1677 SONET Link
Installation Practices
PN 3EM13849AD 01
R05.00, Issue 01, May 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1677 SONET Link and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Alcatel 1677 SONET Link

Summary of Contents for Alcatel 1677 SONET Link

  • Page 1 1677 SONET Link Installation Practices PN 3EM13849AD 01 R05.00, Issue 01, May 2006...
  • Page 2 NOTICE This manual applies to 1677 SONET Link R05.00 software. Release notes describing revisions to this software may impact operations described in this manual. This transfer of commodities, technology, or software, if from the United States, is an export in accordance with the U.S.

  • Page 3: Table Of Contents

    Mount Filler Panels and Brackets to Rack ........2-23 © Alcatel 2002-2006 - All Rights Reserved...
  • Page 4 Test 1677 SONET Link Wiring Continuity ....... . . 2-121...
  • Page 5 3EM13849AD Issue 01, May 2006 Chart-31 Install Trim (Config Option 1) ......... . . 2-133 Chart-32 Install PDU-Quad Labels .
  • Page 6 3EM13849AD Issue 01, May 2006 Table of Contents...
  • Page 7 Unpack 1677 SONET Link ........
  • Page 8 1677 SONET Link Rear Connectors ........
  • Page 9 3EM13849AD Issue 01, May 2006 Figure 24-2. Connect Data Terminal to TC Console Port....... . 2-114 Figure 24-3.
  • Page 10 3EM13849AD Issue 01, May 2006 List of Figures viii...
  • Page 11 Clock Cable Routing ..........2-76 Table 26-A. Continuity Test List From 1677 SONET Link Location To Office Location ..2-122 Table 28-A.
  • Page 12 3EM13849AD Issue 01, May 2006 List of Tables...

  • Page 13: Introduction

    Issue 01, May 2006 1677 SONET Link Installation Overview INTRODUCTION The 1677 SONET Link is a member of Alcatel's family of Synchronous Optical Network (SONET) products. This manual provides installation procedures for the 1677 SONET Link and its ancillary equipment. Here,...

  • Page 14: Installing Equipment

    Define procedures to follow to ensure that the fuse designation and fuse records are checked with the proper drawing before any fuse is removed. • Identify the time of day or night the removed equipment is to be restored. 1677 SONET Link Installation Overview...

  • Page 15: Installation Tools

    An approved copy of the MOP is available and posted for review at the job site at all times. Installation Tools To properly install Alcatel SONET equipment, the following tools 1.10 should be available. Unique tools specific to a given task are listed in the installation section covering that task.

  • Page 16: Recommended Tools List

    3EM13849AD Issue 01, May 2006 Recommended Tools List Refer to the following list for recommended tools: 1.11 • 1677 SONET Link reference manuals • Safety glasses and ear protection • Static protection accessories – Strap, wrist ground, PN 055-9357-000 –...
  • Page 17 Tin snips • Pinch bar • Vacuum cleaner, High Efficiency Particulate Arrester (HEPA) • Volt-ohm meter—Western Electric KS-14510, Triplet 630, or equivalent • Audible continuity checker—Ideal 61-030, Hunter Tools 2647, or equivalent • Optical power meter 1677 SONET Link Installation Overview...

  • Page 18: Related Documentation

    1677 SONET Link Maintenance and Trouble Clearing manual (PN 3EM13853AD) • 1677 SONET Link Commands and Messages manual (PN 3EM13852AD) • 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) • 1677 SONET Link Address and Location Guide (PN 3EM13854AB) 1677 SONET Link Installation Overview...

  • Page 19: Safety Awareness

    Alcatel 1677 SONET Link in it. For approved methods of securing the equipment rack, read the equipment- rack installation instructions or contact the equipment-rack manufacturer.

  • Page 20: Laser Precautions

    Possibility of personal injury. A dc-power source provides high energy, which can cause serious injury or equipment damage. Only Alcatel qualified personnel should connect the dc power to the Alcatel 1677 SONET Link. To prevent serious injury or equipment damage, make sure the power source cables are de-energized before handling or connecting them to the node.
  • Page 21 Never connect an unterminated optical cable to a fiber-optic transmitter. Always connect fiber-optic cables to fiber-optic receivers, test sets, or some other termination first. 1677 SONET Link Installation Overview...
  • Page 22 3EM13849AD Issue 01, May 2006 Figure 2-1. Manufacture Date Label (Equipment Shelf) REAR VIEW OF 1677 GENERIC SHELF ASSEMBLY LABEL GENERIC CLEI LABEL 677-0246-1 031805 1677 SONET Link Installation Overview 1-10...
  • Page 23 3EM13849AD Issue 01, May 2006 Figure 2-2. Danger and Manufacture Date Labels (Modules) LASER WARNING LABEL LASER MN LABEL STATUS PART NUMBER SERIAL LABEL NUMBER OC48 LABEL REACH/ FIBER-TYPE LABEL 677-0317-1 031805 1677 SONET Link Installation Overview 1-11...
  • Page 24 3EM13849AD Issue 01, May 2006 1677 SONET Link Installation Overview 1-12...

  • Page 25: Electrostatic-Sensitive Devices

    The following items are examples of ESS devices: • MOS (Metal Oxide Semiconductor) capacitors, transistors, Integrated Circuits (ICs) • CMOS (Complementary Metal Oxide Semiconductor) transistors, ICs • JFET (Junction Field Effect Transistors) • IGFET (Insulated Gate Field Effect Transistors) 1677 SONET Link Installation Overview 1-13...

  • Page 26: Handling Modules

    Do not handle printed circuit board or components unnecessarily. Use plastic handle. • Do not use synthetic bristled brushes or acid brushes to clean modules. • Handle failed modules with same precautions as good modules. 1677 SONET Link Installation Overview 1-14...

  • Page 27: Repairing Modules

    • Only antistatic (metallized) desoldering tools should be used. ESS devices are protected when properly packaged in conductive or antistatic packaging. Acceptable packaging is marked as either conductive or antistatic. 1677 SONET Link Installation Overview 1-15...
  • Page 28 3EM13849AD Issue 01, May 2006 1677 SONET Link Installation Overview 1-16...

  • Page 29: Product Support Information

    50 states and Canada. To report quality issues, call 800-553-4056. An operator will take the information and have an Alcatel Quality Assurance Representative respond during normal business hours (8:00 a.m. to 5:00 p.m. Central Time, Monday through Friday).
  • Page 30 Training Equipment training is available to all customers. Crafts and maintenance personnel who are trained by Alcatel's Training department can expect more effective assistance if they need to call the Technical Assistance Center. Regularly scheduled courses are available at the training facilities in Plano, Texas.

