Peiying PY0105 Owner's Manual page 16

Owner's manual
HINT: the device can be used wirelessly – connecting the camera
to a wireless module to avoid routing AV signal cable throughout
the vehicle. For cordless use, it is necessary to purchase an
additional wireless module (not included in this set!).
SPeciFicatiOn
camera
• Image sensor: ¼ color CMOS
• Resolution: 640x480 px
• Lens angle: 140 degrees
• Min. illumination: 0,3 Lux
• Video output: CVBS 1.0 V (p-p) / 75 Ohm
• Power consumption: < 1,5 W
• Power supply: 9-15 V; 150 mA
general
• Distance scale
• Respond distance: 0,4 – 2 m
• TV system: PAL
• Image: mirror
• Auto on when on reverse gear
• S/N ratio: 48 dB
• Gyrosensor
• Operational temperature: -20°C ~ +70 °C
• Storage temperature: -30°C ~ +80 °C
• Ingress protection rating: IP67
• Set includes: camera in license plate frame, AV cable (6 m),
power supply cable (1,5 m), manual
16
EN
