• To ensure safe use with a full understanding of this machine's performance, please be sure to read through
this manual completely.
• Store this manual in a safe place where it can be referred to when needed.
• Reproduction, citation, or translation, in whole or in part, of this manual is prohibited without the express
written consent of DGSHAPE Corporation.
• The contents of this operation manual and the specifications of this product are subject to change without
notice.
• DGSHAPE Corporation assumes no responsibility for any damage that may occur through use of this product,
regardless of any failure to perform on the part of this product or of any errors in this document. Damage
includes but is not limited to damage caused by the specifications or performance of the product, damage
caused by non-use of the product, and damage caused by deliverables obtained through use of this product.
Such damage can be either direct or indirect.
Setup Guide
USB
R2-170621
Advertisement
Table of Contents
Related Manuals for DGSHAPE DWP-80S
Summary of Contents for DGSHAPE DWP-80S
- Page 1 • The contents of this operation manual and the specifications of this product are subject to change without notice. • DGSHAPE Corporation assumes no responsibility for any damage that may occur through use of this product, regardless of any failure to perform on the part of this product or of any errors in this document. Damage includes but is not limited to damage caused by the specifications or performance of the product, damage caused by non-use of the product, and damage caused by deliverables obtained through use of this product.
- Page 2 This device is Class A Information Technology Equipment. This device may cause electronic interference when used in a household environment. In such cases, the user may be asked to implement appropriate measures. VCCI-A DGSHAPE Corporation has licensed the MMP technology from the TPL Group.
-
Page 3: Table Of Contents
Printing is No Longer Possible after Using Windows 10 ..............44 Uninstalling the Projector driver ........................ 44 Correct Installation of the DWP-80S Driver Is Impossible (Listed as “Unspecified”) ....45 Windows® is either a registered trademark or trademark of Microsoft® Corporation in the United States and/or other countries. -
Page 4: Important.notes.on.handling.and.use
Important Notes on Handling and Use This machine is a precision device. To ensure the full performance of this machine, be sure to observe the following important points. Failure to observe these may not only result in loss of per- formance but may also cause malfunction or breakdown. -
Page 5: Photo-Curable Resin
Use different liquid material vats depending on the type of resin being used Using the same liquid material vat with different types of resin may hasten the deterioration of the liquid material vat. Contact your authorized DGSHAPE Corporation dealer or visit the DGSHAPE Corporation website (http://www.dgshape.com/) to purchase liquid material vats. -
Page 7: Setup Guide
Setup Guide... -
Page 8: 1. Checking The Included Items
Washing containers (2) Liquid material vat (1) Work tray (1) Strainers (3) Rubber gloves (1 pair) DGSHAPE Software Pack- Read this first (1) age CD (1) Setup Guide (1) * 1: One is attached to the machine before shipment. Setup.Guide... -
Page 9: About The Documentation For This Machine
Items to Prepare Yourself (Ultrasonic cleaner) An ultrasonic cleaner is required for cleaning printed objects. Please prepare an ultrasonic cleaner separately. Contact your authorized DGSHAPE Corporation dealer or visit the DGSHAPE Corporation website (http://www.dgshape.com/) to purchase an ultrasonic cleaner. Setup.Guide... -
Page 10: Installation
2. Installation Important Notes on Installation Be sure to read the booklet “Read this first” before installing the machine. Install the machine in a level, stable location offering good operating conditions. An unsuitable location can cause faulty operation or breakdown. Be sure to perform operations as specified by the instructions, and never WARNING touch any area not specified in the instructions. -
Page 11: Checking The Installation Space And Height
2. Installation Checking the Installation Space and Height The space shown below is required in order to use this machine. 1,000 mm (39.4 in.) 500 mm (15.75 in.) Installation space Work space Installation Location Height The installation location should be above the work floor by 600 mm (23.6 in.) or more. This ma- chine is a desktop-type unit. -
Page 12: Connecting The Power Cables
I mp or t a nt : Do n ot co nn e ct t h e mac hine to the co m p ute r yet. The machine must be connected to the computer after the driver has been installed. Be sure to make the connection according to the instructions given under "Installing the Software and Manuals." Connecting to the computer without doing so may cause driver installation to fail and make use impossible. If you connect the computer and the machine by mistake, you will have to perform operations such as uninstalling the driver. Refer to the following page for more information. " P.32 "Troubleshooting" (P.38"DWP-80S Driver Installation Is Impossible", P.44"Uninstalling the Projector driv- er") Power cable AC adapter Setup.Guide... -
Page 13: Removing And Storing The Retainers
2. Installation Removing and Storing the Retainers Retainers are attached to protect the machine from vibration during shipment. When installation is complete, remove these. Under no circumstances should you move the Z-axis unit with your hands. WARNING Doing so may cause a breakdown. Z-axis unit Procedure Remove the tape on the front surface of the machine. Switch on the power. The initial operation starts. When the light stops flashing and remains steadily lit, initial opera- tion is complete. - Page 14 2. Installation Remove the tape securing the Z-axis unit and remove the retainer. I mp or t a nt The retainers will be required when moving the machine to a different location. Store them careful- ly so that they do not get misplaced. Setup.Guide...
