Infusion System
System Operating Manual
Hospira, Inc.,
275 North Field Drive
Lake Forest,
IL 60045, USA
430-96527-005 (B, 2012-08)
For use with the
Hospira GemStar Pump
List 13086-04
List 13087-04
List 13088-04
Hospira, Sector 2,
Finisklin Business and
Technology Park
Finisklin, Sligo, Ireland
TM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GemStar Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Hospira GemStar Series

  • Page 1 Infusion System System Operating Manual For use with the Hospira GemStar Pump List 13086-04 List 13087-04 List 13088-04 Hospira, Sector 2, Hospira, Inc., 275 North Field Drive Finisklin Business and Lake Forest, Technology Park Finisklin, Sligo, Ireland IL 60045, USA...
  • Page 2 Hospira GemStar Pump This manual is designed for use by healthcare professionals, caregivers, and patients. The Hospira Technical Support Operations hotline is available 24 hours a day (in the USA) to provide consultation and technical assistance regarding the Hospira GemStar Pump.
  • Page 3 PURGE key Added a reference, Warning, Pages 73, 207 instructions, and index entry for reprogramming a delayed start time Updated the cause and remedy of Page 151 the NO DELAY START display message Hospira GemStar System Operating Manual...
  • Page 4: Table Of Contents

    TPN Programming Worksheet........57 Hospira GemStar System Operating Manual...
  • Page 5 Worksheet ............93 Hospira GemStar System Operating Manual...
  • Page 6 Shift Totals and History ..........135 Hospira GemStar System Operating Manual...
  • Page 7 Using the Hospira Carrying Cases ........
  • Page 8: Iec Symbols

    The GemStar Pump has been assessed and complies with the following standard; Fragile, Handle with Care IEC/EN 60601-2 (2001) Manufactured by Hospira, Inc., 275 North Field Drive, Temperature Limitation Lake Forest, IL 60045, USA Protected against vertically falling water drops.
  • Page 9 Notes viii Hospira GemStar System Operating Manual...
  • Page 10: Introduction

    Tip: A TIP contains information that makes the pump easier to use. Note: Examples are provided only to help explain a pump function and may not be clinically relevant. Graphics are for illustrative purposes only and may not reflect the actual product. Hospira GemStar System Operating Manual...
  • Page 11: Gemstar Pump Layout

    Chapter 1. Introduction GemStar Pump Layout Shown approximate size Hospira GemStar System Operating Manual...
  • Page 12 Selects menu items and enters numeric values. If two numbers appear before a menu item (e.g., 02), press both number keys to select that item. * Not all menu items are available with all modes. Hospira GemStar System Operating Manual...
  • Page 13: Gemstar Pump Components

    Top View pocket. I.V. Tubing Guide Use to hold the I.V. tubing. Battery Pack Use to connect the GemStar Connector Rechargeable Battery Pack. Battery Install two fresh, disposable Compartment AA batteries in this compartment. Bottom/Side View Hospira GemStar System Operating Manual...
  • Page 14: Therapies

    • • Weight Dosed Critical care, pediatrics • • • • mL/hr Only Simple rate programming • • Variable Time Chronotherapy • = Available Note: pain management is the only therapy available for List 13088. Hospira GemStar System Operating Manual...
  • Page 15: Gemstar Pump Features

    Review the history on the display, or download it to a printer or computer. • Speed Stores up to nine frequently used programs Chapter 10 Options Protocols in the pump’s memory for quick access. Menu Hospira GemStar System Operating Manual...
  • Page 16: Menu System

    Tip: A menu item does not have to be on the display to be selected. For example, when the Programming Menu first displays, only the first four therapies are shown. Instead of pressing the down arrow to see the other menu items, press [7] to go directly to Variable Time Programming. Hospira GemStar System Operating Manual...
  • Page 17 Only and Continuous therapies. Note: Menu items change depending on when Change Menu is viewed. Options Menu Press REVIEW PROGRAM HISTORIES KEYPAD LOCK PUMP SETTINGS SET CLOCK PRINT SPEED PROTOCOL NEXT DOSE (NOT AVAILABLE FOR LIST 13088) Hospira GemStar System Operating Manual...
  • Page 18: Operating Modes

