Edition, August 2011
www.moxa.com/product
© 2011 Moxa Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V2616 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Moxa Technologies V2616 Series

Summary of Contents for Moxa Technologies V2616 Series

  • Page 1 V2616 Hardware User’s Manual First Edition, August 2011 www.moxa.com/product © 2011 Moxa Inc. All rights reserved.
  • Page 2 V2616 Hardware User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2011 Moxa Inc., All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc. All other trademarks or registered marks in this manual belong to their respective manufacturers.

  • Page 3: Table Of Contents

    Table of Contents Introduction ............................1-1 Overview ............................1-2 Package Checklist ..........................1-2 Product Features ..........................1-2 Hardware Specifications ........................1-2 Hardware Block Diagram ........................1-5 Hardware Introduction........................2-1 Appearance ............................2-2 Dimensions ............................2-3 LED Indicators ............................ 2-3 Real Time Clock ..........................2-4 Hardware Connection Description .....................
  • Page 4 Exiting the BIOS Setup ........................4-10 Save & Exit Setup ........................4-10 Exit Without Saving ........................4-10 Upgrading the BIOS .......................... 4-11 Regulatory Approval Statement ......................A-1...

  • Page 5: Introduction

    Introduction The following topics are covered in this chapter:  Overview  Package Checklist  Product Features  Hardware Specifications  Hardware Block Diagram...

  • Page 6: Overview

    Introduction Overview The V2616 Series EN 50155 certified embedded computers are based on the Intel Core 2 Duo SP9300 x86 processor and feature 2 RS-232/422/485 serial ports, dual LAN ports, and 3 USB 2.0 hosts. In addition, the V2616 computers provide VGA and DVI-D outputs and their EN 50155 certification makes them robust enough for railway and industrial applications.
  • Page 7 V2616 Hardware Manual Introduction Display Graphics Controller: Intel GS45 Integrated Graphics Engine VGA Interface: DB15 female connector, up to 2048 x 1536 resolution DVI Interface: DVI-D connector (chrontel CH7307 SDVO to DVI transmitter), up to 1600 x 1200 resolution Ethernet Interface LAN: 2 auto-sensing 10/100/1000 Mbps ports (M12) Serial Interface Serial Standards: 2 software-selectable RS-232/422/485 ports* (DB9 male)
  • Page 8 V2616 Hardware Manual Introduction Environmental Limits Operating Temperature: (with SSD installed) -25 to 55°C (-13 to 140°F) Storage Temperature: (with SSD installed) -30 to 60°C (-40 to 185°F) Ambient Relative Humidity: 5 to 95% (non-condensing) Anti-vibration: EN 50155 standard Anti-shock: EN 50155 standard Power Requirements Input Voltage: 24 VDC (9 to 36 V), M12 connector Power Consumption: 50 W...

  • Page 9: Hardware Block Diagram

    V2616 Hardware Manual Introduction Hardware Block Diagram...

  • Page 10: Hardware Introduction

    Hardware Introduction The V2616 series embedded computers are compact, well-designed, and built rugged enough for industrial applications. LED indicators help you monitor performance and identify trouble spots, multiple serial ports allow you to connect different devices for wireless operation, and the reliable and stable hardware platform lets you devote your attention to developing your applications.

  • Page 11: Appearance

    V2616 Hardware Manual Hardware Introduction Appearance Front View Rear View...

  • Page 12: Dimensions

    V2616 Hardware Manual Hardware Introduction Dimensions LED Indicators LED Name LED Color LED Function Power Green Power is on and functioning normally Power is off or power error exists Storage Yellow CF/HDD card is detected CF/HDD card is not detected LAN (1, 2) Green 100 Mbps Ethernet mode...

  • Page 13: Real Time Clock

    V2616 Hardware Manual Hardware Introduction Real Time Clock The embedded computer’s real-time clock is powered by a lithium battery. We strongly recommend that you NOT replace the lithium battery on your own. If the battery needs to be changed, please contact the Moxa RMA service team.

  • Page 14: Hardware Connection Description

    Hardware Connection Description In this chapter, we show how to connect the embedded computers to the network and to various devices. The following topics are covered in this chapter:  Installing the V2616  Wiring Requirements  Connecting the Power ...