-
Page 15: Adjusting The Angle
2. Installation Adjusting the Angle Items Used in This Procedure Level gauge (1) Wrench (1) Procedure Open the front cover. Place the level gauge on the front of the shutter. Align the line on the shutter with the line on the level gauge and the center of the shutter with the center of the level gauge. Shutter Use the adjusters on the bottom surface of the machine to adjust the angle. -
Page 16: 3. Installing The Software
Operation of the machine has been verified using an Intel Graphics HD 4000 graphics card built in to the CPU. * For the latest information, see the DGSHAPE Corporation website (http://www.dgshape.com/). Software and Manuals to Install This dedicated software is used for outputting 3D data in STL Quick Denta format. -
Page 17: Differences Between Installation Procedures According To Windows Version
3. Installing the Software Differences between Installation Procedures According to Windows Version Follow the table shown below to carry out the correct installation according to the version of Win- dows you are using. Earlier than " P.23 "Installing the Software and Manuals (Windows 10 version 1607 Version Earlier than 1607, Windows 8.1/7)"... -
Page 18: Installing The Software And Manuals (Windows 10 Version 1607 And Later)
Begin installation. Before installation, confirm that the machine and the computer are not connected with the USB cable. Log on to Windows as the computer's administrator (or as an "Administrators" ac- count). Insert the DGSHAPE Software Package CD into the CD-ROM drive of the computer. When the automatic playback window appears, click [Run menu.exe]. If a "User Account Con- trol" window appears, click [Allow] or [Yes], and then continue with the installation. The setup menu screen appears automatically. Setup.Guide... - Page 19 3. Installing the Software Click [Install]. Install the DWP-80S driver, Quick Denta, and the DWP-80S user’s manual all at once. " P.14 "Software and Manuals to Install" The names of the drivers, software, and other files to be installed appear. M E M O The software can also be installed separately.
- Page 20 3. Installing the Software Install the DWP-80S driver. Click [Install], select "Roland DWP-80S" for the model name and "USB" for the port, and then click [Start]. The DWP-80S driver installation begins. Follow the on-screen explanations to proceed with the installation. If the following window appears during installation, click [Install]. Installation of the DWP-80S driver will proceed. Follow the on-screen explanations to proceed with the installation. When the following window appears, click [Finish]. To continue, proceed with installation of Quick Denta.
- Page 21 3. Installing the Software Install Quick Denta and the manuals. When the following window appears, click [Next]. Quick Denta installation begins. Follow the on-screen explanations to proceed with the installa- tion. When the following window appears, click [Finish]. To continue, proceed with installation of the DWP-80S user’s manual. Setup.Guide...
- Page 22 3. Installing the Software When the following window appears, click [Next]. Installation of the DWP-80S manuals begins. Follow the on-screen explanations to proceed with the installation. When the following window appears, click [Finish]. When the following window appears, click [OK]. All installations are now complete. Click [X] on the setup menu. Remove the DGSHAPE Software Package CD from the computer. Setup.Guide...
