- Page 1 LogiScan-15xx Operating Manual Edition 22.08.2017...
- Page 2 LogiScan-15xx Operating Manual Edition 22.08.2017...
- Page 3 +49 (0) 5251 29816-40 Internet: http://www.aitronic.de E-Mail: info@aitronic.de ___________________________________________________________ Copyright aitronic GmbH, 2017 All Rights reserved, in particular all extracts which correspond to the translation, the reprint and reproduction by copying or similar methods. Delivery and technical changes are subject to change.
-
Page 4: Table Of Contents
General ...................... 7-2 Autologin ....................7-3 Info ......................7-4 Transfer of the Scan Data to the Browser..........7-5 Method 1: JavaScript Function Call ............7-5 Method 2: KeyUp/KeyDown Events ............7-5 Playing Sounds with JavaScript ..............7-6 Edition 22.08.2017 _____________________________________________________ aitronic... - Page 5 Menu......................9-9 Info....................... 9-10 Settings ....................... 9-10 Article Master Data..................9-11 Data Collection ................... 9-11 Listing ......................9-12 Synchronization ..................9-13 10. Disposal ..............10-14 11. Technical Specifications ..........11-1 LogiScan-1500.................... 11-1 LogiScan-1550.................... 11-2 LogiScan-1560.................... 11-4 Edition 22.08.2017 _____________________________________________________ aitronic...
-
Page 6: General
LogiScan-15xx Operating Manual ___________________________________________ 1. General The LogiScan-15xx family of aitronic includes a range of compact Android terminals for data acquisition, data processing and wireless communication. The devices are characterized by high reliability and great expandability. With a full range of high-quality options an easy and safe data collection is ensured in various business fields. -
Page 7: Laserscanner Module
The security labels required are located under the laser light-exit window Never open any part of the laser module or perform any maintenance at it. The laser safety regulations may be hurt. The laser module must be repaired exclusively at the factory. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 8: Precautions For Using Batteries
Observe the loading instructions in the user manual of the product and / or the detailed online help to recharge your batteries. Edition 22.08.2017 _____________________________________________________ aitronic... - Page 9 Charge the battery to approximately 50% of capacity at least once every 6 months. Remove the battery and store these separately from your device. Store the battery at a temperature between 5 °C and 20 °C (41 °F and 68 °F). Edition 22.08.2017 _____________________________________________________ aitronic...
-
Page 10: Getting Started
LogiScan-15xx Operating Manual ___________________________________________ 4. Getting started Controls Loudspeaker Battery LED & Sensor Power Button Reserved Button Reserved Button Screen Navigation Bar Scanner Button Left Function Button Right Function Button Microphon Front LogiScan-1500 Edition 22.08.2017 _____________________________________________________ aitronic... - Page 11 LogiScan-15xx Operating Manual ___________________________________________ Loudspeake Battery LED & Sensor Power Button Reserved Button Reserved Button Screen Navigation Bar QWERTY Keypad Microphone Front LogiScan-1550 Edition 22.08.2017 _____________________________________________________ aitronic...
- Page 12 Pressing Power Device start up / shut down, reboot or flight Button long mode Navigation Bar Function Return to the home screen Short Touch View a list of apps running Long Touch Return to the previous screen Edition 22.08.2017 _____________________________________________________ aitronic...
-
Page 13: Sd Card Installation
LogiScan-15xx Operating Manual ___________________________________________ SD Card Installation Open SIM slot. Open SD slot. Do not insert SD Card in rather insert SD Card in lock SD and SIM Slots. this way and this manner, Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 14: Sim Card Installation
LogiScan-15xx Operating Manual ___________________________________________ SIM Card Installation Open SIM slot, and unfold it. rather insert SIM Card in lock SIM slot. Do not insert SIM Card in this way and this manner, Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 15: Battery Installation/Change
Using a device with pistol grip that Open the battery compartment lock. must be removed by unlocking the catch. Remove / insert the battery. With simultaneous pressure on the battery close the battery lock. Possibly attach pistol grip again. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 16: Charging The Battery
Insert/remove the Pistol Grip To mount / remove the pistol grip, the device must be shut down: Press and hold the power button on the side of the device, and then press "Turn off" in the menu that appears. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 17: Appcenter
LogiScan-15xx Operating Manual ___________________________________________ AppCenter The AppCenter contains a collection of apps for hardware-specific test functions, such as Barcode Scanner, RFID Reader, Fingerprint Sensor, GPS, Network, Bluetooth, NFC, Telephone, Camera, Printer. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 18: Barcode Scanning
Press the power button at the side of the device short to switch on / off the device. Press the power button at the side of the device and hold to start up / shut down the device, to reboot or enable flight mode. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 19: Barcode And Rfid Management
For example, The barcode types to be accepted can be set. Web-based application The aiBrowser from aitronic was is executed in a browser by calling a developed for the barcode/RFID data URL. transfer in web-based applications. Data transfers must be done by broadcast. -
Page 20: Devin
Thus, the bar code scanner and RFID reader can serve as a data source for each app. The next pages contain devin’s user interface description. Only the options for the available hardware are shown. For example, when there is no RFID module no RFID options are displayed. Edition 22.08.2017 _____________________________________________________ aitronic... - Page 21 If no bar code read and this option is enabled, the scanner turns off when you release the button, if the other switches off after a timeout. devin sound output can be suppressed. Barcode and RFID data can be manipulated via JavaScript (refer to devin Programming Manual). Edition 22.08.2017 _____________________________________________________ aitronic...
- Page 22 Code 2 of 5 int. to specify a length fixing, if no check digit is used. Before devin can be used, activation has to be performed. With this button updates can be searched for. Edition 22.08.2017 _____________________________________________________ aitronic...
