Intended use

Applications

3 Intended use
Hazards due to improper usage!
Hazards may arise for persons, animals and material objects if the equipment is not
used correctly. No liability is accepted for any damages arising from improper usage!
• The equipment must only be used in line with proper usage and by trained or expert staff!
• Do not modify or convert the equipment improperly!
3.1 Applications
These cooling modules are designed solely for cooling welding torches.
We can only guarantee smooth and trouble-free operation when used in conjunction with the welding
machines, welding torches, coolants and accessory components from our range.
3.2

General

The cooling units (pump and fan) are controlled by the welding machine only.
The welding machine automatically detects and displays a lack of coolant
(see the welding machine operating instructions).
• The cooling units are supplied with voltage by the welding machine or an external power source.
• The coolant pump is protected against overload by an overcurrent release.
• The coolant connections are realised with self-locking quick connect couplings.
• In case of incorrect coolant pressure or coolant flow the welding machine is switched off to protect the
welding torch against damage.
• The cooling units are fitted with a closed-air-circuit cooled heat exchanger. This means that the
cooling output is directly dependent on the ambient temperature. The lower the ambient temperature
and therefore the intake air temperature, the higher the cooling output.
3.2.1

For operation only with the following equipment

Welding machine
• Phoenix 335
• Taurus 335
Transport vehicle
• Trolly 55-5
12