    When the programmed therapy is complete, and during certain STOP alarm conditions, the pump automatically enters the mode. STOP Press to enter the mode at any time, except during a CHECK CASSETTE alarm. Hospira GemStar System Operating Manual...
  • Page 19: Indications For Use

    Chloroprocaine Hydrochloride USP, Lidocaine Hydrochloride USP, and Morphine Sulfate Injection USP (Preservative Free). WARNING: Delayed respiratory depression following continuous epidural administration of preservative-free morphine sulfate has been reported. Hospira GemStar System Operating Manual...
  • Page 20: Contraindications For Use

    When a proximal occlusion alarm activates, DO NOT power-off the pump. Closely supervise patients who are likely to be adversely affected by unintended operations and failures, including interrupted medication or fluid infusion. Ensure provisions for immediate corrective action are available. Hospira GemStar System Operating Manual...
  • Page 21 Use of high flow rates during infusion will minimize drug absorption. DO NOT use medications that are unstable under infusion conditions. ALWAYS use connections with Luer Lock™ fittings. Hospira GemStar System Operating Manual...
  • Page 22 ALWAYS prime the pump set to remove all air from the cassette, tubing, and injection site prior to connecting to the patient. ALWAYS disconnect the pump set from the patient prior to priming or purging. Hospira GemStar System Operating Manual...
  • Page 23 If the pump does not display the self-test or if beeps do not sound at power-on, check all power connections and install two fresh, disposable AA batteries. If the problem continues, contact Hospira Technical Support Operations before using the pump.
  • Page 24 Refer to the appropriate monitoring system documentation for setup and maintenance instructions. The GemStar Pump has been tested and found to comply with EMC/EMI limits in accordance with: Hospira GemStar System Operating Manual...
  • Page 25 IEC 60601-1-1. If in doubt, contact Hospira Technical Hospira GemStar System Operating Manual...
  • Page 26 DO NOT use abrasive cleaners or materials on the pump. Using abrasive cleaners or cleaning solutions not recommended by Hospira may result in product damage. Please comply with local disposal and recycling regulations as appropriate for disposable batteries, rechargeable battery packs, medical electronic components, and pump sets.
  • Page 27 Notes Hospira GemStar System Operating Manual...
  • Page 28: Basic Operation

    7 Select the therapy type and enter a program. Refer to the appropriate therapy chapter for detailed instructions. Note: List 13088 only delivers therapy in the Pain management Mode. 8 Press [ ] to begin delivery. START Hospira GemStar System Operating Manual...
  • Page 29: Selecting A Power Source

    (e.g., AC mains adaptor, docking station, battery pack). The pump will continue to operate on backup power if the external power source fails. Refer to the caution regarding Power Loss on page 15. Hospira GemStar System Operating Manual...
  • Page 30 5 Return the battery door to the battery compartment. 6 Turn the battery door to the right (clockwise). Ensure the battery door is secured under the slot. 7 Flip closed the tab of the battery door to lock in place. Hospira GemStar System Operating Manual...
  • Page 31 The pump will continue to operate on backup power if the external power source fails. Refer to the caution regarding Power Loss on page 15. Note: The green LED on the pump remains lit when connected to AC mains power. Hospira GemStar System Operating Manual...
  • Page 32 During charging, the battery pack is warm. If the battery pack becomes hot to the touch, IMMEDIATELY unplug AC mains power and contact Hospira Technical Support Operations Ensure two fresh, disposable AA batteries are installed for backup power when using other power sources (e.g., AC mains adaptor, docking station, battery pack).
  • Page 33 Note: The Li-Ion battery pack (List 13073-03) light is yellow while the battery pack is charging and green when the battery pack is charged or not charging. Li-Ion batteries cannot be charged when the room temperature is greater than 95°F (35°C) or less than 41°F (5°C). Hospira GemStar System Operating Manual...
  • Page 34 2 Line up the connectors on the bottom of the pump with the connectors on the docking station. 3 Slide the pump into the docking station until it snaps into place. 4 Connect the docking station to AC mains power. Hospira GemStar System Operating Manual...
  • Page 35 When the docking station is charged or not charging, the light is green. The Li-Ion docking station cannot be charged when the room temperature is greater than 104°F (40°C) or less than 41°F (5°C). Hospira GemStar System Operating Manual...
  • Page 36: Powering On The Pump

