Johnson Controls ACC-WIFI Installation Instructions

A locking retainer clip is included to maintain the integrity of the electrical connection. Additionally,

for extra security, the locking clip helps prevent unauthorized removal of the Skyport Wi-Fi Key.

Please note that the Locking Retainer Clip along with the Skyport Wi-Fi Key will have to be removed

temporarily to insert an SD memory card.

Please refer to the steps below for installation of the Locking Clip.

Install the Locking

Clip as shown in

figure 2.

Installation Instructions

Return thermostat to its position on the backplate on the wall.

Upon successful detection of the Wi-Fi Key, this screen will appear.

Press NO to return to the home screen.

Press YES to proceed to step 4.

With the thermostat off the wall, insert the

Skyport Wi-Fi Key all the way into the

SD slot of the Touch Screen Thermostat.

The 'cut corner' of the Key's circuit board faces

up as shown in figure 1.

The Locking Clip is seated

all the way down next to the

circuit board as shown in

figure 3. Reinstall the

thermostat on the backplate.

The thermostat will scan for all

available networks. Select the

appropriate network from the

list on the display.

model ACC-WIFI
