Human HumaStar 300 Service Manual page 269

test Program
The test activates a program of a random
movement of the Sample plate. Enter the
TEST number of cycles into window: "mm/10".
PLATE "SaMple teSt RepeatS".
Before running this Test:
Position Probe and plate into HOME position.
WASH
MOVE SAMP # This test activates the Sapling Arm rotation,
ARM CUV # from its HOME to the programmed position.
The test activates the random rotation of the
TEST Sampling Arm, starting from HOME to the
ARM programmed position. The number of cycles
are programmed in: SaMple teSt RepeatS
This test moves the syringe piston. To run
MOVE
3000 this test enter the volume into window: "µL
DILUTER
/ 10 ".
This test activates a program of a radmom
TEST DI- movement of the syringe piston for the volu-
3000
LUTER me set in window: "µl / 10" and the number
of cycles as set in: "SaMple teSt RepeatS".
To command the AIR PUMP, it is necessay to
activate PWR ON and AIR [] in both Sam-
AIR
pling and Cuvette Systems.
PUMP
To activate pump – click []
To stop pump – click [O]
Before staring this test, program, program
the volumr into window: " µ l " (example
P1 PUMP 2000 2000 µ l).
Click on [P2] to activate pump and dispense
the programmed volume of (2000 µl).
To activate pump – click []
P4 PUMP
To stop pump – click [O]
Click on [MIXER] to activate the mixing. (max.
MIXER
time is 3 sec)
Position probe and plate into
HOME position
Position Probe and plate into
HOME position
Position Probe and plate into
HOME position
Max. volume to be to be pro-
grammed is 6000 µL/10
Max. volume to be to be pro-
grammed is 6000 µL/10
At the end click [O] in Sampling
system
Before running this test, posi-
tion:
HOME
MOVE Arm to wash
Activate pump P7 to empty
waste receptacle.
During the execution of this
test activate the pump P7 to
empty the waste receptacle.
251
(1)
16.3.1
(1)
16.3.1
(1)
16.3.1
(3)
16.3.1
(3)
16.3.1