- Page 23 M E M O Do not remove the USB cable or disconnect from the network until the two processes shown below are complete. • After connecting the machine to the computer, the DWP-80S driver installation begins. From [Control Panel], click [View devices and printers]. When the machine appears under "Printers," the installa- tion of the DWP-80S driver is complete.
- Page 24 3. Installing the Software When the following screen appears, click [Home] (or [Settings]). Click [Devices]. Click [Connected Devices] and verify that “PJ526ABRL” (or “DisplayLink USB Graphics Device”) is listed twice under “Other Devices.” If “PJ526ABRL” (or “DisplayLink USB Graphics Device”) is not listed twice, refer to the following. " P.41"Projector driver Does Not Operate Correctly" M E M O : W he n t h e f ollo win g wi n dow app ear s When the following window appears, click [Restart Now].
-
Page 25: Installing The Software And Manuals (Windows 10 Version Earlier Than 1607, Windows 8.1/7)
[Allow] or [Yes], and then continue with the installation. The setup menu screen appears automatically. Click [Install]. You can install the DWP-80S driver, the projector driver, Quick Denta, and the DWP-80S user’s manual all at once. " P.14 "Software and Manuals to Install"... - Page 26 3. Installing the Software Click [OK]. Install the DWP-80S driver and projector driver. Click [Install], select "Roland DWP-80S" for the model name and "USB" for the port, and then click [Start]. The DWP-80S driver installation begins. Follow the on-screen explanations to proceed with the installation. If the following window appears during installation, click [Install]. Installation of the DWP-80S driver will proceed. Follow the on-screen explanations to proceed with the installation. Setup.Guide...
- Page 27 3. Installing the Software When the following window appears, click [Finish]. Next, install the projector driver . If the following window appears, click [Install]. Installation of the projector driver begins. M E M O The computer’s display resolution will change during the process. The display may also flash or temporarily disappear. This is a normal part of the installation process and is not a malfunction. Setup.Guide...
- Page 28 M E M O Do not remove the USB cable or disconnect from the network until the two processes shown below are complete. • After connecting the machine to the computer, the DWP-80S driver installation begins. From [Control Panel], click [View devices and printers]. When the machine appears under "Printers," the installa- tion of the DWP-80S driver is complete.
- Page 29 3. Installing the Software Perform the following if the screen shown below is displayed. Windows 10 Click [Home] (or [Settings]). Click [Devices]. Click [Connected Devices] and verify that “PJ526ABRL” (or “DisplayLink USB Graphics Device”) is listed twice under “Other Devices.” If “PJ526ABRL” (or “DisplayLink USB Graphics Device”) is not listed twice, refer to the following. " P.41"Projector driver Does Not Operate Correctly" Setup.Guide...
- Page 30 When the following window appears, click [Restart Later]. The installation will continue by install- ing Quick Denta and the DWP-80S user’s manual. Do not restart at this time. If the computer is restarted, Quick Denta and the DWP-80S user’s manual will need to be installed separately.
- Page 31 3. Installing the Software When the following window appears, click [Finish]. To continue, proceed with installation of Quick Denta. Install Quick Denta and the manuals. When the following window appears, click [Next]. Quick Denta installation begins. Follow the on-screen explanations to proceed with the installa- tion. When the following window appears, click [Finish]. To continue, proceed with installation of the DWP-80S user’s manual. Setup.Guide...
- Page 32 3. Installing the Software When the following window appears, click [Next]. Installation of the DWP-80S manuals begins. Follow the on-screen explanations to proceed with the installation. When the following window appears, click [Finish]. When the following window appears, click [OK]. All installations are now complete. Click [X] on the setup menu. Remove the DGSHAPE Software Package CD from the computer. Setup.Guide...
