CARTON CONTENTS
QUANTITY
DESCRIPTION
CARTON #1
1
CABINET COMPONENTS
CARTON #2
4
POSTS
1
MOUNTING BRACKET
12
#18 X 1 SCREWS
TOOLS REQUIRED - ELECTRIC DRIVER OR DRILL
PHILLIPS DRIVER BIT
1/16 OR 3/32 DIA AND 1/8 DIA DRILL BIT
HAMMER OR RUBBER MALLET
SAFETY GLASSES
PG 1
INSTALLATION INSTRUCTIONS
GT1005AE WALL CABINET, RESIN
35 1/4" LG
QUESTIONS ???? CALL 1-866 664 2724
REV 1, 10/11
Advertisement
Table of Contents
Related Manuals for Garage Tek GT1005AE
Summary of Contents for Garage Tek GT1005AE
- Page 1 INSTALLATION INSTRUCTIONS GT1005AE WALL CABINET, RESIN CARTON CONTENTS QUANTITY DESCRIPTION CARTON #1 CABINET COMPONENTS CARTON #2 POSTS 35 1/4" LG MOUNTING BRACKET #18 X 1 SCREWS TOOLS REQUIRED - ELECTRIC DRIVER OR DRILL PHILLIPS DRIVER BIT 1/16 OR 3/32 DIA AND 1/8 DIA DRILL BIT...
- Page 2 WALL CABINET, RESIN ASSEMBLY INSTRUCTIONS SEE ADDITIONAL REFERENCE PHOTOS ON PAGES 5 THRU 7 TO MATCH THE DIAGRAM STEPS BELOW. ITEM QTY DESCRIPTION CARTON #1 BASE / TOP SIDE / DOOR PANEL SHELF HINGE HANDLE SET (L/R) SCREW, 1 1/2" LG SCREW, 7/8 LG SHELF CLIP LABEL...
- Page 3 WALL CABINET, RESIN ASSEMBLY INSTRUCTIONS STEP #3: A. SLIDE THE POSTS (L) INTO THE FOUR LOCATIONS SHOWN. SLIDE THE POST PAST THE BOTTOM OPENING , PLACE THE BOTTOM CAPS (D) ON THE POSTS AND PUSH INTO THE CABINET BOTTOM OPENING. B.
- Page 4 WALL CABINET, RESIN ASSEMBLY INSTRUCTIONS STEP #5 A. CUTOUT TEMPLATE ON PAGE 7 OF THESE INSTRUCTIONS, PLACE AS SHOWN ABOVE AND MARK THE HOLE LOCATIONS. THE HOLE ON THE INSIDE ALREADY MATCHES A PRE-EXISTING BOSS. DRILL THROUGH THE PANELS WITH A 1/8 DIA DRILL BIT. B.
- Page 5 WALL CABINET, RESIN ASSEMBLY INSTRUCTIONS STEP #7 THE CABINET IS READY FOR MOUNTING ON EITHER TEKPANEL OR TEKTRAK. DOOR CLOSING ADJUSTMENT WHEN THE CABINET IS INSTALLED, THE EASE OR DIFFICULTY OF CLOSING THE DOORS CAN BE ADJUSTED BY TRIMMING THE HEIGHT OF THE BUTTONS SHOWN IN THE ABOVE IMAGE. BUTTONS ARE ON THE TOP AND BOTTOM OF EACH DOOR.
- Page 6 WALL CABINET, RESIN ASSEMBLY INSTRUCTIONS STEP #6 SHELF CLIPS / SHELVES STEP #6 BACK SHELF CLIP STEP #6 - BIN PG 6 QUESTIONS ???? CALL 1-866 664 2724 REV 1, 10/11...
- Page 7 HANDLE DRILL TEMPLATE 1. CHECK PRINTOUT DIMENSIONS OF TEMPLATE ARE CORRECT 2. CUTOUT, MARK AND DRILL 3. SCREW ONTO PANELS...
