Extractor Corporation SUITMATE Adjustment Procedure

SUITMATE
Depress the Lid on the top of the unit and listen for the faint click (activation) of the Micro Switch. If the Micro
Switch does not activate or if it activates before the Lid is ¼ inch from being fully depressed, there is probably
a problem with the alignment of the Micro Switch. The following procedure will solve the alignment problem.
Please consult the illustration (Page 48) showing the back of the SUITMATE
will need to recognize.
REMOVE SUITMATE
1) Turn off the main electrical power to the unit – place a lockout tag on the circuit breaker panel indicating that
the breaker is not to be turned on except by authorized personnel and disconnect the unit before doing any
work on the SUITMATE
2) Remove the SUITMATE
3) Place the unit on its front side and remove the Micro Switch Box Cover to expose the Micro Switch and
Riser Cable Assembly by unscrewing the (2) Machine Screws. Place the screws aside for reassembly.
NOTE: Older units may have rivets instead of screws.
CAUTION!
1) Stand the unit upright and reaching from the rear, push the Lid down on the top of the unit to determine if the
Riser Cable that runs from the top of the unit to the Micro Switch arm is pulling on the arm. If there is no
movement, the Actuator Screw in the top may be broken and will need to be replaced. See the Lid Assembly
section on Page 19 of this manual.
2) If the Riser Cable does pull up on the Micro Switch arm, then the alignment can likely be adjusted. First,
push the Lid down; the Micro Switch should NOT activate (click) until the Lid is approximately ¼ inch from
being totally depressed. Adjust the alignment by tightening (unit will activate sooner) or loosening (unit will
activate later) the Turnbuckle Nut on the bottom of the Riser Cable until the proper adjustment is obtained.
Provide power to the unit and ensure that it is functioning properly.
3) Disconnect the power to the unit.
4) Replace the Micro Switch Box Cover using the (2) Machine Screws removed in step 3.
1) Reinstall the SUITMATE
2) Turn on the main electrical power to the unit and retest to assure proper operation. Refer to TESTING
AND OPERATION on Page 7.
If you have further difficulities or want additional information, please contact Extractor Corporation at:
(Toll Free) 800-553-3353, (Telephone) 847-742-3532 or (E-Mail) info@suitmate.com and explain your problem.
©2019 Extractor Corporation
MICRO SWITCH ADJUSTMENT PROCEDURE
®
115 V, 60 Hz, 8.6 Amp SUITMATE
®
unit. Simply turning off a switch is NOT enough.
®
unit from its Wall Mounting. See instructions beginning on Page 14.
®
Make certain the main electrical power to the unit is turned off – and locked out
– before beginning work on the SUITMATE

CHECKING MICRO SWITCH ALIGNMENT

REATTACH THE SUITMATE
unit to the Wall Mount Bracket. See instructions beginning on Page 14.
®
UNIT FROM THE WALL MOUNT BRACKET
UNIT TO WALL
®
1
Unit
®
unit to identify the parts that you
®
unit.
®
115 V / 60 Hz SUITMATE Unit
®
