- Page 1 rackmount for ml:series product information and installation guide...
- Page 2 • Holds up to two ml:series devices The sonible rackmount adapter can hold up to two devices from the sonible ml:series. The ml:series consists of the • Optional rack panel for three D-Format USB DI-Box ml:1 and the MADI converter ml:mio. Since...
-
Page 3: Weight And Dimensions
weight & dimensions 44,2mm 1,7’’ 482,6mm / 19’’ depth: 150mm / 5,9’’ weight: 1,35kg / 3,0lbs contents 1x connector blind 2x ml:mio 1x rackmount routing sticker 4x countersunk 6mm 6x countersunk 8mm 2x ml:1 routing sticker M3 TX10 screws M3 TX10 screws... - Page 4 installation option 1 - visible outputs step 1 undo top screws on your device, insert into rack step 2 screw in 8mm TX10 screws step 3 (optional) insert additional device...
- Page 5 installation option 2 - visible switches step 1 undo top screws on your device, insert into rack step 2 screw in 8mm TX10 screws step 3 add matching routing sticker to device step 4 (optional) insert additional device...
- Page 6 installation option 3 - with output blind step 1 undo top screws on your device, insert into rack step 2 screw in 8mm TX10 screws step 3 attach inputs of your choosing (not provided) step 4 insert output blind, screw in 6mm screws, connect ml:mio and outputs in blind...
- Page 7 GmbH Haydngasse 10 8010 Graz Austria +43 316 91 22 88 contact@sonible.com www.sonible.com...