  • Page 15: Installing The V2616

    V2616 Hardware Manual Hardware Connection Description Installing the V2616 Wall or Cabinet Mounting The V2616 comes with two wall-mounting brackets. Use two screws per side to attach the V2616 to a wall or cabinet. Wiring Requirements This section describes how to connect serial devices to the embedded computer. You should read and follow these common safety precautions before proceeding with the installation of any electronic device: •...

  • Page 16: Connecting The Power

    V2616 Hardware Manual Hardware Connection Description ATTENTION Safety First! Be sure to disconnect the power cord before installing and/or wiring your V2616. Wiring Caution! Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size.

  • Page 17: Connecting To A Serial Device

    V2616 Hardware Manual Hardware Connection Description Connecting to a Serial Device Use a serial cable to plug your serial device into the embedded computer’s serial port. Serial ports P1 to P2 have male DB9 connectors and can be configured for RS-232, RS-422, or RS-485 communication by software. The pin assignments are shown in the following table: DB9 Male Port RS-232/422/485 Pinouts...

  • Page 18: Connecting A Ps/2 Keyboard And Mouse

    V2616 Hardware Manual Hardware Connection Description 4. Gently insert the CompactFlash card into the CF socket, making sure that the card is oriented correctly. ATTENTION The V2616 embedded computer does not support the CompactFlash hot swap and PnP (Plug and Play) functions.

  • Page 19: Connecting To A Usb Device

    V2616 Hardware Manual Hardware Connection Description Use the Y-type cable to convert the mini-DIN connector into two 6-pin mini-DIN connectors to connect both a PS/2 keyboard and PS/2 mouse at the same time. You may also use the USB ports to connect your USB-based keyboard and mouse.

  • Page 20: Di/Do

    V2616 Hardware Manual Hardware Connection Description DI/DO The V2616 comes with a 6-ch digital input and a 2-ch digital output through a terminal block connector. The pin assignments and the wiring methods are shown below.. DI Dry Contact Wiring DI Wet Contact Wiring DO Wiring Connecting to a VGA Monitor The V2616 comes with a D-Sub 15-pin female connector on the front panel to connect a VGA CRT monitor.

  • Page 21: Connecting To A Dvi-D Monitor

    V2616 Hardware Manual Hardware Connection Description Connecting to a DVI-D Monitor The V2616 computers also come with a DVI-D connector that can connect to a DVI monitor. Use the cable to connect one end to the DVI-D connector and the other end to the monitor. See the following table for DVI-I connector pin assignments.

  • Page 22: Installing An Internal Storage Device

    V2616 Hardware Manual Hardware Connection Description Installing an Internal Storage Device The V2616 computer comes with an internal storage tray that allows users to install a 2.5-inch SATA storage device, such as a hard disk or a SSD drive. Take the following steps to install your storage device. 1.

  • Page 23: Installing A Sata Storage Device In The Removable Trays

    V2616 Hardware Manual Hardware Connection Description 3. First connect the cable and then place the storage device into the tray. Be sure to orient the device in the correct direction. 4. Fasten the screws on the sides of the storage tray. 5.

  • Page 24: Upgrading The Memory Module

    V2616 Hardware Manual Hardware Connection Description 2. Rotate the key counterclockwise to unlock the protection lock, and then pull out the tray by grasping the screws on each side. Place the hard disk into the tray, and then turn the tray clockwise. Fasten the hard disk with two screws on the back of the tray.
  • Page 25 V2616 Hardware Manual Hardware Connection Description 3. Pull up the back cover of the computer; you will be able to see the memory module socket on the main board. 3-12...
  • Page 26 V2616 Hardware Manual Hardware Connection Description 4. Carefully remove the module by pushing the latches on both sides of the module, and then replace the new module. Be sure to orient the module correctly. 5. Push down the module and make sure the latches are firmly in place. 6.

  • Page 27: Bios Setup

    BIOS Setup This chapter describes the BIOS settings of the V2616 computer. The BIOS is a set of input/output control routines for peripherals. The BIOS is used to initialize basic peripherals and helps boot the operating system before the operating system is loaded. The BIOS setup allows the user to modify the system configurations of these basic input/output peripherals.

