- Page 1 Arctica 3200xlp switch Installation Guide Content Arctica 3200xlp Series switch Installation Guide Version 1.1 2017-02-07...
-
Page 2: Table Of Contents
Arctica 3200xlp switch Installation Guide Content Content 1. Introduction ....................1 1.1.Product Brief ...................... 1 1.1.1.Overview ....................1 1.1.2.Features and Benefits ................1 1.2.Description of Hardware ..................3 1.2.1.Front Panel ....................3 1.2.2.Back Panel ....................4 1.3.Status LEDs ......................4 1.4.Port Description .................... - Page 3 Arctica 3200xlp switch Installation Guide Content 3.2.7.AC Power Supply Connection ..............7 3.2.8.Earthing Cable Connection ..............8 3.2.9.Checking the Switch ................9...
-
Page 4: Introduction
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction 1. Introduction 1.1.Product Brief 1.1.1.Overview Arctica 3200xlp switch is the next generation of 40Gb Ethernet routing switches. Arctica 3200xlp switch is based on 40Gb switching technology. It is particularly designed for 40Gb server of data center to fetch in the scene in high consistency. It provides the cogent network sustentation for 40Gb/10Gb connecting to 40Gb/10Gb scheme in data center and distripark network with the characteristic of high reliability, multiple redundancy, high consistency and flexible convergence proportion. - Page 5 Arctica 3200xlp switch Installation Guide Chapter 1 Introduction split into 4 10Gb SFP+ ports. ◇ Support 40Gb Ethernet 40Gb Ethernet which adopts full-duplex technology instead of low-speed, half-duplex CSMA/CD protocol, is a big leap in the evolution of Ethernet. 40Gb Ethernet can be deployed in star or ring topologies.
-
Page 6: Description Of Hardware
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction administrator abide by SMTP protocol. Arctica 3200xlp supports SSH protocol, ensure the configuration management security of the switch. It is adopted the web management system ‘LinkManager’ for unified management expediently and compactly. ◇... -
Page 7: Back Panel
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction and telnet configuration through this port. The console port supports asynchronous mode, set the data bit as 8, the stop bit as 1, the parity bit as none, the default baud rate as 115200bps. 1.2.2.Back Panel The back panel of Arctica 3200xlp includes 2 alternating current of 220V power module (it provides redundancy backups) and 5 fan rabbets. -
Page 8: Port Description
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction Table 1-4 The explanation of the port indicator light Indicator light Panel sign State Green light The port is transmitting data. ETHERNET port Wink Link light (left) Put out There is no data transmitting on port. Yellow light The port is configured at 10M/100M speed... -
Page 9: Power Supply Module
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction Arctica 3200xlp provides 32 QSFP+ ports and supports the QSFP+ cable. It enhances the flexibility of the network. User can select the cables in the table 1-5 according to the demand. Table 1-6 Cables supported by Arctica 3200xlp Type Manufacturer Model... -
Page 10: 550W Power Module
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction +/- 5%. There is a fan and a handle for sticking in or pulling out the module on the back of the power supply. The power supply module supports the hot plug. 1.5.2.550W Power Module Arctica 3200xlp switch also can have two 550W power modules in standard configuration, it provides redundancy backups. -
Page 11: System Specifications
Arctica 3200xlp switch Installation Guide Chapter 1 Introduction Caution！ Different airflow fan modules can not be mix used. Power modules’ airflow must be same with fan modules’. 1.7.System Specifications Table 1-7 System Specifications of Arctica 3200xlp Type Arctica 3200xlp Attribute Dimension(W * H * D) (mm) 433.8 * 44 * 550 Weight... -
Page 12: Installation Notice
Arctica 3200xlp switch Installation Guide Chapter 2 Installation Notice 2. Installation Notice To ensure the proper operation of Arctica 3200xlp and your physical security, please read carefully the following installation guide. 2.1.Environmental Requirements ■ The switch must be installed in a clean area. Otherwise, the switch may be damaged by electrostatic adherence. -
Page 13: Temperature And Humidity
