CARTON CONTENTS
ITEM QUANTITY
A
1
B
1
C
4
D
2
E
2
F
2
G
4
H
12
TOOLS REQUIRED - ELECTRIC DRIVER OR DRILL & PHILLIPS BIT
PG 1
INSTALLATION INSTRUCTIONS
GT2011E GOLF CENTER
DESCRIPTION
SQUARE TUBE
TOP BAR W/ PANEL BRACKET
HANGER HOOK
SHELF
CORNER BRACE
SIDE FRAME
1/2" LONG SCREW
1 1/2" LONG SCREW
QUESTIONS ???? CALL 1-866 664 2724
REV 1, 8/11
Advertisement
Table of Contents
Related Manuals for Garage Tek GT2011E
Summary of Contents for Garage Tek GT2011E
- Page 1 INSTALLATION INSTRUCTIONS GT2011E GOLF CENTER CARTON CONTENTS ITEM QUANTITY DESCRIPTION SQUARE TUBE TOP BAR W/ PANEL BRACKET HANGER HOOK SHELF CORNER BRACE SIDE FRAME 1/2" LONG SCREW 1 1/2” LONG SCREW TOOLS REQUIRED - ELECTRIC DRIVER OR DRILL & PHILLIPS BIT...
- Page 2 GOLF CENTER - ASSEMBLY INSTRUCTIONS STEP 1 STEP 2 STEP #1: CHECK PARTS RECEIVED. STEP #2: POSITION THE PARTS AS SHOWN AN USE THE 1 ½” LG SCREWS TO FASTEN IN SIX PLACES. IMPORTANT: THE OPEN MESH ON THE SIDE FRAMES FACES OUT. STEP 3 STEP 4 STEP #3: FLIP THE ASSEMBLY AND FASTEN AGAIN IN SIX PLACES.
