Setup Guide

Read this first

This guide describes the setup tasks and important conditions about the installation site that must
be met in order to enable use of this machine.
R1-191009
R1-190925

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LD-300 and is the answer not in the manual?

Questions and answers

Related Manuals for DGSHAPE LD-300

Summary of Contents for DGSHAPE LD-300

  • Page 1: Setup Guide

    Setup Guide Read this first This guide describes the setup tasks and important conditions about the installation site that must be met in order to enable use of this machine. R1-191009 R1-190925...
  • Page 2 • The contents of this document and the specifications of this product are subject to change without notice. • DGSHAPE Corporation assumes no responsibility for any damage that may occur through use of this product, re- gardless of any failure to perform on the part of this product or of any errors in this document. Damages include but are not limited to damage caused by the specifications or performance of the product, damage caused by non-use of the product, and damage caused by deliverables obtained through use of this product.

  • Page 3: Federal Communications Commission

    Address : 15363 Barranca Parkway Irvine, CA 92618 U.S.A. Telephone : 949-727-2100 Type of Equipment : METAL PRINTER(Hot Stamping Printer) Model Name : LD-300 NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.

  • Page 4: Table Of Contents

    Specifications ....................29 Windows® is a registered trademark or trademark of Microsoft® Corporation in the United States and/or other countries. Company names and product names are trademarks or registered trademarks of their respective holders. Copyright © 2019 DGSHAPE Corporation http://www.dgshape.com/...

  • Page 5: To Ensure Safe Use

    To Ensure Safe Use Improper handling or operation of this machine may result in injury or damage to property. Points that must be observed to prevent such injury or damage are described as follows. About WARNING and CAUTION Notices WARN- Used for instructions intended to alert the user to the risk of death or severe injury should the unit be used improperly.
  • Page 6 Contents Incorrect operation may cause injury WARNING WARNING Always unplug the power cord when Never climb or lean on the machine. attaching or removing parts and optional The machine is not made to support a per- parts and when performing cleaning or son.
  • Page 7 Contents Danger of electrical short, electrical shock, or fire WARNING WARNING Connect to a power outlet that complies Never place any flammable object close with this machine’s ratings (for voltage, to the machine. Never use a combustible frequency, and current). aerosol spray close to the machine.
  • Page 8 Contents Important notes about the power cord, plug, and power outlet. Never place any object Never bend or twist the Never pull the power cord Never bundle, bind, or roll on top of or subject the power cord with excessive with excessive force.

  • Page 9: Warning Labels

    Contents Warning Labels Warning labels are affixed to the machine to make areas of danger immediately clear. The mean- ings of these labels are as follows. Be sure to heed their warnings. Also, never remove the labels or allow them to become obscured. Caution: Pinching Hazard Exercise caution to prevent fin- gers from being pinched when...

  • Page 10: Pour Utiliser En Toute Sécurité

    Pour utiliser en toute sécurité La manipulation ou l’utilisation inadéquate de cet appareil peuvent causer des blessures ou des dommages matériels. Les précautions à prendre pour prévenir les blessures ou les dommages sont décrites ci-dessous. Avis sur les avertissements ATTEN- Utilisé...
  • Page 11 Pour utiliser en toute sécurité Une utilisation incorrecte peut causer des blessures ATTENTION ATTENTION Toujours débrancher le câble d’alimen- Ne jamais grimper ni s'appuyer sur la ma- chine. tation lors de la fixation ou du retrait La machine n'est pas conçue pour supporter le de pièces et de pièces en option et du poids d'une personne.
  • Page 12 Pour utiliser en toute sécurité Risque de décharge ou de choc électrique, d’électrocution ou d’incendie ATTENTION ATTENTION Brancher à une prise électrique conforme Ne pas utiliser une source d’alimentation aux caractéristiques de cet appareil (ten- autre que celle fournie par l’adaptateur en c.a. sion, fréquence et courant).
  • Page 13 Pour utiliser en toute sécurité ATTENTION ATTENTION Si l'appareil doit rester inutilisé pendant Utiliser uniquement des accessoires d'origine une longue période, débrancher le câble (accessoires en option, articles consomma- d'alimentation. bles, câble d'alimentation et autres articles Cela peut prévenir les accidents en cas de semblables), compatibles avec l'appareil.
  • Page 14 Pour utiliser en toute sécurité Vignettes d’avertissement Des vignettes d’avertissement sont apposées sur l’appareil pour qu’il soit facile de repérer les zones dangereuses. La signification des vignettes est donnée ci-dessous. Respecter les avertissements. Ne jamais retirer les vignettes et ne pas les laisser s’encrasser. Partie supérieure Prudence : Risque de pince- ment...

  • Page 15: Important Notes On Handling And Use

    Important Notes on Handling and Use This machine is a precision device. To ensure the full performance of this machine, be sure to ob- serve the following important points. Failure to observe these points may not only result in loss of performance but may cause faulty operation or a malfunction.

  • Page 16: About The User's Manuals

    LD-300 Setup Guide (this document) LD-300 Setup Guide (this document) This document also provides instructions for how to install the This document also provides instructions for how to install the included software.

  • Page 17: Checking The Included Items

    Light-absorbing films (10) large; 1 each) Head detection jigs (high and low; Film frame (1)*1 Positioning guide pins (3) 1 each) knobs (small; 2)*1 DGSHAPE Software Package Setup Guide (this document; 1) CD (1) *1: Attached to the machine before shipment. ...

  • Page 18: Installing The Software

    ※ As this software is a 32-bit application, it runs on WOW64 (or Windows-On-Windows 64) under the 64-bit version of Windows. For the latest information, see the DGSHAPE Corporation website (http://www.dgshape.com). The Software You Can Install and Set Up This is a program for creating imprint data. It enables you import and crop METAZAStudio images to imprint, and perform editing to add text, boxes, and the like.

