- Page 1 EM456x - Wireless N modem router...
-
Page 2: Table Of Contents
ENGLISH EM456x - Wireless N modem router Warnings and points of attention Due to laws, directives and regulations set out by the European Parliament, this device could be subject to limitations concerning its use in certain European member states. In certain European member states the use of this product could be prohibited. More information regarding this warning can be found in the Declaration of Conformity on the last page of this document! Table of contents... -
Page 3: Introduction
Congratulations with the purchase of this high-quality Eminent product! This product has undergone extensive testing by Eminent’s technical experts. Should you experience any problems with this product, you are covered by a five-year Eminent warranty. Please keep this manual and the receipt in a safe place. -
Page 4: Explanation Of The Back
ENGLISH POWER: Will be lit when the power supply is connected. DSL: Will be lit when an ADSL connection has been established. INTERNET: Will be lit when an internet connection with your provider has been established. WLAN: Will blink when the modem has finished booting and the wireless network is active. -
Page 5: Installation Using The Wizard
ENGLISH WLAN: WLAN button: Used to disable the broadcast of the wireless signal. WPS: WPS button. Use this button to secure the wireless network using WPS. Only applicable when using WPS adapters. 2.0 Installation using the wizard The easiest way to install the EM456X is by using the installation wizard, as described in this chapter. -
Page 6: Logging In To The Em456X
ENGLISH Connect the other end of this network cable to the network connection of your computer’s network adapter. Press the ‘ON/OFF’ switch on the EM456X once to turn the EM456X on. Is my EM456X correctly connected to the power grid? Verify whether the ‘POWER’ LED is lit. -
Page 7: Configuration For Dhcp Providers (Tele2, Babyxl, Online Family)
ENGLISH 12. Fill in ‘48’ at ‘VCI’. 13. Select ‘PPPoA Vc-Mux’ at ‘Connection Type’. 14. Click ‘NEXT’. 15. Click ‘NEXT’. 16. The modem will save the settings. Perhaps you have to login again with your newly chosen password, set at step 4 and 5. 17. -
Page 8: Manually Setup And Secure The Wireless Network
ENGLISH 4.0 Manually setup and secure the wireless network Because everyone can receive a network’s wireless signal, we recommend you to secure your wireless network. There are several security methods available. To use one of the methods, it is very important that each wireless adapter must support this wireless security form. -
Page 9: Wpa Security
ENGLISH *Write down the security type and the chosen password: WPA2 Password: ______________________________________________________ 4.4 WPA security Click ‘Network Setup’. Click ‘Wireless’. You can change the name of your wireless network at the ‘SSID’ field. After settings up another name, this name will be seen as a wireless network. Click at he field behind the ‘Authentication Type’... -
Page 10: Setting Up The Wireless Network On Your Computer
10 | ENGLISH Note: In case your are working wirelessly already: The connection will be terminated the moment the security has been set in the EM456X (WPA(2), WEP) and not yet in your wireless adapter. The moment you have set the security for your wireless card too, the connection will be established again. -
Page 11: Setting Up A Wireless Network Using Windows 7
11 | ENGLISH Choose ‘Add a wireless network within range of this computer’. The computer will start to search for wireless networks. Choose your own network. Click ‘Connect’. 10. A notification will be shown on screen: ‘Type the network security key or passphrase for your network’. -
Page 12: Control Your Internet Connection
12 | ENGLISH 10. You have successfully secured your connection with the use of WPS! 7.0 Control your internet connection If you want extra security besides the already existing WPA(2) or WEP security, you can add ‘Wireless MAC Address Control’. A MAC address is a unique code, or identifier, provided to almost every network adapter. -
Page 13: Blocking Websites Using Url Filtering
13 | ENGLISH Do you want specific wireless MAC Addresses to be blocked? Then choose ‘Deny Association’ to deny the selected MAC Address access. 7.2 Blocking websites using URL Filtering Open your web browser (For example: Internet Explorer, Netscape or Firefox). Type ‘http://192.168.1.1’... -
Page 14: Frequently Asked Questions
Now what? Eminent has the mostly used VPI and VCI values for a DHCP connection written down (usable for the Netherlands):... - Page 15 15 | ENGLISH BabyXL/Telfort 0/34 BBned/Tele2 Super 0/35 Online Family 8/35 How can I reset the modem to factory defaults? Use the following steps to reset the EM456X: Turn on the modem and wail until it has finished starting. Now press the little reset button on the bottom with a paperclip for about 10 seconds.
-
Page 16: Service And Support
300Mbps, whilst the EM4562 has one antenna and can reach wireless speeds up-to 150Mbps. 10.0 Service and support This users manual has been carefully written by Eminent’s technical experts. If you have problems installing or using the product, please fill out the support form at the website www.eminent-online.com/support. -
Page 17: Declaration Of Conformity
Eminent warranty. Products are not covered by the Eminent warranty when subjected to incorrect/improper use, external influences and/or when opened by parties other than Eminent. - Page 18 EM456x | 02-2010...