  • Page 31: Technical Assistance Center

    Customers can expect effective telephone assistance when their crafts and maintenance personnel have been trained by Alcatel's Training department and are equipped with adequate test equipment, spares, and documentation at the site. For technical assistance, call customer service telephone support.

  • Page 32: Repair And Return Services

    These services may or may not be billable to a customer. This depends on several factors such as what type of Service Level Agreement a customer has with Alcatel, the age of the product, etc. Repair and Return Services As part of a comprehensive technical support program, Alcatel 4.18...

  • Page 33: Service Center

    Order number the equipment was purchased against and approximate date of purchase Service Center The Service Center tests, repairs, and modifies all modules (both in 4.24 and out of warranty). Modules received for repair or modification are returned promptly. 1677 SONET Link Installation Overview 1-21...
  • Page 34 RA number. 4.25 Notification to the Service Center and issuance of an RA number by Alcatel personnel must be made prior to shipment of parts. The following information must be furnished with the request for return authorization: •...

  • Page 35: Installation And Maintenance Services

    Field service from Alcatel offices nationwide is available if a 4.28 maintenance contract is selected. Alcatel field service is well-suited for private networks of any size. For a fixed annual fee, Alcatel provides prompt response to service calls and provides scheduled preventive maintenance, including FCC-required measurements and record keeping.
  • Page 36 Factory-trained service technicians are qualified on similar systems 4.29 before they are allowed to maintain customer equipment. They have direct access to additional technical support around the clock and to all necessary tools and test equipment. 1677 SONET Link Installation Overview 1-24...

  • Page 37: Unpack And Inspect Equipment

    Issue 01, May 2006 Chart-1 Unpack and Inspect Equipment PURPOSE Follow this procedure to unpack and inspect the 1677 SONET Link and to report any shipping damage or missing parts. GENERAL This procedure covers both the 18RU and 15RU shelf types.
  • Page 38 Inspect 1677 SONET Link chassis and its card cage area for visible damage. If damage is visible, contact Alcatel to report damage and to find out what to do next. Remove four screws at the base of the shelf to release it from the shipping base.
  • Page 39 Chart-1 3EM13849AD Issue 01, May 2006 Figure 1-1. Unpack 1677 SONET Link CARDBOARD SLEEVE AIR-PLENUM TRAY KIT BAGGED ITEMS INCLUDED WITH SHELF: ACCESSORY CARTON CABLE ASSEMBLIES (2), CONTAINS: COIL CORD, SCREWS, ESD WRIST STRAP, WRIST STRAP CONSOLE CABLE MOUNTING SCREW KIT,...
  • Page 40 Chart-1 3EM13849AD Issue 01, May 2006 Unpack and Inspect Equipment...

  • Page 41: Prepare Floor

    The 26 in. wide equipment racks are installed on 36 in. centers. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details.
  • Page 42 Chart-2 3EM13849AD Issue 01, May 2006 STEP PROCEDURE Observe the following guidelines: Verify that layouts of floor, ceiling, and walls are as indicated in applicable drawings and specifications. Verify that area dimensions and location of reference points correspond to floor plan.
  • Page 43 Chart-2 3EM13849AD Issue 01, May 2006 Figure 2-1. Rack Footprint 15.5 FRONT RACK FOOTPRINT ALL DIMENSIONS IN INCHES 677-0287-1 032405 Prepare Floor...
  • Page 44 Chart-2 3EM13849AD Issue 01, May 2006 Figure 2-2. Rack (PN 1AD014120032) 5.00 0.50 21.50 1.75 USE TEMPLATE TO MARK FLOOR. 22.31 15.63 4.75 84.00 5.25 10.09 17.25 25.94 RACK FOOTPRINT REMOVABLE COVER 5.91 25.94 7.00 ALL DIMENSIONS IN INCHES 677-0318-1 031805 Prepare Floor...
  • Page 45 Chart-2 3EM13849AD Issue 01, May 2006 PREPARE FOR RACK INSTALLATION Rack design is 5.00 in. extruded steel channel with 43 vertical EIA mounting increments with 12-24 tapped holes. Tapped hole pattern provides for mounting shelf assemblies and ancillary equipment on front of channels and rack rear covers. Racks are typically installed on concrete floors;...
  • Page 46 Chart-2 3EM13849AD Issue 01, May 2006 Engage rotation mode, then drill until chuck is within 1/16 in. above concrete surface. See figure 2-3. Stop tool and lift approximately 1 in. to disengage impact action, then start tool and withdraw anchor. Disengage rotation action.
  • Page 47 Follow job floor plan, and mark equipment locations on floor with chalk line. Follow chalk line to mark front baseline and end of rack. Lay out 1677 SONET Link system template (PN 3EM19359AAAAHCZZA, single rack layout). Use felt-tipped marking pen and template to mark location of mounting holes.
  • Page 48 Chart-2 3EM13849AD Issue 01, May 2006 Drop plumb bob through drilled holes. Use felt-tipped marking pen to mark position on concrete floor. Remove floor tiles to gain access to concrete floor. To install floor anchors on concrete floor, go to step 10. Uni-Strut Floor Anchor System Use felt-tipped marking pen and template to mark location of mounting holes.

  • Page 49: Install Racks

    1677 SONET Link shelves can be equipped in one rack, each shelf is an independent 1677 SONET Link system. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. Install Racks...
  • Page 50 Chart-3 3EM13849AD Issue 01, May 2006 Figure 3-1. Config Option 1 (Front) SHELF 2 SHELF 1 677-0378-1 020106 Install Racks 2-14...
  • Page 51 Chart-3 3EM13849AD Issue 01, May 2006 Figure 3-2. Config Option 2 (Front) SHELF 2 SHELF 1 677-0379-1 020106 Install Racks 2-15...
  • Page 52 Chart-3 3EM13849AD Issue 01, May 2006 RECOMMENDED TOOLS Carpenter’s level, heavy duty Heavy-duty extension cord (50 ft.) Foot-pound torque wrench Insulated trouble lamp (droplight—Duralamp, or equivalent) Pinch bar Shims (0.06 in., 0.09 in., 0.012 in.) Socket set, 3/8 in. drive with ratchet handle and extensions Steel measuring tape (50 ft.) Wrenches (3/8 to 11/16 in.), open- and box-end combination STEP...
  • Page 53 Chart-3 3EM13849AD Issue 01, May 2006 Carefully position frame over mounting holes on floor. Use hardware supplied in rack mechanical kits to secure rack to floor. Secure top of rack to overhead superstructure. See figure for typical overhead uni- strut support assembly. Install but do not tighten anchor bolts.
  • Page 54 Chart-3 3EM13849AD Issue 01, May 2006 Install Racks 2-18...

