- Page 1 LogiScan-15xx Short Instruction...
- Page 2 LogiScan-15xx Short Instruction...
- Page 3 +49 (0) 5251 29816-40 Internet: http://www.aitronic.de E-Mail: info@aitronic.de ___________________________________________________________ Copyright aitronic GmbH, 2016 All Rights reserved, in particular all extracts which correspond to the translation, the reprint and reproduction by copying or similar methods. Delivery and technical changes are subject to change.
-
Page 4: Table Of Contents
4.7 devin......................4-10 Broadcast Receiver.................. 4-13 Barcode Types ..................4-14 RFID Tag Types ..................4-15 4.8 Barcode Scanning.................. 4-16 4.9 Turning Device on/off ................4-16 5. Disposal ............... 5-17 6. Technical Specifications ..........6-18 6.1 LogiScan-1500..................6-18 6.2 LogiScan-1550..................6-19 ____________________________________________________________________ aitronic... -
Page 5: General
LogiScan-15xx Short Instruction ____________________________________________ 1. General The LogiScan-15xx family of aitronic includes a range of compact Android terminals for data acquisition, data processing and wireless communication. The devices are characterized by high reliability and great expandability. With a full range of high-quality options an easy and safe data collection is ensured in various business fields. -
Page 6: Laserscanner Module
Lithium-ion batteries gradually, if they are not in use or during storage (self- discharge). The battery charge status should be checked regularly. The instructions contain information such as the state of charge to check and how the batteries must be recharged. ____________________________________________________________________ aitronic... - Page 7 Charge the battery to approximately 50% of capacity at least once every 6 months. Remove the battery and store these separately from your device. Store the battery at a temperature between 5 °C and 20 °C (41 °F and 68 °F). ____________________________________________________________________ aitronic...
-
Page 8: Getting Started
LogiScan-15xx Short Instruction ____________________________________________ 4. Getting started 4.1 Controls Loudspeaker Battery LED & Sensor Power Button Reserved Button Reserved Button Screen Navigation Bar Scanner Button Left Function Button Right Function Button Microphon Front LogiScan-1500 ____________________________________________________________________ aitronic... - Page 9 LogiScan-15xx Short Instruction ____________________________________________ Loudspeake Battery LED & Sensor Power Button Reserved Button Reserved Button Screen Navigation Bar QWERTY Keypad Microphone Front LogiScan-1550 ____________________________________________________________________ aitronic...
- Page 10 Button short Pressing Power Device start up / shut down, reboot or flight Button long mode Navigation Bar Function Return to the home screen Short Touch View a list of apps running Long Touch Return to the previous screen ____________________________________________________________________ aitronic...
-
Page 11: Sd Card Installation
LogiScan-15xx Short Instruction ____________________________________________ 4.2 SD Card Installation Open SIM slot. Open SD slot. Insert SD Card and lock SD slot and SIM slot. 4.3 SIM Card Installation Open SIM slot. Insert SIM Card. Lock SIM slot. ____________________________________________________________________ aitronic... -
Page 12: Battery Installation/Change
Using a device with pistol grip that Open the battery compartment lock. must be removed by unlocking the catch. Remove / insert the battery. With simultaneous pressure on the battery close the battery lock. Possibly attach pistol grip again. ____________________________________________________________________ aitronic... -
Page 13: Battery Charging
Please notice: To charge the pistol battery the LogiScan-15xx has to be charged with the cradle. 4.6 AppCenter The AppCenter contains a collection of apps for hardware-specific test functions, such as Barcode Scanner, RFID Reader, Fingerprint Sensor, GPS, Network, Bluetooth, NFC, Telephone, Camera, Printer. ____________________________________________________________________ aitronic... -
Page 14: Devin
RFID reader data to the keyboard buffer or the clipboard. Alternatively, a broadcast message is possible. Thus, the bar code scanner and RFID reader can serve as a data source for each app. The next pages contain devin’s user interface description. ____________________________________________________________________ aitronic... - Page 15 Scanned files can be output as a message Apps can also change scanner settings. If no bar code read and this option is enabled, the scanner turns off when you release the button, if the other switches off after a timeout. ____________________________________________________________________ aitronic...
- Page 16 For example it is very important for Code 2 of 5 int. to specify a length fixing, if no check digit is used. Before devin can be used, activation has to be performed. ____________________________________________________________________ aitronic...
-
Page 17: Broadcast Receiver
LogiScan-15xx Short Instruction ____________________________________________ 4-13 Broadcast Receiver If within section "Processing" "Broadcast de.aitronic.SCAN_DATA" was set, the scanned barcode or scanned RFID id. can be received in a receiver class of your app as follows: public class ScanCompletedReceiver extends BroadcastReceiver ScannerProvider provider = null;... -
Page 18: Barcode Types
ISSN EAN, PDF417, Macro PDF417, Micro PDF417 Aztec, Aztec Rune Data Matrix QR Code, MicroQR Maxicode US Postnet US Planet Japan Postal UK Postal Netherland KIX Code Australia Post USPS 4CB/OneCode/Intelligent Mail UPU FICS Postal Han Xin Signature Capture ____________________________________________________________________ aitronic... -
Page 19: Rfid Tag Types
LogiScan-15xx Short Instruction ____________________________________________ 4-15 RFID Tag Types Parameter „type“ RFID Tag Type IDCard ANIMAL_TAG HITAG HDXTAG EM4450 ISO14443A ISO15693 ____________________________________________________________________ aitronic... -
Page 20: Barcode Scanning
Press the power button at the side of the device short to switch on / off the device. Press the power button at the side of the device and hold to start up / shut down the device, to reboot or enable flight mode. ____________________________________________________________________ aitronic... -
Page 21: Disposal
Legal notice for waste disposal In accordance with the European legislation, it is forbidden to dispose of electrical and electronic equipment in the domestic waste. The aitronic GmbH takes back all of it placed on the market or sold electronic devices and accessories. -
Page 22: Technical Specifications
LF 125 kHz / 134.2 kHz, HDX/FDX-B (optional) HF 13.56 MHz, ISO14443A/ISO15693 (optional) UHF 860 – 960 MHz, EPC C1 GEN2/ISO18000-6C (optional) Camera (optional) 5 mega pixel, auto focus Developing Environment Operating System Android 4.4.2 Chainway SDK Programming Language Java Developing Tool Android Studio ____________________________________________________________________ aitronic... -
Page 23: Logiscan-1550
HF 13.56 MHz, ISO14443A/ISO15693 (optional) UHF 860 – 960 MHz, EPC C1 GEN2/ISO18000-6C (optional) Camera (optional) 8 mega pixel, auto focus, with LED Developing Environment Operating System Android 4.4.2 Chainway SDK Programming Language Java Developing Tool Android Studio ____________________________________________________________________ aitronic...
