Machine description – quick overview
Front view
4
Machine description – quick overview
4.1
Front view
Item Symbol
1
2
3
4
5
6
7
14
Description
0
Screw connector
Connects cooling module and welding machine
Coolant tank cap
Coolant tank
Cooling air inlet
Machine feet
Quick connect coupling, blue
Coolant supply to the welding torch
Quick connect coupling, red
Coolant return from the welding torch
Figure 4-1
099-008598-EW501
04.04.2016