-
Page 33: Launching The Software And Viewing The Manuals
Im po r t an t Be sure to restart the computer at this point. Launching the Software and Viewing the Manuals Launching the Software Windows 10 and 7 Click the [Start] button. Click [All apps] (or [All Programs] for Windows 7). Click the [Roland DWP-80S] folder, and then click [Quick Denta]. Windows 8.1 On the [Start] screen, click On the [Apps] screen, click the [Quick Denta] icon under [Roland DWP-80S]. Displaying the User's Manual (Electronic-format manual) Windows 10 and 7 From the [Start] menu, click [All apps] (or [All Programs]), [Roland DWP-80S], and then click [User's Manual]. -
Page 34: Troubleshooting
When the automatic playback window appears, click [Run menu.exe]. If a "User Account Con- trol" window appears, click [Allow] or [Yes], and then continue with the installation. The setup menu screen appears automatically. Click [Custom Install]. Click [Install] for the "DWP-80S Driver." Click [Install], select "Roland DWP-80S" for the model name and "USB" for the port, and then click [Start]. The DWP-80S driver installation begins. Follow the on-screen explanations to proceed with the installation. Setup.Guide... -
Page 35: Installing The Projector Driver Separately
USB cable until installation is complete. Installing the Projector Driver Separately Im p or t an t If the DWP-80S driver has not yet been installed, install it first. Otherwise, you may not be able to install the projector driver . Windows 10 version 1607 or later Carry out the operations in step under P.16 "Installing the Software and Manu-... - Page 36 Troubleshooting Insert the DGSHAPE Software Package CD into the CD-ROM drive of the computer. When the automatic playback window appears, click [Run menu.exe]. If a "User Account Control" window appears, click [Allow] or [Yes], and then continue with the installation. The setup menu screen appears automatically. Click [Custom Install]. Click [Install] for the "DisplayLink Driver." If the following window appears, click [Install]. Installation of the projector driver begins.
- Page 37 Troubleshooting If the following window appears, turn on the machine and connect the machine to the computer with the USB cable. Installation of the projector driver begins. During installation, several windows similar to that shown below will appear in order to show the installation progress. The computer’s display resolution will change during the process. The display may also flash or temporarily disappear. This is a normal part of the installation process and is not a malfunction.
- Page 38 Troubleshooting Click [Devices]. Click [Connected Devices] and verify that “PJ526ABRL” is listed twice under “Other Devices.” If [PJ526ABRL] is not listed twice, refer to the following. " P.41"Projector driver Does Not Operate Correctly" Windows 8.1 and 7 Verify that “PJ526ABRL” appears twice next to “Display.” If [PJ526ABRL] is not listed twice, refer to the following. " P.41"Projector driver Does Not Operate Correctly" Setup.Guide...
-
Page 39: Installing Quick Denta Or The Manuals Separately
Procedure Before installation, confirm that the machine and the computer are not connected with the USB cable. Log on to Windows as the computer's administrator (or as an "Administrators" ac- count). Insert the DGSHAPE Software Package CD into the CD-ROM drive of the computer. When the automatic playback window appears, click [Run menu.exe]. If a "User Account Con- trol" window appears, click [Allow] or [Yes], and then continue with the installation. The setup menu screen appears automatically. Setup.Guide... -
Page 40: Dwp-80S Driver Installation Is Impossible
Click [Custom Install]. Click [Install] for “Quick Denta” or the “DWP-80S Manuals.” When the following window appears, click [Next]. Installation of Quick Denta or the DWP-80S manuals begins. Follow the on-screen explanations to proceed with the installation. DWP-80S Driver Installation Is Impossible If a wizard does not appear even though you have connected the USB cable, do the following: Windows 10 Windows 8.1... - Page 41 Manager]. If a [User click [Continue]. appears, click [Con- Account Control] The [Device Manager] tinue]. window appears, appears. click [Continue]. The [Device Manager] appears. The [Device Manager] appears. From the [View] menu, click [Show hidden devices]. In the list, find and double-click [Printers] or [Other devices]. When the model name you are using or [Unknown device] appears below the item you selected, click the model name to select it. Go to the [Action] menu, and click [Uninstall]. In the [Confirm In the "Confirm Device Uninstall" window, click Device Uninstall] [OK]. window, select [Delete the driver software for this device.], then click [OK]. Close [Device Manager]. Remove the USB cable from the computer, and then restart Windows. Uninstall the driver by following the procedure described on P.40"Uninstalling the DWP-80S Driver" Reinstall the driver again following the driver installation procedure in the Set- up Guide. Setup.Guide...
