Draminski Animal profi 2 Manual

Portable ultrasound scanner with mechanical probes
Hide thumbs
Table of Contents

Advertisement

Quick Links

DRAMIŃSKI Animal profi
W
D Eh >
EN08.02.2019

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Animal profi 2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Draminski Animal profi 2

Summary of Contents for Draminski Animal profi 2

  • Page 1 DRAMIŃSKI Animal profi D Eh > EN08.02.2019...
  • Page 2 We wish you and all the users of our product every success with your patients and we are convinced that with our product you will be able to serve your patients well. DRAMINSKI S.A. company will be happy to hear any comments from our clients with regard to the device and this instruction.

  • Page 3: Table Of Contents

    DRAMIŃSKI Animal profi 2 user manual Table of contents Introduction ......................4 Construction of DRAMIŃSKI Animal profi 2 ultrasound scanner ......7 III. Preparing the device for operation ..............15 IV. The menu structure ..................... 16 Most frequently used functions ................19 VI.

  • Page 4: Introduction

    DRAMIŃSKI Animal profi 2 user manual I. Introduction Information on the user manual for the device The goal of this User Manual is to identify the technical characteristics of the device. It has been written in an accessible way to facilitate, as much as possible, the use of information contained in it.
  • Page 5 DRAMIŃSKI Animal profi 2 is a diagnostic device used to monitor illnesses and physiological conditions through the application of 2D (black and white) imaging. With Animal profi 2 you can examine abdominal cavity organs and carry out urological and gynaecological...
  • Page 6 Explorer type transport casing with a foam insert A carrying strap and a waist belt User Manual Ultrasound gel (250ml) Any additional accessories to be used with the Animal profi 2 ultrasound scanner are available after a consultation with the supplier.

  • Page 7: Construction Of Dramiński Animal Profi 2 Ultrasound Scanner

    DRAMIŃSKI Animal profi 2 user manual II. Construction of DRAMIŃSKI Animal profi 2 ultrasound scanner The device comprises several main elements: 1. A casing with a membrane keyboard and LCD LED display. 2. Ultrasonic probe connected to a multi pin connector.
  • Page 8 DRAMIŃSKI Animal profi 2 user manual View and description of casing elements membrane keyboard LCD monitor with LED with a monitor window display USB 2.0 connector to transmit images to external memory via special adapter silicone gasket carrying strap casing body made...
  • Page 9 DRAMIŃSKI Animal profi 2 user manual View of the housing rear wall with the pack installed ultrasonic probe connector socket (port) removable external battery pack lock of the battery pack mount system system for mounting the pack on the casing...
  • Page 10 DRAMIŃSKI Animal profi 2 user manual 2. Ultrasonic probe Probe (head) is an important element of the device. DRAMIŃSKI Animal profi 2 ultrasound scanner has one port but it is compatible with two types of mechanical, sectorial probes, they are:...
  • Page 11 DRAMIŃSKI Animal profi 2 user manual Li-Ion type battery pack Connecting the battery Batteries are expected to last for 500 charging cycles. Owing to the use of modern, high capacity batteries (3.1Ah), it's possible to work up to 4 hours with one battery.
  • Page 12 DRAMIŃSKI Animal profi 2 user manual 5. Charger For charging batteries use an appropriately adapted charger powered by a 110-240V/ 60Hz power supply and equipped in cables and a coloured diode signalling the charging status. Attention: To charge the pack use only an original charger delivered with the ultrasound scanner.
  • Page 13 DRAMIŃSKI Animal profi 2 user manual Membrane keyboard and button layout The keyboard buttons are placed in its upper part to allow for operating the ultrasound scanner with a left or right hand. A double function was assigned to most buttons to enable both access to various options as well as easier and faster setting of image parameters (the so called fast access).
  • Page 14 DRAMIŃSKI Animal profi 2 user manual OK/MENU - 1. opening the main menu and accepting the selected option or settings 2. approving the position of the marker while dimensioning navigation keys are assigned to the following operations: navigating the menu and setting parameter values "Cineloop"...