  • Page 55: Install Overhead Rack Support

    This chart provides instructions to install overhead rack supports. GENERAL Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS Insulated trouble lamp Socket set, 3/8 in.
  • Page 56 Chart-4 3EM13849AD Issue 01, May 2006 Figure 4-1. Typical Overhead Rack Support WASHER OVERHEAD UNI-STRUT SUPPORT BAR 5/8-11 STOCK EQUIPMENT FRONT SPACE 677-0323-1 031805 Check level and alignment of frame at base, top, and both sides. When necessary, insert shims under base to correct leveling. Tighten and torque floor anchor bolts to 80 ft-lbs.

  • Page 57: Route And Connect Frame-Ground Cable

    PURPOSE This chart provides instructions to route and connect frame-ground cable to equipment rack. GENERAL For more detailed information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 03. RECOMMENDED TOOLS Antioxidation compound such as NO-OX-ID...
  • Page 58 Chart-5 3EM13849AD Issue 01, May 2006 Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 03, to connect frame-ground cable. STOP. This procedure is complete. Route and Connect Frame-Ground Cable 2-22...

  • Page 59: Mount Filler Panels And Brackets To Rack

    For more detailed information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS Phillips screwdriver, #2 ×...
  • Page 60 Mount middle filler panel (PN 3EM12177AC) to front of rack such that press nuts face towards rear of rack (when DS1 splitters are installed in a later procedure, they will be installed on the front-facing side of the filler panel). Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 04.
  • Page 61 501-A for proper bracket orientation. Mount tie brackets (PN 3EM11696AB) to rack at rack increments 2, 5, 9, 15, 23, 28, 34, and 41 on both sides of rack. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 05, detail 501-B for proper bracket orientation.
  • Page 62 Chart-6 3EM13849AD Issue 01, May 2006 Mount Filler Panels and Brackets to Rack 2-26...

  • Page 63: Mount 1677 Sonet Link Chassis And Pdu-Quad In Rack

    Follow this procedure to mount the 1677 SONET Link chassis in an equipment rack. GENERAL Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS Phillips screwdriver, #2 ×...
  • Page 64 If config option 1, go to step 7. If config option 2, go to step 12. Is 1677 SONET Link chassis being installed shelf 1 (bottom of rack) or shelf 2 (top of rack)? If shelf 1, go to step 8.
  • Page 65 Install remaining screws in mounting flanges or mounting brackets and tighten all screws using a #2 Phillips screwdriver. Is there another 1677 SONET Link to install in same equipment rack? If yes, go to step 4. If no, go to step 20.
  • Page 66 032405 Install PDU-Quad Remove PDU-Quad from packing material. Position PDU-Quad in rack increment 1. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 06. Ensure that bottom edge of each mounting bracket is aligned between two mounting- hole patterns (between 1/2 in.

  • Page 67: Unseat Modules

    This procedure is used to unseat modules in a 1677 SONET Link. GENERAL Refer to the 1677 SONET Link Address and Location Guide (PN 3EM13854AB) for module locations. Modules are not shipped installed; they are shipped in individual electrostatic-sensitive containers.
  • Page 68 Chart-8 3EM13849AD Issue 01, May 2006 While pulling ejector handle down, push interlock switch (see figure 8-1) to right. Using a Phillips screwdriver, loosen two captive thumbscrews on module (see figure 8-2). WARNING: Possibility of equipment damage. To prevent thumbscrew damage, do not use a power screwdriver to loosen thumbscrews.
  • Page 69 Chart-8 3EM13849AD Issue 01, May 2006 Figure 8-1. System Module Interlock (Detail) LEVER FULLY LATCHED LIFT INTERLOCK WHILE PULLING EJECTOR AFTER UNSCREWING LEVER UP (1). HANDLE DOWN (2a), PUSH THUMBSCREWS, PUSH INTERLOCK SWITCH EJECTOR HANDLE OUT (2b). UP (3). 677-0272-1 050505 Figure 8-2.
  • Page 70 Chart-8 3EM13849AD Issue 01, May 2006 Figure 8-3. System Module Ejector Handles (detail) 2 inches Ejector AL TH IN -U AL TH AL TH IN -U IN -U AL TH AL TH IN- US IN- US IN- US AL TH AL TH IN- US IN- US...

  • Page 71: Connect Power Cables Between Pdu-Quad And 1677 Sonet Link

    102204 Remove clear panel from rear of PDU-Quad. At power panel of each 1677 SONET Link installed in rack, set Power A and Power B switches to OFF. See figure 9-2. Connect Power Cables Between PDU-Quad and 1677 SONET Link...
  • Page 72 050106 Using a #2 Phillips screwdriver, remove transparent protective cover from Power A and Power B power connections (see figure 9-2) from each 1677 SONET Link installed in rack. Run and tie down power cables from PDU-Quad to each 1677 SONET Link installed in rack.

  • Page 73: Route And Terminate Office Battery Power Cables

    For more detailed information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS...
  • Page 74 Chart-10 3EM13849AD Issue 01, May 2006 DANGER: Possibility of personal injury. Exercise care during the following test; exposed voltage of up to -56 V dc might be present on terminal. Verify that all PDU-Quad fuses are not installed. See figure 10-1. Figure 10-1.
  • Page 75 Route cables up rack and tie power cables to the outside facing surface of cable tie brackets. Eight cable tie brackets are on each side of rack. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 08, detail 802-A.
  • Page 76 Connect lug of office B2-battery power cable to B2-battery power terminal block on PDU-Quad. Tie down power cable according to local office practice. Attach loose end of PDU-Quad frame ground cable to rack. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 08, figure 803.

  • Page 77: Verify Pdu-Quad Ground

    GENERAL Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. REQUIRED TOOL...
  • Page 78 Chart-11 3EM13849AD Issue 01, May 2006 WARNING: Possibility of equipment damage. Each power feed from a source (-48 V dc and Return) requires a 48-amp dc-rated fast-trip circuit breaker or fuse and disconnects. Circuit breakers or fuses must meet applicable local and national electrical safety codes and be approved for the intended application.
  • Page 79 If yes, go to step 15. If no, go to step 14. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) power and ground distribution drawings for battery return paths, and verify there are no shorts to frame ground. Go to step 12.
  • Page 80 If yes, go to step 18. If no, go to step 17. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) power and ground distribution drawings for battery return paths, and verify there are no shorts to frame ground. Go to step 15.
  • Page 81 Chart-11 3EM13849AD Issue 01, May 2006 Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) power and ground distribution drawings for battery return paths, and verify there are no shorts to frame ground. Go to step 21. Use dmm to measure continuity from PDU-Quad A1 power to B1 power.
  • Page 82 Chart-11 3EM13849AD Issue 01, May 2006 Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) power and ground distribution drawings. Include analysis of fan assembly as a point of failure during troubleshooting. Go to step 33. Is rack equipped with AC outlet? If yes, go to step 37.
  • Page 83 If yes, go to step 49. If no, go to step 48. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) power and ground distribution drawings for battery return paths, and verify there are no shorts between A2 and B1 returns. Go to step 46.
  • Page 84 If yes, go to step 61. If no, go to step 60. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) power and ground distribution drawings for battery return paths, and verify there are no shorts between B1 return feeder and CO ground. Go to step 58.

