Project #399
Project #401
Oscillation
Sounds (III)
OBJECTIVE: Show variations of project 399.
Use the circuit in project 399. Connect the
whistle chip (WC) across points B & E.
OBJECTIVE: To make sounds with an oscillator circuit.
Turn on the switch (S1) and the speaker (SP) emits an oscillating
sound. Now connect the whistle chip (WC) across points A & B and
the sound changes.

Oscillation Sounds (II)

OBJECTIVE: Show variations of project 399.
Use the circuit in project 399. Connect the whistle chip (WC) across
points C & D.
Project #402
Oscillation
Sounds (IV)
OBJECTIVE: Show variations of project 399.
Use the circuit in project 399.
whistle chip under capacitor C2. Turn on the
switch (S1) and the circuit oscillates at
another frequency.

Oscillation Sounds

Project #400
Project #403
Touch-Control
Oscillator
OBJECTIVE: Show variations of project 399.
Install the Using project 399, replace the 100kΩ resistor
(R5) with the photo resistor (RP). Wave your
hand over the resistor and the frequency
changes.
-36-
