O W N E R S M A N U A L
Cima AC NT
Retractable, Above Ceiling Screen System
Producers of Professional Projection Screens

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cima AC NT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Stewart Audio Cima AC NT

  • Page 1 O W N E R S M A N U A L Cima AC NT Retractable, Above Ceiling Screen System Producers of Professional Projection Screens...
  • Page 2 Printed in U.S.A. ©2019 Stewart Filmscreen Corporation Stewart Filmscreen reserves the right to make changes to the product specified in this document. Sizes and specifications subject to change without notice at Manufacturer’s discretion. From time to time, this document is updated. Current versions of documentation are posted on the Stewart Filmscreen website at: www.stewartfilmscreen.com...
  • Page 3: Table Of Contents

    Cima AC NT O W N E R S M A N U A L Contents To the Owner Preparing the Installation Product Dimensions Installing the Screen Into the Ceiling Standard Controls: Keypad Control Projector Trigger Control Keypad & Projector Trigger Control...
  • Page 4: To The Owner

    Cima by Stewart Filmscreen product ABOUT YOUR CIMA AC NT ELECTRISCREEN The Cima Above Ceiling Non-Tensioned ElectriScreen is designed for ease of installation The Cima...
  • Page 5: Preparing The Installation

    PREPARING THE INSTALLATION The Cima Above Ceiling Non-Tensioned product can be controlled through a number of remote control devices, including keypads, dry contact outputs, and low-voltage trigger outputs With the optional Cima- Link Controller Packages, your Cima screen can be controlled by local and remote Infrared, IP ethernet, and computer-based signaling sources such as those manufactured by Control4, AMX, Crestron, Elan Home Systems with RS-232-C or RS-485 interfaces i CAUTION...
  • Page 6: Product Dimensions

    PRODUCT DIMENSIONS ROUGH OPENING (DIM D) = DIM A - 3/4” [19 mm] 6-3/4” 7-3/4“ [196 mm] DIM A = IMAGE WIDTH + (SIDE MASKING X 2) [171 mm] 6-1/2“ + 11-1/2” [292 mm] 6-1/8“ [154 mm] +/-1/4” [165 mm] [6 mm] DIM C = IMAGE WIDTH + (SIDE MASKING X 2) + 10”...
  • Page 7: Installing The Screen Into The Ceiling

    INSTALLING THE SCREEN INTO THE CEILING Professional mounting techniques should be used Stewart Filmscreen cannot be liable for substandard or faulty installations i CAUTION During installation of the Cima Above Ceiling Non-Tensioned ElectriScreen into the ceiling opening, be advised that damage can occur to the screen Perform the following actions to avoid damage: Wear clean gloves throughout the installation process to prevent damage to the screen housing or screen material Make sure that the screen batten never contacts or strikes any objects as damage may occur...
  • Page 8: Keypad Control

    STANDARD CONTROL - KEYPAD CONTROL A standard, 3-button, low-voltage keypad is supplied for both the standard controller and the optional Cima-Link Controller Accessories MAKING THE CONNECTIONS 1 Connect the RJ25 cable to the keypad 2 2 Connect the other end of the RJ25 cable to the Cima unit ADDITIONAL RJ25 JACK FOR OPTIONAL CONTROLS...
  • Page 9: Projector Trigger Control

    STANDARD CONTROL - PROJECTOR TRIGGER CONTROL MAKING THE CONNECTIONS Connect a projector trigger cable to the projector (Note: projector trigger cable not provided – the installer needs to make the cord from a RJ25 cord, cut one end off and add the mono plug onsite ) 2 Connect the other end of the trigger cable to the Cima unit (RJ25 plug) ADDITIONAL RJ25 JACK FOR...
  • Page 10: Keypad & Projector Trigger Control

    STANDARD CONTROL - KEYPAD & PROJECTOR TRIGGER CONTROL MAKING THE CONNECTIONS 1 Connect the RJ25 cable splitter to the RJ25 jack in the Cima unit 2 Connect the RJ25 cable and projector trigger cable to each jack in the splitter (Note: projector trigger cable not provided –...
  • Page 11 OPTIONAL CONTROLS - CIMA-LINK CONTROLLER DESCRIPTION The optional Cima-Link Controller (IMC-100C) is a state-of-the art bi-directional communication AC motor controller designed to control your Cima projection screen and integrate with optional infrared remote, additional Cima screens, and 3rd party applications Up to 255 Cima ElectriScreens can be linked together on any one span when connected together via the optional Cima-Link RS-232 Serial Package or Cima-Link Ethernet Package CIMA-LINK...
  • Page 12: Cima-Link Infrared Package