  • Page 15: Preparing The Device For Operation

    Monitor view Messages and information shown on the screen while working with the device. An example of a Animal profi 2 screenshot with a frozen image and description of messages and displayed information: Information bar showing current settings: date and time, type of probe, level of G1 and G2...

  • Page 16: The Menu Structure

    DRAMIŃSKI Animal profi 2 user manual DRAMIŃSKI Animal profi 2 ultrasound scanner is fitted with a single multi pin connector for connecting the probes. Note! The probe replacement must be carried out at the unit switched off. In order to change the probe, unscrew and remove the connector, and then plug the new one and re-tighten the connector.
  • Page 17 DRAMIŃSKI Animal profi 2 user manual In some options messages (hints) are displayed, suggesting which buttons may be used to set or change a selected parameter. Main menu is opened with the use of button. The menu has several positions with...
  • Page 18 DRAMIŃSKI Animal profi 2 user manual Additional menu opened with the button makes it possible to manage images and image sequences (cine loop), i.e. saving, loading, transferring via USB, deleting and dimensioning. (besides this menu provides access to the imaging mode selection position).

  • Page 19: Most Frequently Used Functions

    DRAMIŃSKI Animal profi 2 user manual V. Most frequently used functions The table below shows basic functions that are used most frequently when working with the ultrasound scanner as well as keyboard buttons to activate them: The ultrasound scanner is switched on by pressing the ON/OFF button.
  • Page 20 DRAMIŃSKI Animal profi 2 user manual The function allowing for displaying the maximum 256 of the recent frames from the moment the image is frozen. By using Cineloop the navigation buttons, the user may scroll manually frame by frame the sequences of the completed examination or may automaticallyplay forward or backwards cine loop by using the buttons.
  • Page 21 DRAMIŃSKI Animal profi 2 user manual Image freeze This is the basic function used when examining animals. To freeze the image the user should press one of the buttons: The message FREEZE will appear at the bottom of the information bar. Pressing one of the above buttons again will immediately activate imaging.
  • Page 22 The scope of penetration may be set from the option available in the Main menu/Settings. MHz – setting the head frequency Animal profi 2 ultrasound scanner cooperates with broadband (multifrequency) probes. The signal frequency can be changed through the options in the menu or in a simple, fast way using the navigation buttons You can also set the level of MHz by selecting this option in the menu.
  • Page 23 DRAMIŃSKI Animal profi 2 user manual Example of a screen with gamma level adjustment Zoom (enlargement) During active imaging or freezing, 100% of the image size may be enlarged (or reduced) within the range from – 60% to + 200%. At the bottom of the screen a message box appear informing about the set enlargement, which will automatically disappear after 2 seconds or after confirming the setting with OK button.
  • Page 24 Image presentation option in reverse greyscale. This option is used less frequently. Postprocessing – digital image processing The Animal profi 2 ultrasound scanner is a miniaturized, yet a technologically advanced device. To optimize the quality of image and improve its diagnostic value, the user may choose the option of real time digital processing of displayed or frozen images or images and cine loops loaded from the memory.
  • Page 25 DRAMIŃSKI Animal profi 2 user manual System The option in the Main menu which enables setting additional available parameters that are used less frequently: Switch left/right/ Date / Time Brightness Language Factory settings Automatic power off Presets save Switch left/right/ This option allows for changing the image displayed from the head to the right or left hand side to adjust it to the actual side being scanned.
  • Page 26 DRAMIŃSKI Animal profi 2 user manual After choosing a language and pressing OK the system automatically switches into the selected language version. Set the head It is very rarely used option. It is performed at the service workshop or in the event that mechanical displacement of the head index happens, for example, after a strong blow or fall to the ground.
  • Page 27 DRAMIŃSKI Animal profi 2 user manual ultrasound scanner off and then restarting it, the selected preset does not change. Every modification of parameter results in exiting the preset and the preset name will not be displayed. B+B mode Attention! ESC – fast access. Holding the button for about 1 second results in quick start- up of the B+B mode.
  • Page 28 DRAMIŃSKI Animal profi 2 user manual will immediately freeze the moved image. To unfreeze the image in an active window, use "Freeze" buttons. B+M mode This imaging mode reflects the movement of individual structures and tissues as a function of time with simultaneously integrated B image.
  • Page 29 DRAMIŃSKI Animal profi 2 user manual Position of the marker is confirmed with the "OK” button. When position is confirmed, another red marker appears, which can be set in an appropriate place to measure the distance between a pair of markers. After pressing OK a new cursor appears and the distance between another pair can be measured.
  • Page 30 DRAMIŃSKI Animal profi 2 user manual most comfortable method of measuring the volume is using the B+B mode and taking relevant measures on a frozen image. Measurements – Age tables (foetus age) After selecting this option and checking the animal type and species from the available list, the additionally calculated foetus age will be displayed on the information bar, expressed in days.
  • Page 31 DRAMIŃSKI Animal profi 2 user manual Additional menu - managing images and cine (saving in the memory and loading onto the screen, searching, sending to the pendrive and cancelling images and cine loops) After freezing the user may save in the memory a single image or the entire sequence of 256 frames as well as load onto the screen already recorded images and cine loops.
  • Page 32 DRAMIŃSKI Animal profi 2 user manual Screen view with the list of saved images or cine loops and a preview to a checked image Searching for images and cine loops from the list Images and cine loops saved in the memory and included in the list may be searched by providing a string of signs, on condition that such a description was created during the saving procedure.
  • Page 33 DRAMIŃSKI Animal profi 2 user manual USB 2.0 adapter for connecting external storage carrier of a pen-drive type Images and cine loops saved in the memory and included in the list may be sent to the external disc (pendrive). For this purpose, an external carrier should be attached to the USB micro connector located on the side of the casing (the message "USB On"...
  • Page 34 DRAMIŃSKI Animal profi 2 user manual cine loop it will be a number of the frame recompiled to the Avi form and being currently sent). Delete image/cine Images and cines that are saved in the memory and listed may be deleted any time. To cancel elements from the list, the user prepares them in a similar way as when sending them.