-
Page 23: Aibrowser
By default, the default URL is about: blank, i.e. As long as no other URL is set, a white page is displayed. Settings Previous Web Page Reload set URL After tapping the hardware button menu (for Android 5, press and hold), the menu bar will appear Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 24: Settings
If the password is forgotten, a master password that is valid only for the day can be requested via the aitronic support. After entering the master passwords, the password is reset to ai1500. -
Page 25: Autologin
You can specify the HTML ID of the field on which JavaScript-Click is to be executed after completing the Username and Password fields. However, this works only if both Username and Password are stored. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 26: Info
LogiScan-15xx Operating Manual ___________________________________________ Info About the copyright and version of the app. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 27: Transfer Of The Scan Data To The Browser
Here, after a successful scan, the data are passed to a JavaScript function on the web page. This function must be implemented by the customer on the website. The call is: Aitronic.scanDataReceived('barcode') Example: var Aitronic = { scanDataReceived: function(dat){ document.getElementById("idcode").value=dat; return true; Method 2: KeyUp/KeyDown Events Keyboard input is generated from the scanned data. -
Page 28: Playing Sounds With Javascript
Sounds can be stored in the format wav, ogg or mp3 on the SD card of the device. For the aiBrowser to process these, they must be stored in folder /aitronic/aiBrowser/sounds. After changing the sound files, the aiBrowser must be restarted to read the new files. The files can then be played over the provided interface. -
Page 29: Scannerdemo
Barcodes of type Code 2/5 interleaved can be allowed. Switch on the scanner or RFID module. Switch off the scanner or RFID module. Scanned codes are output with the preceding type. Scan barcode or RFID tag. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 30: Aiinventur
LogiScan-15xx Operating Manual ___________________________________________ 9. aiInventur The aitronic App aInventur is used for demonstrating barcode scanners and/or RFID readers and can be used for simple inventories. In order to use the app with barcode scanner and/or RFID reader, the app devin must be installed and enabled. -
Page 31: Start Screen
Selection of screen Menu Selection of screen Article Master Data Selection of screen Data Collection Selection of screen List Selection of screen Synchronization Menu Selection of screen Settings Selection of screen Info Displaying the Licence Agreement Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 32: Info
If this option is selected, the quantity is scaled up when scanning the same item numbers. If this option is selected, the data is synchronized with FTP instead of with MTP. The appropriate FTP settings must be made for this. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 33: Article Master Data
The item number can be scanned or entered manually. The default quantity "1" can be incremented, decremented, or manually changed. When scanning the next barcode, the current record is automatically saved. Manually store the current record. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 34: Listing
LogiScan-15xx Operating Manual ___________________________________________ 9-12 Listing After confirming a query, the entire recorded data can be deleted. After tapping a data record, it can be edited or deleted. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 35: Synchronization
MTPWin has to be configured accordingly (refer to MTPWin Operating Manual), After tapping the button "START SYNCHRONIZATION", synchronization is performed. After the synchronization has been completed, the system asks whether the data on the device is to be deleted. Edition 22.08.2017 _____________________________________________________ aitronic... -
Page 36: Edition 22.08.2017
Legal notice for waste disposal In accordance with the European legislation, it is forbidden to dispose of electrical and electronic equipment in the domestic waste. The aitronic GmbH takes back all of it placed on the market or sold electronic devices and accessories. - Page 37 WCDMA/HSDPA/HSPA+ (850/1900/2100 MHz) GSM/GPRS/EDGE (850/900/1800/1900 MHz) WLAN IEEE802.11b/g/n, internal antenna WPAN Bluetooth v4.0 Low Energy GPS (embedded A-GPS) Data Collection Barcode Scan Engine 1D barcode (Symbol SE955, laser）(optional) (optional) 2D CMOS laser scanner: Symbol SE4750 (optional) Edition 22.08.2017 _____________________________________________________ aitronic...
- Page 38 1 PSAM, 1 SIM, 1 MicroSD Audio 0.5 W Performance Characteristics Cortex-A7 1,3 GHz Quad Core Memory 1 GB RAM, Build-in 4 GB Flash, MicroSD max. 32 GB expansion Interface USB Micro-B, serial port RS-232 (TTL) Edition 22.08.2017 _____________________________________________________ aitronic...
- Page 39 Peer-to-Peer, NFC Forum Tag Type 1-4, Sony FeliCa UHF (860 – 960 MHz) EPC C1 GEN2/ISO18000-6C Camera (optional) 8 mega pixel, auto focus, with LED Developing Environment Operating System Android 4.4.2 Chainway SDK Programming Language Java Developing Tool Android Studio Edition 22.08.2017 _____________________________________________________ aitronic...
- Page 40 2G: GPRS (900/1800MHz), 3G: WCDMA B1/B8, 4G: FDD-LTE B1/B3/B7/B8/B20 WLAN IEEE802.11b/g/n, internal antenna WPAN Bluetooth v4.0 Low Energy GPS (embedded A-GPS) Data Collection Barcode Scan Engine 1D Barcode Laser Scanner (Symbol SE955/SE655) (optional) 2D CMOS Laser Scanner: Symbol SE4500 Edition 22.08.2017 _____________________________________________________ aitronic...
- Page 41 Peer-to-Peer, NFC Forum Tag Type 1-4, Sony FeliCa UHF (860 – 960 MHz) EPC C1 GEN2/ISO18000-6C Camera (optional) 8 mega pixel, auto focus, with LED Developing Environment Operating System Android 5.1 Chainway SDK Programming Language Java Developing Tool Android Studio Edition 22.08.2017 _____________________________________________________ aitronic...
