PROART DUAL AM/FM TUNER WITH RS232
www.altronics.com.au

OPERATING INSTRUCTIONS

VIDEO DOOR INTERCOM
S 9413A Base Station & Camera System
S 9414A Additional Base Station
S 9415A Additional Camera Unit
Manufactured in China for Altronic Distributors Pty Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S 9413A and is the answer not in the manual?

Questions and answers

Summary of Contents for Altronics S 9413A

  • Page 1: Operating Instructions

    PROART DUAL AM/FM TUNER WITH RS232 www.altronics.com.au OPERATING INSTRUCTIONS VIDEO DOOR INTERCOM S 9413A Base Station & Camera System S 9414A Additional Base Station S 9415A Additional Camera Unit Manufactured in China for Altronic Distributors Pty Ltd...
  • Page 2 VIDEO DOOR INTERCOM SYSTEM Included in the box: • Indoor base station x 1 • Outdoor camera x 1 • Indoor handset x 1 • Expansion junction box x 1 • Mounting bracket x 1 • Mounting screws (4Gx18mm) x 2 •...
  • Page 3 VIDEO DOOR INTERCOM SYSTEM Page 7...
  • Page 4: Troubleshooting

    VIDEO DOOR INTERCOM SYSTEM Troubleshooting Problem Cause No power (Power LED off) Insert power cord into power outlet. Ensure the ON/OFF switch on the bottom of the unit is switched to ON. Power LED dim Cabling between monitor and camera has a short circuit. No picture Check the brightness control.
  • Page 5 VIDEO DOOR INTERCOM SYSTEM Fig 2. Outdoor Camera Unit Fig 1. Base Station. 1. Camera 2. Microphone 3. Infra-Red LEDs 4. Speaker 5. Call button 1. Handset 2. Speaker Stand by 3. Screen 4. Power LED 5. Monitor button 6. Call button 7.
  • Page 6 12V 1A d.c. plugpack such as the Altronics M 9274A should be suitable for most door strikes. Drill cable entry hole in box containing PCB (PCB labelled ‘Altronics strike timer V1’). This box can be located up to 20m from the door strike.
  • Page 7 VIDEO DOOR INTERCOM SYSTEM Fig 5. Wiring for two indoor base stations and two outdoor Camera 1 camera units. Ensure all wires go to the correct terminals ie: 1 to 1, 2 to 2 and so on. See Fig. 6 Optional door lock interface Base Station 2...
  • Page 8 For repair or service please contact your place of purchase. Note: Under no circumstances should you attempt to repair the product yourself or via a non-authorised Altronics service centre as this will invalidate the warranty! During the warranty period, we undertake to repair or replace your product at no charge if found to be defective due to a manufacturing fault.