  • Page 35: Technical Data

    0,71 A Attention! If storage temperature happens to have fallen below 5° C, the head should be warmed up before turning the device on. Using Dramiński Animal profi 2 interchangeably in extreme temperatures has an adverse effect and may cause damage.

  • Page 36: Charging Batteries

    Owing to the use of high capacity batteries, it's possible to work long hours with one battery. (over 4 hours). At the bottom of the screen, Dramiński Animal profi 2 has a graphic indication of battery status. When the indicator is shortened or changes from green to yellow, it means that the battery will be discharged in about 1.5 hours.
  • Page 37 Attention! A charger is an auxiliary device used solely for the purpose of battery charging. It is not an integral part of DRAMIŃSKI Animal profi 2 ultrasound scanner, used during operation of the device.

  • Page 38: Operational And Technical Comments

    DRAMIŃSKI Animal profi 2 user manual VIII. Operational and technical comments Prepare the device and accessories before starting the work. • Turn the power on and check if low battery is signalled. • There is a special micro-valve implemented inside the USB connector for pressure compensation.

  • Page 39: Guarantee

    DRAMIŃSKI Animal profi 2 user manual If none of the basic actions helps, please contact DRAMIŃSKI S.A. service ultrasound@draminski.com centre, tel. +48 89 527 11 30 or email: IX. Guarantee The manufacturer hereby grants the buyer a 24-month guarantee for a trouble-free operation of the product used in accordance with the attached user manual.
