CARTON #1 CONTENTS
ITEM
QUANTITY
A
1
B
1
C
2
-
8
TOOLS REQUIRED - PHILLIPS SCREW DRIVER / PLIERS
OPTIONAL FOR EASIER ASSEMBLY: ELECTRIC DRIVER, PHILLIPS DRIVER BIT,
PG 1
INSTALLATION INSTRUCTIONS
GT1301 – FOLDING TABLE W/ RESIN TABLE TOP
DESCRIPTION
TOP BRACKET - 48" WIDE
BOTTOM BRACKET -
FOLDING ARM ASSEMBLIES
NUTS, WASHERS, YELLOW CAPS
QUESTIONS ???? CALL 1-866 664 2724
CARTON # 2 CONTENTS
QUANTITY
1
TABLE TOP – 2FT X 4 FT
2
STIFFENERS
8
SCREWS – 1"
3/32" DRILL BIT, SOCKET WRENCH SET.
DESCRIPTION
REV 1, 8/11
Advertisement
Table of Contents
Related Manuals for Garage Tek GT1301
Summary of Contents for Garage Tek GT1301
- Page 1 INSTALLATION INSTRUCTIONS GT1301 – FOLDING TABLE W/ RESIN TABLE TOP CARTON #1 CONTENTS CARTON # 2 CONTENTS ITEM QUANTITY DESCRIPTION QUANTITY DESCRIPTION TOP BRACKET - 48” WIDE TABLE TOP – 2FT X 4 FT BOTTOM BRACKET - STIFFENERS FOLDING ARM ASSEMBLIES SCREWS –...
- Page 2 FOLDING TABLE W/ RESIN TOP - ASSEMBLY INSTRUCTIONS STEP #1: CHECK CONTENTS OF BOTH CARTONS STEP #2: PLACE TOP BRACKET (A) THE DESIRED DISTANCE FROM THE FLOOR. MOUNT THE 2 FOLDING ARM ASSEMBLIES (C) ON THE TOP BRACKET AND FASTEN WITH THE SUPPLIED NUTS, WASHERS &...
- Page 3 (THIS IS IMPORTANT SO THE TABLE TOP CAN BE “LIFTED” TO DOWN INTO THE FOLDED POSITION. ) STEP #7 THIS COMPLETES THE GT1301 ASSEMBLY. STEP #7: WITH THE SUPPLIED 1” SCREWS, FASTEN THROUGH THE REAR 2 HOLES IN EACH BRACKET ASSEMBLY INTO THE STIFFENER PREVIOUSLY INSTALLED ON THE TABLE TOP IN STEP #5..
- Page 4 FOLDING TABLE OPERATION DIAGRAM OF OPERATING STEPS PG 4 QUESTIONS ???? CALL 1-866 664 2724 REV 1, 8/11...