    OPTIONAL CONTROL - CIMA-LINK INFRARED PACKAGE CONNECTION MAKING THE CONNECTION Connect the RJ25 cable to the top RJ25 jack located on the left side of the Cima unit 2 Place infrared eye in line of sight of remote Note: The maximum length of the RJ25 cable shall not exceed 50’ INFRARED EYE INFRARED EYE CONNECT CABLE...
  • Page 13: Cima-Link Ethernet Package

    OPTIONAL CONTROL - CIMA-LINK ETHERNET PACKAGE CONNECTION MAKING THE CONNECTION Connect the RJ25 cable to the left RJ25 jack located on the left side of the Cima unit 2 Place the other end of the RJ25 cable to the RJ25 jack in the IP device 3 Place the RJ45 cable in the RJ45 jack in the IP Device 4 Place the other end of the RJ45 cable in the end-user device Note: The maximum length of the RJ25 cable shall not exceed 50’...
  • Page 14: Cima-Link Rs232 Package

    OPTIONAL CONTROL - CIMA-LINK RS232 PACKAGE CONNECTION MAKING THE CONNECTION Connect the RJ25 cable to the top RJ25 jack located on the left side of the Cima unit 2 Place the other end of the RJ25 cable to the RJ25 jack in the RS232 3 Connect the 9-pin end of the RS232 to the 9-pin jack in the end-user device Note: The maximum length of the RJ25 cable shall not exceed 50’...
  • Page 15: Operating The Screen

    OPERATING THE SCREEN DESCRIPTION The method you use to raise and lower the screen depends on the type of switch control device you have selected When you lower or retract the screen, it will stop at its preset limit If an obstacle (such as a person or furniture) is in the path of the screen as it is lowered, use the switch control to stop the screen’s motion (it will not automatically stop if it hits an obstacle) The motor is designed to be used for short operations such as lowering the screen in preparation for...
  • Page 16: Adjusting The Screen Extension

    ADJUSTING THE SCREEN EXTENSION i CAUTION Improper adjustment of the limit switches can cause irreparable damage to the screen itself, resulting in voiding the factory warranty The extension and retraction limit switches have been preset at the factory In general, we advise you to avoid readjusting these switches In some cases, to enable proper alignment of the displayed image on the screen, you may need to adjust the extension of the screen If adjustment to the extension is necessary, carefully follow these instructions...
  • Page 17 ADJUSTING THE SCREEN EXTENSION (CONTINUED) To decrease the screen extension: Lower the screen until it is extended about halfway down 2 Remove the dust cover to locate the white extension (down) limit switch on the left side of the screen tube (audience left) Use a small electrician’s style screwdriver or a 5/32” ( 4 cm) hex wrench to turn the switch in a clockwise direction Note: One complete turn of the switch will make approximately a 3/4”...
  • Page 18: Caring For & Cleaning The Screen

    SCREEN CARE AND CLEANING With reasonable care, you may expect many years of dependable use of your Stewart projection screen We encourage you to keep your screen clean To protect your screen when it is not in use, store it in the fully retracted position Avoid getting any foreign material on the screen, as cleaning may prove very difficult It may not be possible to remove scratches, paint, ink, etc GENERAL MAINTENANCE...
  • Page 19: Troubleshooting

    TROUBLESHOOTING Refer to the following guidelines if you encounter a difficulty in the operation of your Stewart Filmscreen product Problems related to electrical or motor function may require a qualified service person or electrician Should you have a problem that is not addressed here, call Stewart Filmscreen Corporation (310-784-5300) Toll free (800-762-4999) Problem Cause...
  • Page 20 TROUBLESHOOTING Problem Cause Action Steps Screen continues past bottom White limit switch is out of Readjust the white DOWN stop position adjustment limit switch See the section on Adjusting the Screen Extension Batten retracts too far into Yellow limit switch is out of Have a qualified service case adjustment Failure to correct...
  • Page 21: Product Warranty

    LIMITED ONE YEAR WARRANTY STEWART FILMSCREEN CORPORATION (Stewart) warrants all products to the original purchaser only Stewart products are guaranteed to be free from defects in materials and workmanship for a period of one (1) year from the date of purchase by the original purchaser or eighteen (18) months from date of manufacture, as defined in the serial number Additionally, all products must be properly operated and maintained according to Stewart instructions and cannot be damaged due to improper handling or treatment after shipment from the factory This warranty does not apply to equipment showing evidence...
  • Page 22 www.stewartfilmscreen.com 1161 W. Sepulveda Blvd., Torrance CA 90502 USA 800.762.4999 Tel: 310.784.5300 Fax: 310.326.6870 Email: request@stewartfilmscreen.com ©2019 Stewart Filmscreen. Specifications are subject to change without notice.