  • Page 28: Entering The Bios Setup Utility

    V2616 Hardware Manual BIOS Setup Entering the BIOS Setup Utility To enter the BIOS setup utility, press the “Del” key while the system is booting up. The main BIOS Setup screen will appear. A basic description of each function key is listed at the bottom of the screen. Refer to these descriptions to learn how to scroll about the screen, how to select by pressing “Enter,”...

  • Page 29: System Security

    V2616 Hardware Manual BIOS Setup System Security To set up system security, select the “Security” option under “Main” to bring up the following screen. This menu includes two options: “Set Password” and “Security Option.” When you select the Set Password option, a pop-up “Enter Password:” window will appear on the screen. The password that you type will replace the password stored in the CMOS memory.

  • Page 30: Hard Disk Boot Priority

    V2616 Hardware Manual BIOS Setup Hard Disk Boot Priority First/Second/Third Boot Device This option allows users to select or change the device boot priority. You may set 3 levels of priority to determine the boot up sequence for different bootable devices, such as a hard drive, CD-ROM, and removable devices.

  • Page 31: Virtualization Technology

    V2616 Hardware Manual BIOS Setup Virtualization Technology This item allows you to enable or disable the Virtualization Technology Options: Enabled, Disabled (default) Quick Power On Self Test This setting allows the system to skip certain tests while the system boots up. Enable this feature to speed up the boot up process.

  • Page 32: Boot Display

    V2616 Hardware Manual BIOS Setup Boot Display This item allows you to choose which display interface will be shown when system is booting up. Due to the display limitation, two displays at most can be shown when booting up. If you select the default option, VBIOS Default", the displays that have been connected will be used as the default displays.

  • Page 33: Super I/O Device

    V2616 Hardware Manual BIOS Setup Super I/O Device Debug Port This function allows you to enable/disable the debug port communication. This port is only for engineers who are debugging program. Options: Disabled (default), Enabled Power on After Power Fail This item allows you to configure the power on after power fail function. Options: Off, On (default), Former-Sts Power The Power Setup Menu allows you to configure your system power-up/ power-down options.

  • Page 34: Hpet Support

    V2616 Hardware Manual BIOS Setup HPET Support This item allows you to enable/disable the HPET (High Precision Event Timer) function. Option: Enabled (default), Disabled HPET Mode This item allows you to select the HPET mode. Option: 32-bit mode (default), 64-bit mode Soft-Off by PWR-BTTN This item determines the delay to stop the software when pushing the power button.

  • Page 35: Hardware Monitor

    V2616 Hardware Manual BIOS Setup Hardware Monitor This item helps monitor the status of the system, including CPU temperature and the voltage of the CPU, SDRAM and battery. CPU Warning Temperature This item allows you to configure what temperature will trigger a high temperature warning. Options: 80°C/176°F, 90°C/194°F (default), 100°C/212°F, Disabled Warning Beep This item allows you to enable/disable the warning beep.

  • Page 36: Load System Default Settings

    V2616 Hardware Manual BIOS Setup Load System Default Settings Use this option to load system factory default settings instead of the current BIOS settings. This option is useful for when the system is unstable. Users do not need to remember what settings were active before the system fails.

  • Page 37: Upgrading The Bios

    V2616 Hardware Manual BIOS Setup Upgrading the BIOS This section describes how to upgrade the BIOS. However, please note that upgrading the BIOS involves high risk of damage to your computer. We strongly recommend that you contact Moxa’s TS staff for assistance and obtain all necessary tools and files before attempting to upgrade.
  • Page 38 V2616 Hardware Manual BIOS Setup 2. Copy the file to the Bootable USB Disk. 3. Double click to extract the BIOS update installation file. The file includes a binary file in the form s261610.SXX and the upgrade utility named awdflash.exe. Step 3: Set up the BIOS to Boot from the USB Disk.
  • Page 39 V2616 Hardware Manual BIOS Setup 4. Press F1 to reset the system after the bios update is complete. The system should reboot at this time. 5. Please note that once the BIOS is successfully upgraded, the default BIOS values will be automatically loaded.

  • Page 40: Regulatory Approval Statement

    Regulatory Approval Statement This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
