7.0

PRE-OPERATING SYSTEM CHECK

Once material, water and electrical connections are made, the NWB Series dryer should
be given a final checkout.

7.1 Starting The Dryer

Turn the main disconnect switch to "ON" position to power the dryer. The Main Menu will
appear. To start the dryer depress the "ON/OFF" button on the controller.
The blowers and heaters are now energized and the desiccant wheel will begin turning
and start to dry the return air. It will take several minutes and a couple revolutions of
the wheel, for the dew point to get down to the -40° dew point.

7.2 Checking Electrical Phase

Your NOVATEC NWB Dryer includes Phase Detection. This is particularly
important for dryers that may be moved around the plant. When you turn the MAIN
Disconnect switch to the ON position, a Pop-Up Alarm will appear on the screen if
the connection is not correct. You should immediately correct this condition.
WARNING:
Any wiring procedure should only be done by a qualified electrician familiar with three
phase electrical wiring.