Arctica 3200xlp switch Installation Guide Chapter 2 Installation Notice Average (mg/m³) Max (mg/m³) 0.006 0.03 0.04 0.15 0.05 0.15 0.01 Table 2-2 Environmental Requirements: Particles 2.1.2.Temperature and Humidity Although the switch is designed to use 5 fans, the site should still maintain a desirable temperature and humidity. -
Page 14: Power Supply
Arctica 3200xlp switch Installation Guide Chapter 2 Installation Notice 15 ~ 30°C 0 ~ 40°C 40 ~ 65% 10 ~ 90% Table 2-3 Environmental Requirements: Temperature and Humidity Caution! A sample of ambient temperature and humidity should be taken at 1.5m above the floor and 0.4m in front of the switch rack, with no protective panel covering the front and rear of the rack. -
Page 15: Rack Configuration
Arctica 3200xlp switch Installation Guide Chapter 2 Installation Notice All sources of interference, whether from the device/system itself or the outside environment, will affect operations in various ways, such as capacitive coupling, inductive coupling, electromagnetic radiation, common impedance (including the grounding system) and cables/lines (power cables, signal lines, and output lines). -
Page 16: Security Warnings
Arctica 3200xlp switch Installation Guide Chapter 2 Installation Notice 2.3.Security Warnings ■ When using QSFP transceiver, do not stare directly at the fiber bore when the switch is in operation. Otherwise the laser may hurt your eyes. ■ Do not attempt to conduct the operations which can damage the switch or which can cause physical injury. -
Page 17: Device Installation
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation 3. Device Installation 3.1.Installation Preparation 3.1.1.Verify the Package Contents Please unpack the shipping package and verify carefully the contents inside. 3.1.2.Required Tools and Utilities The required tools and utilities are shown below: ■... -
Page 18: Installing The Power Supply Module
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation 1. Attach the 2 brackets on the Arctica 3200xlp with screws provided in the accessory kit. 2. Put the machine on the stock of the rack when installing because the machine is quite heavy. -
Page 19: Installing The Fan
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation Figure 3-3 The figure of Arctica 3200xlp switch power supply installing Please install the power supply module according to the following approach: The golden finger is entad and aim at the power supply rabbet of the machine to insert to the end downwards. -
Page 20: Connecting Console
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation Figure 3-4 The figure of Arctica 3200xlp switch installing the fan Please install the fan module according to the following approach: The golden finger is inward and adown and aim at the fan rabbet of the back machine flatly to the end. -
Page 21: Qsfp+ Transceiver Installation
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation Figure 3-5 Connecting Console to Arctica 3200xlp 40Gb Routing switch The connection procedure is listed below: Find the console cable provided in the accessory kit. Attach the console cable end to console port of the switch. -
Page 22: Copper Cable/Fiber Cable Connection
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation 3.2.6.Copper Cable/Fiber Cable Connection Copper cables should be connected as below: Step 1: Insert one end of the Ethernet cable to the RJ-45 Ethernet port in the switch copper port; Step 2: Insert the other end of the Ethernet cable to the RJ-45 Ethernet port of other device;... -
Page 23: Ac Power Supply Connection
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation Figure 3-6 Connect the DAC cable to Arctica 3200xlp switch The connection approach of DAC cable is below: Connect the two side of DAC cable to QSFP+ transceiver of Arctica 3200xlp switch. -
Page 24: Earthing Cable Connection
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation Figure 3-7 Connect the power supply cable to the Arctica 3200xlp switch AC Power supply connection procedure is described as below: 1. Insert one end of the power cable provided in the accessory kit into power source socket, and the other end to the power socket (with overload and leakage protection). -
Page 25: Checking The Switch
Arctica 3200xlp switch Installation Guide Chapter 3 Device Installation Figure 3-8 Connect the earthing cable to the Arctica 3200xlp switch Please connect the earthing cable according to the following approach: Cover one side of the earthing cable to the earthing pillar of the back panel. Take out the screw from accessories, put and screw down the fixed nut on the earthing pillar of the switch,.