    CAUTION: If the pump does not display the self-test or if beeps do not sound at power-on, check all power connections and install two fresh, disposable AA batteries. If the problem continues, contact Hospira Technical Support Operations before using the pump.
  • Page 37 For more information on: Refer to the following pages: Setting the clock Set Clock in Chapter 10 Options Menu, on page 120. Locking the keypad Keypad Lock in Chapter 10 Options Menu, on page 116. Hospira GemStar System Operating Manual...
  • Page 38: Accessing The Programming Menu

    Tip: To enter a new program when the pump is already powered on: Press [STOP] to place the pump in STOP mode. Press [CHANGE] to display the Change Menu. Select NEW PROGRAM. The pump clears the current program and displays the Programming Menu. Hospira GemStar System Operating Manual...
  • Page 39: Programming The Pump

    The pump stores the program in memory and then SAVING PROGRAM enters mode. STOP Tip: If you enter an incorrect number during programming, press [CHANGE] BEFORE pressing [YES/ENTER] to reset the number to zero. Then enter the correct number. Hospira GemStar System Operating Manual...
  • Page 40 The UP arrow inserts a decimal point in a numeric value. When entering a numeric value during programming, press to reset the value to zero. Press to return to a previous display, to exit the Options Menu, or to exit HELP mode. Hospira GemStar System Operating Manual...
  • Page 41: Starting A New Container

    Contact a Hospira representative for more information on selecting the appropriate pump set configuration. Additional disposable components, such as air-eliminating filters and extension sets, may be added to the line as required. To use a GemStar Pump Set, follow the instructions included with the set.
  • Page 42 Chapter 2. Basic Operation A typical GemStar Pump Set is shown below: Piercing Pin Tubing Proximal End Slide Clamp Cassette Secure Lock Flow Stop (open / close Pressure-activated Anti-Siphon valve Distal End Hospira GemStar System Operating Manual...
  • Page 43 Remove protective coverings as assembly progresses. Opening the Pump Set 1 Open the GemStar Pump Set package and remove the contents. 2 Remove the protective covers from the fluid container administration port and the pump set. Hospira GemStar System Operating Manual...
  • Page 44: Loading The Cassette

    3 Line up the cassette as shown (with the flow stop button facing the pump). Hospira GemStar System Operating Manual...
  • Page 45: Releasing The Cassette

    Note: Ensure the tubing is behind the tubing guide (at the distal end). 3 Remove the cassette. Note: When the cassette is released from the pump, the cassette flow stop automatically closes, preventing free flow. Hospira GemStar System Operating Manual...
  • Page 46: Priming A Gemstar Pump Set