  • Page 19: Installing The Software

    • Even if METAZAStudio and SFEdit2 have already been installed, be sure to install the software from the DGSHAPE Software Package CD included with the machine. • If METAZAStudio and SFEdit2 have been installed, carry out the installation without uninstalling these pieces of software.
  • Page 20 Installing the Software Select[Install],[DGSHAPELD-300]forthemodelname,and[USB]fortheport,andthenclick [Start]. Installation starts. Proceed by following the on-screen instructions. If the screen shown below appears during installation, click [Install]. Followthedisplayedinstructionsandcontinuewiththeinstallation. Installation information for each software item will be displayed automatically as needed. Whenthefollowingwindowappears,click[OK]. This completes the installation of all items.
  • Page 21 Installing the Software How to Display the LD Driver Printing Preferences Window The Printing Preferences window can be displayed after LD Driver installation is complete. Procedure Displaytheprintericon. Windows10 Clickthe[Start]menuonthecomputer. Click[WindowsSystem],andthenclick[ControlPanel]. Click[Viewdevicesandprinters]. Windows8.1 Right-clickthe[Start]menuonthecomputer. Click[ControlPanel]. Click[DevicesandPrinters]. Windows7 Clickthe[Start]menu. Click[DevicesandPrinters]. Right-clickthe[DGSHAPELD-300]icon,andthenclick[Printingpreferences]. ...
  • Page 22 Installing the Software The LD Driver Printing Preferences window appears. How to Open the LD Driver Help Open the LD Driver Printing Preferences window, and then click [Help]. " P.19 「HowtoDisplaytheLDDriverPrintingPreferencesWindow」  ...
  • Page 23 Installing the Software How to View the Electronic-format Manual Windows10 Fromthe[Start]menu,click[DGSHAPELD-300],andthenclick[LD-300User'sManual]. Windows8.1 Onthe[Start]screen,click .Onthe[Apps]screen,clickthe[LD-300User'sManual]iconun- der[DGSHAPELD-300]. Windows7 From the [Start] menu, click [All Programs], [DGSHAPE LD-300], and then click [LD-300 User's Manual]. ...

  • Page 24: Installation

    Installation Installation Environment WARNING Never install outside or in any location where exposure to water or high humidi- ty may occur. Current leakage may cause electrical shock or fire. WARNING Never install the machine close to any flammable object or in a gas-filled location. Combustion or explosion may occur. WARNING Position the machine so that the power-cord plug is within immediate reach at all times.

  • Page 25: Removing And Storing The Retainers

    Installation Installation Space Ensure that at least the following amount of space is available. Work space Installation space 1.0 m (39.4 in.) 2.0 m (78.7 in.) Removing and Storing the Retainers Retaining materials are attached to protect the machine from vibration during shipment. When installa- tion is complete, remove these retainers.
  • Page 26 Installation Procedure Makesurethepowercordisnotconnected. Whileliftingtheheadup,removeretainerA. Retainer A Hexagonal wrench (large) Slowlymovetheheadtotheright. Be careful to avoid moving it with too much force. Head ...
  • Page 27 Installation RemoveretainersBandC. Retainer C Retainer B Hexagonal wrench (large) Hexagonal wrench (large) Storing the retainers The removed retainers and package are required when moving the machine to a different location. Store them carefully so that they do not get misplaced. Store the retainers by attaching them to the back of this machine.

  • Page 28: Connecting The Machine To A Computer

    Installation Connecting the Machine to a Computer WARNING Do not use with any electrical power supply that does not meet the ratings displayed on the AC adapter. Use with any other power supply may lead to fire or electrical shock. WARNING Never use any AC adapter or power cord other than the AC adapter and power cord included with the machine.

  • Page 29: Affixing The Light-Absorbing Film To The Film Frame

    Installation Affixing the Light-absorbing Film to the Film Frame Item used Light-absorbing Film frame film Procedure Orientthefilmframesothattheadhesivesheetsurfacefacesup. Adhesive sheet Supports Peelofftheprotectivefilmoftheadhesivesheet. Protective film ...
  • Page 30 Installation Affixthelight-absorbingfilmtothefilmframe. Match the film to the shape of the film frame, ensuring that the film does not protrude outside the edges of the film frame. Not OK Light-absorbing film Important! Thelight-absorbingfilmhasamaterialsideandalensside.Youcanensurethatthefilmisaffixedwith thecorrectsidefacingupbymatchingthefilmtotheshapeofthefilmframe.Exercisecautionwhenaf- fixingthefilm.Usingthemachinewiththeincorrectsidefacingupmayleadtomalfunctions. ...

  • Page 31: Specifications

    Specifications LD-300 Imprintable material Acrylic, polycarbonate, polypropylene, polystyrene, ABS, leather, polyurethane, vinyl chloride Loadable material (Width) With base table: 323 mm (12.72 in.), without base table: 281 mm (11.06 in.) width and thickness (Thickness) 216 mm (8.50 in.) " User’sManual“WorkArea”...
  • Page 32 For China 产品中有毒有害物质或元素的名称及含量 有毒有害物质或元素 部件名称 六价铬 多溴联苯 多溴二苯醚 铅(Pb) 汞(Hg) 镉(Cd) (Cr(Ⅵ)) (PBB) (PBDE) 印刷电路板 × ○ × ○ ○ ○ 头部 × ○ ○ ○ ○ ○ 壳体、底架 × ○ ○ ○ ○ ○ 电源 × ○ × ○ ○...