  • Page 85: Verify Pdu-Quad Power

    The acceptable voltage range is between -40 V dc and -57.5 V dc. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details.
  • Page 86 Chart-12 3EM13849AD Issue 01, May 2006 Figure 12-1. PDU-Quad (Front View) BLOWN TPA FUSE INDICATOR LEDS BLOWN TPA FUSE INDICATOR LEDS FRONT VIEW 677-0254-1 102204 BDFB Power A1 and PDU-Quad At CO BDFB panel, switch A1 BDFB breaker to ON. Ensure A2, B1 and B2 BDFB breakers are OFF.
  • Page 87 Chart-12 3EM13849AD Issue 01, May 2006 Figure 12-2. PDU-Quad (Rear view) REAR VIEW 677-0255 102204 Is voltage present? If yes, go to step 12. If no, go to step 10. Use dmm to measure voltage between B2 INPUT, 48V and B2 INPUT, RETURN power-ground distribution blocks.
  • Page 88 Chart-12 3EM13849AD Issue 01, May 2006 Use dmm to measure voltage between A1 INPUT, -48V and A1 INPUT, RETURN power-ground distribution blocks. See figure 12-2. Is voltage present? If yes, go to step 22. If no, go to step 18. Use dmm to measure voltage between B1 INPUT, -48V and B1 INPUT, RETURN power-ground distribution blocks.
  • Page 89 Chart-12 3EM13849AD Issue 01, May 2006 Use dmm to measure voltage between A1 INPUT, -48V and A1 INPUT, RETURN power-ground distribution blocks. See figure 12-2. Is voltage present? If yes, go to step 32. If no, go to step 30. Use dmm to measure voltage between A2 INPUT, -48V and A2 INPUT, RETURN power-ground distribution blocks.
  • Page 90 Chart-12 3EM13849AD Issue 01, May 2006 Use dmm to measure voltage between A2 INPUT, -48V and A2 INPUT, RETURN power-ground distribution blocks. See figure 12-2. Is voltage present? If yes, go to step 42. If no, go to step 43. Cable routing problem exists between BDFB and PDU-Quad.
  • Page 91 Chart-12 3EM13849AD Issue 01, May 2006 Replace clear panel on back of PDU-Quad. STOP. This procedure is complete. Verify PDU-Quad Power 2-55...
  • Page 92 Chart-12 3EM13849AD Issue 01, May 2006 Verify PDU-Quad Power 2-56...

  • Page 93: Verify Frame Ground

    Issue 01, May 2006 Chart-13 Verify Frame Ground PURPOSE This procedure is used to verify frame grounding of equipment rack and 1677 SONET Link chassis. STEP PROCEDURE DANGER: Possibility of personal injury. This equipment might contain aluminum electrolytic capacitors that present a potential safety hazard when overstressed.
  • Page 94 Chart-13 3EM13849AD Issue 01, May 2006 Is measured value of resistance above 50 ohms? If yes, troubleshoot and go to step 5. If no, go to step 9. Use dmm to measure resistance between B battery return and frame ground. Measured resistance includes all wiring from battery return to frame ground.

  • Page 95: Verify Secondary Power

    Exercise caution to avoid shorting power input terminals. At power panel of each 1677 SONET Link shelf in rack, set Power A and Power B switches to OFF. See figure 14-1.
  • Page 96 Chart-14 3EM13849AD Issue 01, May 2006 At front of rack, remove all PDU-Quad TPA fuses except for A1-1 (40 amp fuse). See figure 14-2. Figure 14-2. PDU-Quad (Front View) BLOWN TPA FUSE INDICATOR LEDS BLOWN TPA FUSE INDICATOR LEDS FRONT VIEW 677-0254-1 102204 At CO BDFB panel, set A1 circuit breaker to ON.
  • Page 97 Chart-14 3EM13849AD Issue 01, May 2006 Verify A1 power LED on PDU-Quad is lighted. If ON, go to step 8. If OFF, troubleshoot fault, then go to step 4. At shelf 1 power panel, set breaker A to ON and breaker B to OFF. See figure 14-1. Verify fan tray in shelf 2 (if equipped) is not operating.
  • Page 98 Chart-14 3EM13849AD Issue 01, May 2006 At CO BDFB panel, set B1 circuit breaker to ON. Circuit breakers A1, A2, and B2 remain OFF. See figure 14-3 for a simplified power routing diagram. Verify B1 power LED on PDU-Quad is lighted green. If ON, go to step 24.
  • Page 99 Chart-14 3EM13849AD Issue 01, May 2006 Shelf 2, A2 Power At front of rack, remove all PDU-Quad TPA fuses except for A2-1 (40 amp fuse). See figure 14-2. See figure 14-3 for a simplified power routing diagram. At CO BDFB panel, set A2 circuit breaker to ON. Circuit breakers A1, B1, and B2 remain OFF.
  • Page 100 Chart-14 3EM13849AD Issue 01, May 2006 At CO BDFB panel, set A2 circuit breaker to OFF. Shelf 2, B2 Power At front of rack, remove PDU-Quad TPA A2-1 fuse and insert B2-1 (40 amp fuse). See figure 14-2. At CO BDFB panel, set B2 circuit breaker to ON. Circuit breakers A1, A2, and B1 remain OFF.
  • Page 101 At shelf 2 power panel, set breaker A to OFF. See figure 14-1. At CO BDFB panel, set A2 circuit breaker to OFF. Has secondary power for all 1677 SONET Link shelves in rack been tested? If yes, go to step 71.
  • Page 102 Chart-14 3EM13849AD Issue 01, May 2006 Verify Secondary Power 2-66...

  • Page 103: Install Ds1 Splitter And Route Internal Clock Cables

    Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS...
  • Page 104 3EM171590004RJZZA, page 09. Route clock cable from splitter box at middle-right of rack (when facing front of rack) to TC slots in shelf 1. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 10.
  • Page 105 3EM171590004RJZZA, page 09. Route clock cable from splitter box at middle-right of rack (when facing rear of rack) to TC slots in shelf 2. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 10.
  • Page 106 Chart-15 3EM13849AD Issue 01, May 2006 Install DS1 Splitter and Route Internal Clock Cables 2-70...