    3 Push down on the flow stop 6 Return the cassette to the upright open (priming position) the cassette. position. Continue priming until fluid fills the tubing. Hospira GemStar System Operating Manual...
  • Page 47 CAUTION: Ensure all four events occur when using Pain cassette latches are clearly Management therapy: visible after the cassette is installed. Refer to Loading the Complete Review of New Cassette on page 35. Program New Container Air-in-Line Alarm Hospira GemStar System Operating Manual...
  • Page 48 1 Push down on the flow stop 4 Load the cassette. close the cassette. 2 Hold the container with the administration port toward the ceiling and insert the piercing pin. 3 Ensure slide clamp is open prior to inserting cassette. Hospira GemStar System Operating Manual...
  • Page 49 If flow is observed, DO NOT use the pump set. 9 Connect the pump set to the patient-access device. 5 Program desired therapy. Hospira GemStar System Operating Manual...
  • Page 50 2 Insert the piercing pin into the 5 Ensure the CAIR (roller) clamp is container. Suspend the container open prior to inserting cassette. on an I.V. Pole. 6 Invert the cassette approximately 3 Squeeze the drip chamber until 45°. filled halfway. Hospira GemStar System Operating Manual...
  • Page 51 Refer to Loading the Cassette on page 35. 9 Push down on the flow stop close the cassette. 10 Ensure lower CAIR clamp is open prior to inserting cassette. Hospira GemStar System Operating Manual...
  • Page 52 CAUTION: When priming is complete, ensure no fluid flows at the distal end of the pump set. If flow is observed, DO NOT use the pump set. 12 Connect the pump set to the patient-access device. Hospira GemStar System Operating Manual...
  • Page 53 3 Squeeze the drip chamber until close the cassette. filled halfway. 2 Insert the piercing pin into the 4 Push down on the flow stop container. Suspend the container open (priming position) the on an I.V. Pole. cassette. Hospira GemStar System Operating Manual...
  • Page 54 Refer to Loading the Cassette on page 35. 6 Load the cassette. Note: Ensure the tubing is behind the tubing guide (at the distal end). 7 Program the desired therapy. Hospira GemStar System Operating Manual...
  • Page 55 CAUTION: When priming is complete, ensure no fluid flows at the distal end of the pump set. If flow is observed, DO NOT use the pump set. 11 Connect the pump set to the patient-access device. Hospira GemStar System Operating Manual...
  • Page 56 SAM lockbox insert for instructions. 1 If using a pump set with the 2 Open the upper and lower slide Y-extension, use the slide clamp to clamps. close off the KVO (Keep Vein Open) side of the tubing. Hospira GemStar System Operating Manual...
  • Page 57 3 Push down on the flow stop air is cleared from the pre-filled close the cassette. vial, injector, cassette, and tubing. 4 Connect the pump set to a Hospira pre-filled vial and injector. 8 Push down on the flow stop close the cassette.
  • Page 58 Refer to Loading the 12 Connect the pump set to the Cassette on page 35 patient-access device. Note: Ensure the tubing is behind the tubing guide (at the distal end). Hospira GemStar System Operating Manual...
  • Page 59 3 Push down on the flow stop open (priming position) the 6 Return the cassette to the upright cassette. position. Continue priming until fluid fills the tubing. Hospira GemStar System Operating Manual...
  • Page 60 (at the distal end). 10 Load the cassette. 11 Program the desired therapy. CAUTION: Ensure all four cassette latches are clearly visible after the cassette is installed. Refer to Loading the Cassette on page 35. Hospira GemStar System Operating Manual...
  • Page 61 CAUTION: When priming is complete, ensure no fluid flows at the distal end of the pump set. If flow is observed, DO NOT use the pump set. 15 Connect the pump set to the patient-access device. Hospira GemStar System Operating Manual...
  • Page 62: Total Parenteral Nutrition (Tpn)

    Displays information during Returns to a previous display, programming and alarm exits the Options Menu, and HELP conditions. exits the mode. Clears a numeric value (resets to zero) during programming. Hospira GemStar System Operating Manual...
  • Page 63: Tpn Programming

    9 Review the program. Press to begin review. 10 If using the key to prime the pump set, press [ ] now. PURGE PURGE WARNING: ALWAYS disconnect the pump set from the patient before priming or purging. Hospira GemStar System Operating Manual...
  • Page 64: Changing A Tpn Program

    2 As each message displays, make the desired changes or press [ ] to ENTER accept the current setting. 3 Review the program. Press to begin review. 4 Press [ ] to begin infusion. START Hospira GemStar System Operating Manual...
  • Page 65: Tpn Auto Taper Down
