CARRiAgE BOLt (1x)
hEx kEy (1x)
Mighty MOunt (1x)
LOCking SkEwER (1x)
IMPORTANT WARNING
it iS CRitiCAL thAt ALL yAkiMA RACkS AnD ACCESSORiES BE PROPERLy AnD SECuRELy AttAChED tO yOuR vEhiCLE. iMPROPER AttAChMEnt COuLD RESuLt in An
AutOMOBiLE ACCiDEnt, AnD COuLD CAuSE SERiOuS BODiLy inJuRy OR DEAth tO yOu OR tO OthERS. yOu ARE RESPOnSiBLE FOR SECuRing thE RACkS AnD ACCESSORiES
tO yOuR CAR, ChECking thE AttAChMEntS PRiOR tO uSE, AnD PERiODiCALLy inSPECting thE PRODuCtS FOR ADJuStMEnt, wEAR, AnD DAMAgE. thEREFORE, yOu MuSt READ AnD
unDERStAnD ALL OF thE inStRuCtiOnS AnD CAutiOnS SuPPLiED with yOuR yAkiMA PRODuCt PRiOR tO inStALLAtiOn OR uSE. iF yOu DO nOt unDERStAnD ALL OF thE inStRuCtiOnS
AnD CAutiOnS, OR iF yOu hAvE nO MEChAniCAL ExPERiEnCE AnD ARE nOt thOROughLy FAMiLiAR with thE inStALLAtiOn PROCEDuRES, yOu ShOuLD hAvE thE PRODuCt inStALLED By
A PROFESSiOnAL inStALLER.
1033569C-1/12
SnAP AROunD (1x)
POD SCREwS (3x)
POD (1x)
whEEL tRAy (1x)
COvER (1x)
tuBE SLEEvE (1x)
wREnCh (1x)
Min. - Max.
Type of
Crossbar
Rack
Spread*
Load
1 or more
32" - 50"
bikes
81cm - 127cm
DO nOt ExCEED RACk wEight LiMitS!
*CROSSBAR SPREAD
Your crossbar spread is
the distance between
the crossbars.
Designed for forks
with safety tabs.
Off-road driving is
Forks with
not recommended.
Safety Tabs
Limits
35 lbs./bike
16 kg/bike
Part #1033569 Rev.C