  • Page 107: Route And Terminate External Clock Cables To Ds1 Splitter

    Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS...
  • Page 108 Chart-16 3EM13849AD Issue 01, May 2006 Table 16-A. BITS Clock Cable Connections CABLE ROUTE ON RACK CLOCK TYPE DS1 SPLITTER CONNECTOR (FRONT OF RACK) Primary J501 Left side Secondary J502 Right side STOP. This procedure is complete. Route and Terminate External Clock Cables to DS1 Splitter 2-72...

  • Page 109: Route External Clock Cables To Tc Slots

    Follow this procedure to route the primary and secondary Building Integrated Timing Supply (BITS) to the TC slots in the 1677 SONET Link chassis not using a DS1 splitter. The BITS A IN and BITS B IN connections provide redundant paths for the office BITS source. The BITS A OUT and BITS B OUT connections provide two separate DS1 clock references at remote sites that do not have a BITS office reference.
  • Page 110 Chart-17 3EM13849AD Issue 01, May 2006 Figure 17-1. BITS Wire-Wrap Connection Locations TERMINATION OF BITS CLOCK CABLES ON 1677 TIMING CARDS DRAIN CABLE WIRE REFER TO NOTE 1 DRAIN DRAIN 1-PR T1 CABLE (STP) (REFER TO NOTE 1) DRAIN CABLE WIRE REFER TO NOTE 2 DRAIN DRAIN...
  • Page 111 Route Four BITS Sources to Node Run four pairs of twisted, shielded 22-AWG ABAM cable from BITS source to TCs in 1677 SONET Link chassis (see figure 17-2). Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 13.
  • Page 112 (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 10, figure 1002, for cable routing inside shelf to TCs. Primary source (A) is installed at position 11A (A IN) on 1677 SONET Link chassis, and secondary source (B) is installed at position 11B (B IN) (see figure 17-2).
  • Page 113 Chart-17 3EM13849AD Issue 01, May 2006 Leave BITS clock cables hanging in front of TC slots 11A and 11B. Update office records. STOP. This procedure is complete. Route External Clock Cables to TC Slots 2-77...
  • Page 114 Chart-17 3EM13849AD Issue 01, May 2006 Route External Clock Cables to TC Slots 2-78...

  • Page 115: Install Fiber Management

    For more detailed information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS...
  • Page 116 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 12, detail 1201-C and detail 1201-D. Install rear middle kick plate. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 11.
  • Page 117 Chart-18 3EM13849AD Issue 01, May 2006 Figure 18-1. Flex-Tube Holder Locations FACTORY-INSTALLED FLEX-TUBE HOLDERS LEFT SIDE RIGHT SIDE NEW LOCATIONS FOR FLEX-TUBE HOLDERS FOR RAISED-FLOOR APPLICATION 677-0382-1 020606 Install Fiber Management 2-81...
  • Page 118 Chart-18 3EM13849AD Issue 01, May 2006 Install Fiber Management 2-82...

  • Page 119: Route Central Office Oc-N Signal Cables

    PURPOSE This chart provides instructions to route Central Office (CO) OC-n fiber-optic signal cables to 1677 SONET Link IOC modules. Optical cables are routed to staging positions in front of shelf slots, to be terminated when modules are installed. GENERAL Customer fiber-optic cables carry traffic signals from CO Network Elements (NEs) to and from 1677 SONET Link IOC modules.
  • Page 120 (as viewed from front of rack). Flex-hose tubing that supports protect fibers enters fiber access hole on right side of rack base (as viewed from front of rack). Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 15.
  • Page 121 Issue 01, May 2006 Route working optical cables across guides on front of shelf to designated IOC module. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 15, detail 1502-B. Use guides on top of shelf to access top modules containing straight optical connectors;...
  • Page 122 (as viewed from front of rack). Flex- hose tubing that supports protect fibers enters fiber access hole on right side of rack base (as viewed from front of rack). Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 16.
  • Page 123 Route working optical cables down into top of front-left rack panduit. Route working optical cables down, and exit cables out of panduit at appropriate height to enter shelf. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 16, figure 1602.
  • Page 124 Route protect optical cables down into top of front-right rack panduit. Route protect optical cables down, and exit cables out of panduit at appropriate height to enter shelf. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 16, figure 1602.

  • Page 125: Route Central Office Gige Signal Cables

    Route Central Office GigE Signal Cables PURPOSE This chart provides instructions to route Central Office (CO) GigE signal cables to 1677 SONET Link GIGE modules. GigE cables are routed to staging positions in front of shelf slots, to be terminated when modules are installed.
  • Page 126 Issue 01, May 2006 Position flex-hose tubing under rack and attach to flex-tube holders mounted at bottom of fiber management on left and right sides. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 15.
  • Page 127 (as viewed from front of rack), as appropriate for module location in shelf. If rack supports two shelves, start with lower shelf, and cable up to upper shelf. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 16.
  • Page 128 Issue 01, May 2006 Route GigE cables down, and exit cables out of panduit at appropriate height to enter shelf. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 16, figure 1602.

