- Page 1 Fotodiox Inc. USER MANUAL 1100 Lakeside Dr Gurnee , IL60031, United States Toll Free:(866)812-1107 Local & International: (847)201-4623 Fax: (847) 261-0295 Http://www.fotodioxpro.com...
- Page 2 FACTOR Prizmo 150/300 Introduction: Thank you for choosing the FACTOR Prizmo lighting series from Fotodiox Pro. FACTOR Prizmo lights are designed with all-aluminum frames for durability and enhanced heat dissipation. These lights have been designed using all of the features and advantages of LED lighting and our FACTORSOFT technology, creating a soft, compact and efficient flat light panel.
- Page 3 LED STUDIO LIGHT LED STUDIO LIGHT Parts Diagram: FACTOR Prizmo 150 Control panel A DMX output FACTOR Prizmo 150 Front view B DMX input A Yoke locking screw C USB port Battery B Accessory clip D Power switch DATA DMX OUT...
- Page 4 LED STUDIO LIGHT LED STUDIO LIGHT Packing List: Parts Diagram: FACTOR Prizmo 300 Front view A Yoke locking screw B Accessory clip C Front diffuser panel D Mount locking screw E Yoke FACTOR Prizmo 300 FACTOR Prizmo 300 –1PC Barn doors–1PC Power cord–1PC AC power adapter 320W –1PC DMX cable–1PC...
-
Page 5: Specifications
-4 to 113°F (-20 to 45℃) Dimensions unit:(mm) Protection IP20 LED lifetime Up to 50,000 hours 20lbs 5oz (9.2KG) Weight Dimension 18.5in x 20.4in x 7.2in (47x51.8x18.2CM) FACTOR Prizmo 150 Illuminance data: 2800K 3200K 5600K 10000K Illuminance Distance 0.5m 10090Lux 10325Lux... - Page 6 LED STUDIO LIGHT LED STUDIO LIGHT Specifications: Set up instructions: (1) Loosen the stand mount locking screw by turning counterclockwise. Place the mount on the stand or stud, Name FACTOR Prizmo 300 then turn mount locking screw clockwise to tighten in place. FACTORSOFT™...
- Page 7 LED STUDIO LIGHT LED STUDIO LIGHT Functions of the dimming knobs 4.How to use the safety cable (1)When hanging the product, always use the safety cable. (2)The safety cable is fixed through the yoke and the external fixing frame. 1.Selector Knob 5.Installing the AC power adapter* (1) The V-lock holder is pre-installed on the AC power adapter.
- Page 8 LED STUDIO LIGHT LCD display screen and the menu instruction: Indicator function description: Battery Data FOTODIOX Boot display Welcome message WELCOME TO USE 1.Battery indicator When the Battery indicator light is on, the V-lock battery is being used to power the light.
- Page 9 LED STUDIO LIGHT LED STUDIO LIGHT Menu function instruction: 5.Filters Filter comparison table 1.HSI HUE:0-360゜ -----------Adjusted by the Selector knob Fotodiox No. Rosco Description Fotodiox No. Rosco Description SAT:0-100%----------Adjusted by the SAT knob 0328 R320 9203 07 CYAN INT:0-100%----------Adjusted by the Intensity knob...
- Page 10 LED STUDIO LIGHT LED STUDIO LIGHT 12.DMX connection: 6.Scenes When using DMX function, connect the DMX cable to the DMX console (see the figure below). Set the *Model One DMX address to desired address for control on the DMX console. (Corresponding CCT mode) CCT:2800-10000 K INT: 0-100% *Model Two light...
