4.8. Entering Offset Value (offset)
Offset value can be entered using this menu to device. Returned to entered offset value when pressed to
rst button or signal comes from Z input. If offset value is zero and reset button is pressed, zero will write on
the screen. Found offset menu with up-down button and pressed to prg button then bottom row choice
flashes. Set to value with up-down button and each press of the button moves to the left in a digit. Then
you can save them.

4.9. Reset With Button (rst btn)

This menu allows becoming active RST button on the front panel. While RST button is active, the value of
the on-screen will be reset when pressed up-down button for two times at operating mode or return to
offset value. In order to open RST button, pressed to prg button at operating mode. Found Tot rst menu
with up-down button and pressed to prg button then one of reset/no reset choice at bottom row flashes.
Change to option with up-down button and save choice with prg button then return to operation mode
with rst button
.

4.10. Reset With External Z Signal (rst inpt)

Resetting at device screen can be done with by applied from outside external an encoder Z signal or a
switch when external Z input is be activated. While you make active the Z input, select the edge you will
make reset on. You can select one of rising and falling edges. If you don't want to use Z input, select to
noreset option. In order to activate to Z input, pressed to prg button at operating mode and found rst inpt
menu with up-down button.
down button. Then save it by prg button.
.
 . 
.
 . 
When prg button is pressed, options will flash
.
PRG
 . 
- 8 -

 . 


and made the selection with up-