  • Page 129: Mount 48-Port Or 96-Port Ds3/Ec1 Connector Panel

    (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, pages 17 and 18. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details.
  • Page 130 6-32 × 3/8 in. Phillips flathead screw in bottom threaded hole. Tighten screws with a #2 Phillips screwdriver. Locate connector 13B-16B or 2B-5B on rear of 1677 SONET Link onto which 48-port DS3/EC1 connector panel is to be installed (see figure 21-3).
  • Page 131 Issue 01, May 2006 Figure 21-2. Cable-Tie Brackets Attached to Chassis-Mounted 48-Port DS3/EC1 Connector Panel ALIGNMENT (8) 6-32 X 3/8 PHILLIPS FLATHEAD SCREWS 677-0039-1 032405 Figure 21-3. 1677 SONET Link Rear Connectors 13B-16B 2B-5B CONNECTOR CONNECTOR REAR VIEW 13A-16A 2A-5A...
  • Page 132 Chart-21 3EM13849AD Issue 01, May 2006 Figure 21-4. Rear Connector Access Cover (4) 6-32 X 1/4 PHILLIPS SCREW W/LOCKWASHERS 677-0041-1 032405 Align four captive screws of panel with threaded holes and tighten each one using a #2 Phillips screwdriver. Is a second 48-port DS3/EC1 connector panel to be installed on back of chassis? If yes, go to step 3.
  • Page 133 Make sure there are no damaged or missing parts in kit. See figure 21-1 information on parts included with 48-port DS3/EC1 connector-panel (PN 3EM12329AA). To report any missing or damaged parts, contact Alcatel CTAC at 1-888-252-2832. Attach 48-port DS3/EC1 connector-panel (PN 3EM12329AA) to horizontal mounting bracket (PN 3EM18816AA).
  • Page 134 Attach to side of horizontal mounting bracket that faces 48-port DS3/EC1 connector panel. Install clip in the direction that cable exits its connector housing. Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, figure 1804.
  • Page 135 20 through 25. DS3/EC1 connectors must face outward from the rack (rearward for rear-mounted assembly or frontward for front-mounted assembly). Locate connector 13A-16A or 2A-5A on rear of 1677 SONET Link to which 48-port DS3/EC1 connector panel is to be connected (see figure 21-3).
  • Page 136 Chart-21 3EM13849AD Issue 01, May 2006 Figure 21-6. Rack-Mounted 96-Port DS3/EC1 Connector Panel Kit LIFTING CONNECTOR PANEL CONNECTOR-PANEL HANDLES CABLES (2) LABEL SHEET ANTISTATIC BAG CONNECTOR PANEL ASSEMBLY 23-INCH MOUNTING BRACKETS (2) CABLE-TIE BRACKETS (4) INSTALLATION HARDWARE 27.94 CM (11 IN.) 58.42 CM ( 23 IN.) 58.42 CM...
  • Page 137 Chart-21 3EM13849AD Issue 01, May 2006 Figure 21-7. Cable-Tie Brackets Attached to Rack-Mounted 96-Port DS3/EC1 Connector Panel ALIGNMENT (8) 6-32 X 3/8 PHILLIPS FLATHEAD SCREWS 677-0044-1 032405 Select action. If mounting 96-port DS3/EC1 connector panel on a 23 in. equipment rack, go to step 47.
  • Page 138 Using a #2 Phillips screwdriver, tighten four thumbscrews on each rear chassis cable (see figure 21-10). At rear of 1677 SONET Link, locate connectors in which two connector panel cables are to be plugged (see figure 21-3). Using a #2 Phillips screwdriver, remove connector access covers (see figure 21-4) at rear of chassis, and save it and attaching screws for possible future use.
  • Page 139 Chart-21 3EM13849AD Issue 01, May 2006 Figure 21-9. Connector Panel/Adapter Plate Attached to Equipment Rack (19-inch shown) DI AG DI AG LAS ER LAS ER EX T. IN G MGN T RI NG MGN T MGN T RI NG MGN T RI NG STAT (8) 12-24 X 1/2...
  • Page 140 Chart-21 3EM13849AD Issue 01, May 2006 Is there a second 96-port DS3/EC1 connector panel kit to install on equipment rack? If yes, go to step 43. If no, go to step 61. Locate 96-port DS3/EC1 connector panel label sheet(s) that came in kit(s). Label sheet has four labels, Labels A-D that correspond to different connections that can be made to the connectors on the rear of the chassis (see figure 21-3).

  • Page 141: Route And Terminate Central Office Ds3 And Ec1 Signal Cables

    (PN 3EM17362AB) and see drawing 3EM171590004RJZZA. Typically, if more than one 1677 SONET Link is equipped in a rack, coax cables are run to the first (lower position) 1677 SONET Link in a rack, then to the other (upper position) 1677 SONET Link as specified in job documentation.
  • Page 142 (as viewed from front of rack) of rack. Route coaxial cable up sides of rack, using bars inside side channel to support cables. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 21 (config option 2).
  • Page 143 (as viewed from front of rack) of rack. Route coaxial cable down sides of rack, using bars inside side channel to support cables. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 21 (config option 2).
  • Page 144 Route coaxial cable down sides of rack, using cable-tie brackets to support cables. Use cable-tie brackets facing rearward and outward from rack. Refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 20 (config option 1) or page 21 (config option 2).
  • Page 145 Chart-22 3EM13849AD Issue 01, May 2006 Figure 22-1. Typical DS3/EC1 Signal Connectors 48-P OR T DS 3/E C 1 C ONNE C T OR P ANE L 48-P OR T DS 3/E C 1 C ONNE C T OR P ANE L R E AR V IE W 677-0383-1 020806...
  • Page 146 Chart-22 3EM13849AD Issue 01, May 2006 Route and Terminate Central Office DS3 and EC1 Signal Cables 2-110...

  • Page 147: Connect Office Alarm Wiring To 1677 Sonet Link

    The alarm contacts on each CCC are redundant and can be wired to either one or two alarm connection points. The 1677 SONET Link does not provide separate fan alarms, nor does it have external Alarm Cutoff (ACO) or processor reset wiring.
  • Page 148 Chart-23 3EM13849AD Issue 01, May 2006 Connect Office Alarm Wiring to 1677 SONET Link 2-112...

  • Page 149: Connect Data Terminal Or Modem To 1677 Sonet Link

    Issue 01, May 2006 Chart-24 Connect Data Terminal or Modem to 1677 SONET Link PURPOSE Follow this procedure to connect a data terminal or modem to a 1677 SONET Link. STEP PROCEDURE WARNING: Possibility of equipment damage. This equipment contains static- sensitive devices.
  • Page 150 EXT. TIMING CONSOLE SYSTEM CONSOLE RING CABLE OR PC RING RJ-11 RING CONSOLE PORT PIN-OUTS 1 Tx RING 2 GND1 3 GND2 STATUS 4 Rx BITS IN-USE TIMING 677-0051-1 032405 Connect Data Terminal or Modem to 1677 SONET Link 2-114...
  • Page 151 TIMING TRANSMISSION NULL MODEM CONSOLE RING LINE CABLE CABLE RING RING RJ-11 CONSOLE PORT PIN-OUTS 1 Tx RING 2 GND1 3 GND2 STATUS 4 Rx BITS IN-USE TIMING 677-0052-1 032405 Connect Data Terminal or Modem to 1677 SONET Link 2-115...
  • Page 152 Chart-24 3EM13849AD Issue 01, May 2006 Connect Data Terminal or Modem to 1677 SONET Link 2-116...