-
Page 42: Uninstalling The Dwp-80S Driver
Troubleshooting Uninstalling the DWP-80S Driver When uninstalling the driver, perform the following operation: Windows 10 Windows 8.1 Windows 7 Turn off the machine and disconnect the cable connecting the computer and the machine. Log on to Windows as an administrator. Right-click [Start]. Click [Desktop]. Click [Start]. Point to the low- er-right corner of the screen to display the charms, and click [Settings]. Click [Programs and Click [Control Panel], and then click [Uninstall a Features]. Program]. Select the driver of the machine to delete by clicking it, click [Uninstall], and then click [Start]. If a message prompting you to confirm deletion appears, click [Yes]. When the "User When the "User When the "User Account Control" Account Control" Account Control"... -
Page 43: Projector Driver Does Not Operate Correctly
If you're not using the CD-ROM, go to the DGSHAPE Corporation website (http://www. dgshape.com/), download the driver for the machine you want to delete, and then speci- fy the folder where you want to extract the downloaded file. • For 64-bit systems: Drivers\WINX64 •... - Page 44 Troubleshooting Windows 10 (version 1607 or later) Windows 10 (version earlier than 1607) Check whether “USB Projec- Check whether "USB Projector" is tor” is displayed under “Display displayed under "USB Display Adapt- adapters.” If “USB Projector” is ers." If “USB Projector” is displayed, displayed, perform procedure perform procedure . If not, per- If not, perform the procedures form the procedures through through Click [Control Panel] and then [Adjust Screen Resolution]. If “Multiple displays” is set to “Extend these displays,” uninstall and re-install the projector driver. " P.44"Uninstalling the Projector driver" If “Multiple displays” is not set to “Extend these displays,” change the setting to “Extend these displays.” Click [Control Panel] and then click [Uninstall a Program]. Verify that “DisplayLink Core Look for “DisplayLink Core Software” Software,” “DisplayLink Graphics,” and “DisplayLink Graphics.” and “DisplayLink Graphics Driver” If neither “DisplayLink Core Software” are not displayed. nor “DisplayLink Graphics” is shown, the If “DisplayLink Core Software,”...
- Page 45 Troubleshooting Windows 8.1 Windows 7 Connect the machine to the computer with the USB cable and turn on the ma- chine. From [Start], click [Desktop]. Point From [Start], click [Control Panel], to the lower-right corner of the [Hardware and Sound], and then screen to display the charms, and [Device Manager]. click [Settings]. "Device Manager" appears. From [Control Panel], click [Hard- Check whether "USB Projector" is ware and Sound] and then [Device displayed under "USB Display Adapt- Manager]. ers." If “USB Projector” is displayed, perform procedure . If not, per- The [Device Manager] appears. form the procedures through Check whether "USB Projector" is displayed under "USB Display Adapters." If “USB Projector” is displayed, perform procedure . If not, perform the proce- dures through Click [Control Panel] and then [Adjust Screen Resolution]. If “Multiple displays” is set to “Ex- tend these displays,” uninstall and re-install the projector driver. " P.44"Uninstalling the Projector driver" If “Multiple displays” is not set to “Extend these displays,” change the setting to “Extend these dis-...
-
Page 46: Printing Is No Longer Possible After Using Windows 10
Troubleshooting Printing is No Longer Possible after Using Windows 10 If you perform one of the following operations to update to version 1607 or later of Windows 10, the new and old drivers for the projector will conflict with each other and prevent the machine from operating. -
Page 47: Correct Installation Of The Dwp-80S Driver Is Impossible (Listed As "Unspecified")
Correct Installation of the DWP-80S Driver Is Impossible (Listed as “Unspecified”) If the DWP-80S driver is not installed correctly, the installed driver will be listed as “Unspecified” on the computer. In such cases, perform the following procedure to reinstall the driver. - Page 48 Windows 8.1 Windows 7 Right-click on the “Unspecified” DWP-80S driver for the machine being used, and then click [Properties]. If the machine and the computer are not connected, no DWP-80S driver will be displayed under “Unspecified.” If no driver is displayed, turn on the machine and connect the ma- chine to the computer. Click the [Hardware] tab, then double-click the name of the model being used. Click [Change Settings] on the [General] tab to hide the button.