  • Page 153: Connect Local Area Network (Lan) Wiring

    Chart-25 Connect Local Area Network (LAN) Wiring PURPOSE This chart provides instructions to terminate LAN connections at the 1677 SONET Link chassis. The chassis supports two 10/100Base-T interfaces, which operate at either 10 Mbps or 100 Mbps. GENERAL In a 10/100Base-T installation, the NE can be connected to only one other device. This can be another 1677 SONET Link or LAN hub or switch equipment.
  • Page 154 Connections between two NEs require a cross-over configuration; transmit pair of one NE should connect to receive pair of other NE. Connect RJ-45 cable to Ethernet connector on 1677 SONET Link TC (see figure 25-2). Make appropriate terminating connection on terminating equipment.
  • Page 155 Chart-25 3EM13849AD Issue 01, May 2006 Figure 25-2. Locate 10/100Base-T Ethernet Connector on TC RJ-45 ETHERNET PORT PIN-OUTS N.C. N.C. EXT. TIMING RING RING RING RING BITS IN-USE TIMING 677-0053-1 032405 Connect Local Area Network (LAN) Wiring 2-119...
  • Page 156 Chart-25 3EM13849AD Issue 01, May 2006 Connect Local Area Network (LAN) Wiring 2-120...

  • Page 157: Test 1677 Sonet Link Wiring Continuity

    3EM13849AD Issue 01, May 2006 Chart-26 Test 1677 SONET Link Wiring Continuity PURPOSE Follow this procedure to verify the end-to-end wiring continuity of the 1677 SONET Link. RECOMMENDED TOOLS Triplett Volt-Ohm Meter (VOM), Model 630 or equivalent STEP PROCEDURE Set VOM to RX1 scale.
  • Page 158 Chart-26 3EM13849AD Issue 01, May 2006 Table 26-A. Continuity Test List From 1677 SONET Link Location To Office Location 1677 SONET Link TERMINATION POINT OFFICE TERMINATION LOCATION CCC 9 minor alarm visual contact pair Office alarm interface CCC 9 major alarm visual contact pair...

  • Page 159: Install Rear Kick Plate

    1677 SONET Link system. GENERAL Brackets and fastening hardware, when required, are supplied in the kits. For more detailed information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 22. RECOMMENDED TOOLS...
  • Page 160 Chart-27 3EM13849AD Issue 01, May 2006 Install Rear Kick Plate 2-124...

  • Page 161: Install Ac Outlets

    For AC outlet kit information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM137210002UDZZA. Alcatel provides expert Installation Services for installations that have different requirements from config option 1 and config option 2 as outlined in this manual. Contact Alcatel at 1-888-252-2832 for details. RECOMMENDED TOOLS...
  • Page 162 Chart-28 3EM13849AD Issue 01, May 2006 Is AC outlet being installed on front or rear of rack? If front of rack, go to step 7. If rear of rack, go to step 9. Install mounting bracket, duplex box, and AC outlet on rack (see figure 28-1). Go to step 11.
  • Page 163 Chart-28 3EM13849AD Issue 01, May 2006 Figure 28-2. AC Duplex Outlet Installation, Rear Mount RACK BASE DUPLEX (REAR VIEW) AC OUTLET OUTLET COVER 677-0377-1 100505 Install AC Outlets 2-127...
  • Page 164 Chart-28 3EM13849AD Issue 01, May 2006 Install AC Outlets 2-128...

  • Page 165: Install Front Base Plate

    This chart provides instructions to install a front base plate on a rack. GENERAL A front base plate kit (PN 3EM13721DN) is installed on a 1677 SONET Link rack. For more detailed information, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing 3EM171590004RJZZA, page 23.
  • Page 166 Chart-29 3EM13849AD Issue 01, May 2006 Install Front Base Plate 2-130...

  • Page 167: Install Electrical Switch

    GENERAL Installation of an electrical switch is optional. If not installing an electrical switch, skip this Chart. For additional details, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB), and see drawing PN 3EM171590004RJZZA, page 25. RECOMMENDED TOOLS...
  • Page 168 Chart-30 3EM13849AD Issue 01, May 2006 Install Electrical Switch 2-132...

  • Page 169: Install Trim (Config Option 1)

    This chart provides the instructions to install rack rear, front, and middle trim for config option 1. GENERAL If performing an installation using config option 2, skip this Chart. For additional details, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB), and see drawing PN 3EM171590004RJZZA, page 25. RECOMMENDED TOOLS...
  • Page 170 Is rack installed adjacent to another rack containing 1677 SONET Link shelves? If yes, go to step 10. If no, go to step 11. Install front and rear middle trim (PN 3EM16590AP). Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing PN 3EM171590004RJZZA, page 28.

  • Page 171: Install Pdu-Quad Labels

    Install PDU-Quad Labels PURPOSE This chart provides the instructions to install PDU-Quad labels. GENERAL For additional details, refer to the 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB), and see drawing PN 3EM171590004RJZZA, page 29. STEP PROCEDURE Install PDU-Quad fuse labels (PN 3EM16596AA and PN 3EM16596AB). Refer to 1677 SONET Link Engineering Support Documentation manual (PN 3EM17362AB) and see drawing PN 3EM171590004RJZZA, page 29.
  • Page 172 Chart-32 3EM13849AD Issue 01, May 2006 Install PDU-Quad Labels 2-136...

  • Page 173: Verify Final Installation

    STEP PROCEDURE Check that -48 V dc office power to 1677 SONET Link is turned off. Ensure mounting assemblies (shelves, fuse panels, and so forth) were properly secured to equipment rack. Check that equipment rack was located per approved floor plan.
  • Page 174 3EM13849AD Issue 01, May 2006 Verify all relay rack and BDFB labels are properly installed. This completes basic installation. To turn up system, refer to 1677 SONET Link Turn- Up manual (PN 3EM13850AB). STOP. This procedure is complete. Verify Final Installation...

  • Page 175: Installing Mos Modules

    3EM13849AD Issue 01, May 2006 Installing MOS Modules REQUIREMENTS Follow the procedures in this chapter to perform the following: • Unpack, inspect, and inventory an order • Mount the optical modules in the equipment rack • Route and connect cables to the Modular Optical System (MOS) To install the MOS, installers will need the following tools and supplies: •...

  • Page 176: Electrical Power Requirements

    3EM13849AD Issue 01, May 2006 Table 1-A. Environmental Requirements TEMPERATURE (IMMEDIATELY SURROUNDING THE MODULES) Operating 5°C to 40°C (41°F to 104°F) Non-Operating -40°C to +70°C (-40°F to +158°F) TEMPERATURE CHANGE/HOUR (IMMEDIATELY SURROUNDING THE MODULES) Operation / Non-Operation less than 30°C (54°F) per hour HUMIDITY Operation / Non-Operation 5% to 85%...

  • Page 177: Inspection

    (If a camera is available, take several pictures of damage.) Open carton and carefully remove and inspect contents for damage. If there is damage, contact Alcatel CTAC at 1-888-252-2832 to report damage and to find out what to do next.

  • Page 178: Preventing Esd Damage

    CAUTION Possibility of service interruption. High insertion loss and back reflections may occur if APC-type cable is inserted into SC-type connector on 1677 SONET Link. The 1677 SONET Link uses an SC/UPC pigtailed laser and an SC/UPC pigtailed receiver. UPC is a type of domed polish that reduces back reflections to -55 db.

  • Page 179: Installation

    3EM13849AD Issue 01, May 2006 INSTALLATION Follow the procedures in this section to plan and install mid-mounted and front-mounted modules in 19 in. and 23 in. equipment racks. 19-Inch Mounting Installers can mid-mount or front-mount the MOS in a 19 in. equipment rack or cabinet using the two 19 in.

  • Page 180: Fiber-Optic Jumper Cable Requirements

    CAUTION Possibility of service interruption. High insertion loss and back reflections may occur if APC-type cable is inserted into SC-type connector on 1677 SONET Link. The 1677 SONET Link uses an SC/UPC pigtailed laser and an SC/UPC pigtailed receiver. UPC is a type of domed polish that reduces back reflections to -55 db.

  • Page 181: Planning The Installation

    3EM13849AD Issue 01, May 2006 Planning the Installation To simplify installation and to optimize cable routing and servicing, follow these recommendations: Ensure there is enough space in equipment rack. Each module requires one unit (1U) of vertical space for an ANSI/EIA- 310-D or IEC equipment rack, or 2 in.

  • Page 182: Mounting The Module

    3EM13849AD Issue 01, May 2006 Figure 3-2. Typical Module Placement DCM EAST OTHER DWDM EAST MODULES DWDM EAST EAST DWDM EAST MODULES ADM EAST ADM EAST ADM WEST WEST DWDM WEST MODULES DWDM WEST OTHER DWDM WEST MODULES DCM WEST 677-0170-1 032405 Mounting the Module...

  • Page 183: Front-Mounting The Modules

    3EM13849AD Issue 01, May 2006 Front-mounting the Modules Locate the module that will be installed in the lowest position. This 3.10 module will be mounted first. Determine which mounting brackets to use. 3.11 If mounting module in a 19 in. equipment rack, attach two 19 in. mounting brackets to front of left and right sides of module (see figure 3-3) using #2 Phillips screwdriver and eight #6-32 x 3/8 in.
  • Page 184 3EM13849AD Issue 01, May 2006 If mounting-hole spacing of equipment rack meets ANSI 310-D or IEC 3.13 standard (see figure 3-1), do the following: Position and support module in equipment rack so bottom edge of each front-mounting bracket is located roughly between two mounting-hole patterns (the 1/2 in.
  • Page 185 3EM13849AD Issue 01, May 2006 Figure 3-4. Locate Front-Mounting Brackets on Rack LOCATE BRACKET EDGE 23-INCH OR 5/8-INCH BELOW NEXT HOLE 19-INCH MOUNTING BRACKET 23-INCH OR 19-INCH MOUNTING LOCATE BRACKET BRACKET EDGE BETWEEN 1/2-INCH HOLE DISTANCE ANSI 310D OR IEC 1-INCH ON-CENTER EQUIPMENT RACK EQUIPMENT RACK...

  • Page 186: Mid-Mounting A Module

    3EM13849AD Issue 01, May 2006 Figure 3-6. Install Cable Exit Clips 677-0174-1 032405 To install fiber-optic cables and OMB cables, follow the procedures in 3.16 section of this discussion of MOS modules. Mid-mounting a Module Locate the module that will be installed in the lowest position in the 3.17 rack and mount this module first.
  • Page 187 3EM13849AD Issue 01, May 2006 Figure 3-7. Install Mid Mounting Brackets 23-INCH 23-INCH MOUNTING MOUNTING BRACKET BRACKET 6-32 X 3/8 FLATHEAD SCREWS 19-INCH 19-INCH MOUNTING MOUNTING BRACKET BRACKET 677-0171-1 032405 Determine the mounting-hole spacing on the equipment rack, and 3.19 mount and position the module according to the following.
  • Page 188 3EM13849AD Issue 01, May 2006 If the equipment rack has 1 in. on-center mounting holes: 3.21 Position module in equipment rack, making sure screw holes in front- mounting brackets line up with four holes in equipment rack. Install four #12-24 x 1/2 in. screws provided in right and left mid- mounting brackets and lightly tighten each screw with a #2 Phillips screwdriver.
  • Page 189 3EM13849AD Issue 01, May 2006 Install the cable-exit clips in the holes on the right end and left end of 3.25 the modules (see figure 3-6). Follow the procedures in the next section to install and route the fiber- 3.26 optic cables.
  • Page 190 3EM13849AD Issue 01, May 2006 Installing MOS Modules 3-16...

  • Page 191: Installing And Routing Fiber-Optic Cables

    Inspect and, when necessary, clean fiber-optic cable connector and module adapter before connecting them. Refer to the 1677 SONET Link Turn-Up manual (PN 3EM13850AB) for inspection and cleaning procedure. Open shutter on fiber-optic adapter of module (see figure 4-1).

  • Page 192: Cabling The Mos

    Determine the number, the lengths, and the types of jumper cables that are needed. Connect fiber-optic cables between the optical modules and an Alcatel 1677 SONET Link, then connect metallic cables between the OMB jacks of the module. Install the west-to-east express path fiber-optic cable from the ADM...
  • Page 193 3EM13849AD Issue 01, May 2006 Figure 4-2. Installing Express Path Cables PORT 1 PORT 2 PORT 11 PORT 12 NETWORK EXPRESS OUT EXPRESS IN NETWORK (TO WEST) (FROM WEST) ADM EAST ADM WEST PORT 1 PORT 2 PORT 11 PORT 12 NETWORK EXPRESS IN EXPRESS OUT...
  • Page 194 Connect this side of east-to-west network fiber to NETWORK OUT adapter (port 1) on ADM west module. Figure 4-3. Connecting OMB Cables COMMON CONTROL CARDS (CCCs) IN ALCATEL 1677 SONET LINK OPTICAL MANAGEMENT BUS CABLE TO MOS...

  • Page 195: Selecting And Installing Fiber-Optic Attenuators

    (port 12) on ADM east module. Connect the optical management bus (OMB) cables between the 4.12 modules and the common control cards (CCCs) in the Alcatel 1677 SONET Link (see figure 4-3). Route an OMB cable from left-side OUT jack of one module, through left cable-exit clip, and around cable guide to left-side IN jack of next module.
  • Page 196 3EM13849AD Issue 01, May 2006 Installing MOS Modules 3-22...

Table of Contents
